KEMET UD2-5NU

The UD2-5NU is a precision voltage reference IC that provides a stable and accurate reference voltage for various electronic applications. It is designed to offer high precision and low noise performance, making it suitable for precision measurement and control systems.

KEMET UD2-5NU's Features

Precision Voltage Reference: Provides a stable and accurate reference voltage for precise voltage-based applications.
Low Noise Performance: Offers low noise operation for high-precision measurement systems.
High Precision: Delivers precise voltage output with minimal deviation.
Wide Operating Temperature Range: Suitable for operation in various temperature conditions.
Small Form Factor: Available in a compact package for space-efficient designs.

Note: For detailed technical specifications, please refer to the UD2-5NU datasheet.

KEMET UD2-5NU's Applications

Electronic switching systems
PBX
Terminal equipment
Telephone systems

KEMET UD2-5NU's Attributes

Type	Description
Category	Relays Signal Relays, Up to 2 Amps
Manufacturer	KEMET
Series	UD2
Packaging	Tube
Part Status	Active
Mounting Type	Surface Mount
Coil Voltage	5VDC
Contact Form	DPDT (2 Form C)
Contact Rating (Current)	1 A
Switching Voltage	250VAC, 220VDC - Max
Load - Max Switching	250VA, 220W
Coil Current	28 mA
Coil Type	Non Latching
Termination Style	Gull Wing
Must Operate Voltage	3.75 VDC
Must Release Voltage	0.5 VDC
Operate Time	2 ms
Release Time	1 ms
Operating Temperature	-40°C ~ 85°C
Contact Material	Silver Alloy, Gold Alloy
Approval Agency	CSA, TUV, UL
Relay Type	General Purpose
Coil Resistance	178 Ohms
Base Product Number	UD2-5N

KEMET UD2-5NU's Datasheet

KEMET UD2-5NU's Category - Relays

Relays are commonly used components in automotive control circuits. They operate based on the principle of electromagnetic induction to control the connection or disconnection of a certain circuit, achieving the control of large currents with small currents, thereby reducing the current load on the control switch contacts and protecting the switch contacts from erosion.

Working Principle and Characteristics of Relays: A relay is an electronic control device that consists of a control system (also known as the input circuit) and a controlled system (also known as the output circuit), and is typically used in automatic control circuits. It is essentially an "automatic switch" that uses a smaller current to control a larger current. Relays play the roles of automatic regulation, safety protection, and circuit conversion in circuits.

UD2-5NU's Manufacturer - KEMET

KEMET Corporation is a leading global supplier of electronic components. We offer our customers the broadest selection of capacitor technologies in the industry across all dielectrics, along with an expanding range of electromechanical devices, electromagnetic compatibility solutions and supercapacitors. Our vision is to be the preferred supplier of electronic component solutions for customers demanding the highest standards of quality, delivery, and service.
