SBH31 - NBPB - D12 - ST - BK is a model-specific connector for the SBH31 series produced by Sullins. SBH31 stands for series and has a box-type male head with a 0.050 " (1.27mm) contact center and row spacing. N stands for nylon insulating material, which provides electrical insulation and mechanical support; B stands for brass contact material, which has good electrical conductivity and mechanical properties. P stands for overall gold-plated and RoHS-compliant, which can improve electrical conductivity and corrosion resistance. D means dual-row configuration, with 12 for each row of 12 contact positions. ST is in-line for easy straight-through board installation. BK indicates that the connector is black. Overall, it is a black, double-row, straight-in, 12-pin brass pin per row, gold-plated, nylon-insulated SBH31 series box male connector.
SBH31-NBPB-D12-ST-BK 's Features
Based on its characteristics as a rectangular male connector, the SBH31 - NBPB - D12 - ST - BK may have the following applications. In computer hardware, expansion cards such as graphics cards can be connected to the main board to achieve high-speed data transmission, or memory modules can be connected to ensure read and write operations. In terms of communication equipment, it can be used for board-to-board connection of routers and other equipment to transmit high-speed signals, and can also be connected to communication modules and antennas to ensure stable signal transmission and reception. In the field of industrial automation control, sensors and controllers can be connected to allow sensors to transmit data in real time, and controllers and actuators can also be connected, such as controlling temperature sensors on production lines or motors of robot arms, to achieve precise control.
SBH31-NBPB-D12-ST-BK 's Applications
Based on its characteristics as a rectangular male connector, the SBH31 - NBPB - D12 - ST - BK may have the following applications. In computer hardware, expansion cards such as graphics cards can be connected to the main board to achieve high-speed data transmission, or memory modules can be connected to ensure read and write operations. In terms of communication equipment, it can be used for board-to-board connection of routers and other equipment to transmit high-speed signals, and can also be connected to communication modules and antennas to ensure stable signal transmission and reception. In the field of industrial automation control, sensors and controllers can be connected to allow sensors to transmit data in real time, and controllers and actuators can also be connected, such as controlling temperature sensors on production lines or motors of robot arms, to achieve precise control.
SBH31-NBPB-D12-ST-BK's Attributes
| Attribute Name | Attribute Value | Attribute Name | Attribute Value |
|---|---|---|---|
| Category | Rectangular Connectors - Headers, Male Pins | Contact Length - Mating | - |
| Manufacturer | Sullins Connector Solutions | Contact Length - Post | 0.094" (2.40mm) |
| Series | SBH31 | Overall Contact Length | - |
| Packaging | Tray | Insulation Height | 0.211" (5.35mm) |
| Part Status | Active | Contact Shape | Square |
| Connector Type | Header | Contact Finish - Mating | Gold |
| Contact Type | Male Pin | Contact Finish Thickness - Mating | Flash |
| Pitch - Mating | 0.050" (1.27mm) | Contact Finish - Post | Gold |
| Number of Positions | 24 | Contact Material | Brass |
| Number of Rows | 2 | Insulation Material | Polyamide (PA9T), Nylon 9T |
| Row Spacing - Mating | 0.050" (1.27mm) | Features | - |
| Number of Positions Loaded | All | Operating Temperature | -40°C ~ 105°C |
| Style | Board to Board | Ingress Protection | - |
| Shrouding | Shrouded - 4 Wall | Material Flammability Rating | UL94 V-0 |
| Mounting Type | Through Hole, Right Angle | Insulation Color | Black |
| Termination | Solder | Current Rating (Amps) | 1A |
| Fastening Type | Push-Pull | Voltage Rating |
SBH31-NBPB-D12-ST-BK's Datasheet
FTS-104-02-F-DV-TR vs SBH31-NBPB-D12-ST-BK
| Image |  |  |
| Part Number | FTS-104-02-F-DV-TR | SBH31-NBPB-D12-ST-BK |
| Category | Rectangular Connectors - Headers, Male Pins | Rectangular Connectors - Headers, Male Pins |
| Manufacturer | Samtec Inc. | Sullins Connector Solutions |
| Description | .050 X .050 C.L. LOW PROFILE TER | CONN HEADER .050" 24POS |
| Package | - | - |
| Series | FTS | SBH31 |
| Operating Temperature | -55°C ~ 125°C | -40°C ~ 105°C |
| Mounting Type | Surface Mount | Through Hole |
| Termination | Solder | Solder |
| Style | Board to Board or Cable | Board to Board |
| Current Rating | 3.3A per Contact | 1A |
| Contact Material | Phosphor Bronze | Brass |
| Number of Positions | 8 | 24 |
| Connector Type | Header, Cuttable | Header |
| Number of Positions Loaded | All | All |
| Number of Rows | 2 | 2 |
| Insulation Color | Black | Black |
| Contact Type | Male Pin | Male Pin |
| Fastening Type | Push-Pull | Push-Pull |
| Material Flammability Rating | UL94 V-0 | UL94 V-0 |
| Pitch - Mating | 0.050" (1.27mm) | 0.050" (1.27mm) |
| Shrouding | Unshrouded | Shrouded - 4 Wall |
| Contact Length - Mating | 0.075" (1.90mm) | - |
| Insulation Height | 0.034" (0.86mm) | 0.213" (5.40mm) |
| Contact Shape | Square | Square |
| Contact Finish - Mating | Gold | Gold |
| Contact Finish - Post | Tin | Gold |
| Insulation Material | Liquid Crystal Polymer (LCP) | Polyamide (PA9T), Nylon 9T |
| Contact Finish Thickness - Mating | 3µin (0.08µm) | Flash |
| Row Spacing - Mating | 0.050" (1.27mm) | 0.050" (1.27mm) |
| Contact Length - Post | - | 0.094" (2.40mm) |
SBH31-NBPB-D12-ST-BK's Category - Rectangular Connectors
Rectangular connectors, also known as rectangular sockets, are common electronic components. They are usually composed of a metal shell and pins, and are often used as interfaces in electronic devices to connect circuit boards with external power supplies or signals. Compared with other connectors, rectangular connectors have a relatively simple shape and a small size, and can accommodate a large number of pins. Therefore, they are widely used in various electronic devices.
The Meaning of Rectangular Connector Model Numbers
The model numbers of rectangular connectors usually consist of multiple characters, with each character representing specific functions and performance parameters. The specific meanings are as follows:
In summary, by looking at the model number of a rectangular connector, we can understand its specific functions and performance parameters to meet the needs of different application scenarios.
Application Fields of Rectangular Connectors
