The 30BQ100 is a Schottky Barrier Rectifier diode designed for high efficiency and low power loss applications. This diode features a forward current of 3A and a reverse voltage of 100V, making it suitable for various rectification and switching tasks in electronic circuits. In addition to its impressive technical specifications, the 30BQ100 also offers easy installation on PCBs and efficient heat dissipation, thanks to its surface mount SMB package (DO-214AA). This makes it a versatile option for a wide range of electronic circuits and devices, where space is at a premium and optimal thermal management is crucial.
SMC 30BQ100's Features
- Schottky Barrier Rectifier: The 30BQ100 is a Schottky diode known for its fast switching and low forward voltage drop characteristics.
- High Efficiency: This diode offers high efficiency in power conversion applications, reducing energy loss.
- Low Power Dissipation: With its low forward voltage drop, the 30BQ100 minimizes power dissipation and heat generation.
- Fast Switching Speed: The diode provides fast switching speed, ideal for high-frequency rectification and switching applications.
SMC 30BQ100's Applications
The 30BQ100 Schottky diode finds applications in power supplies, freewheeling in inverters, battery chargers, voltage clamping, and reverse polarity protection in various electronic systems.
SMC 30BQ100's Attributes
| Product Category | Schottky Diodes & Rectifiers | RoHS | N |
| Product | Schottky Diodes | Mounting Style | SMD/SMT |
| Package / Case | DO-214AB-2 | Configuration | Single |
| Technology | Si | If - Forward Current | 3 A |
| Vrrm - Repetitive Reverse Voltage | 100 V | Vf - Forward Voltage | 900 mV |
| Ifsm - Forward Surge Current | 800 A | Ir - Reverse Current | 500 uA |
| Minimum Operating Temperature | - 55 C | Maximum Operating Temperature | + 175 C |
| Brand | Vishay Semiconductors | Height | 2.62 mm |
| Length | 7.11 mm | Product Type | Schottky Diodes & Rectifiers |
| Factory Pack Quantity | 1000 | Subcategory | Diodes & Rectifiers |
| Type | Schottky Diode | Width | 6.22 mm |
| Unit Weight | 0.010582 oz |
SMC 30BQ100's Datasheet
SMC 30BQ100's Category - SCHOTTKY RECTIFIER
Unipolar power diodes, also known as Schottky rectifier diodes, rely on the metal-semiconductor barrier for their rectification function. In addition, this type of diode also contains a drift region, whose resistance increases rapidly under the action of reverse voltage. Therefore, the blocking voltage of commercial silicon Schottky diodes is usually limited to less than 100V to prevent the on-state voltage drop from becoming too large when exceeding this value. Although silicon PiN diodes have a slower switching speed, their low on-state voltage drop makes it possible to design devices with a higher breakdown voltage.
30BQ100's Manufacturer - SMC
SMC Corporation was founded in 1959, with its headquarters located in Tokyo, Japan. Up to now, SMC has become a developer, manufacturer, and distributor of pneumatic components. It has an extensive market network in Japan, providing customers with products and after - sales services. As a multinational company engaged in the manufacturing and sales of pneumatic components, SMC's sales network and production bases are spread all over the world. SMC products are renowned globally for their complete range, high reliability, cost - effectiveness, and ability to meet the needs of different users in numerous fields.
