Headers, Plugs and Sockets(86764)

Image Product Number Pricing(USD) Quantity ECAD Quantity Available Weight(Kg) Mfr Series Package Product Status Operating Temperature Mounting Type Type Features Color Ingress Protection Termination Style DataSheet RoHS Status Moisture Sensitivity Level (MSL) REACH Status Other Names ECCN HTSUS Standard Package Pitch Contact Material Housing Material Material Flammability Rating Number of Positions Insulation Height Wire Gauge or Range - AWG Wire Gauge or Range - mm² Screw Size Positions Per Level Number of Levels Header Orientation Plug Wire Entry Current - IEC Current - UL Voltage - UL Contact Mating Finish Torque - Screw Wire Strip Length Contact Tail Length Voltage - IEC
1928430000 Weidmüller 1928430000 8.0972
RFQ
 ECAD 9087 0.00000000 Weidmüller Omnimate BV Bulk Active -50°C ~ 130°C Through Hole Header, Blade Sockets Mating and Mounting Flange Black IP20 Solder - RoHS Compliant 1 (Unlimited) REACH Unaffected BVL7.62HP/06/90FI 3.5SN BK BX EAR99 8536.69.4040 50 0.300" (7.62mm) Copper Alloy Polyamide (PA), Nylon, Glass Filled UL94 V-0 6 0.449" (11.40mm) - - - 6 1 90°, Right Angle - 41A 35 A 300 V Tin - - 0.138" (3.50mm) 1 kV
1928440000 Weidmüller 1928440000 8.7628
RFQ
 ECAD 3631 0.00000000 Weidmüller Omnimate BV Bulk Active -50°C ~ 130°C Through Hole Header, Blade Sockets Mating and Mounting Flange Black IP20 Solder - RoHS Compliant 1 (Unlimited) REACH Unaffected BVL7.62HP/07/90FI 3.5SN BK BX EAR99 8536.69.4040 50 0.300" (7.62mm) Copper Alloy Polyamide (PA), Nylon, Glass Filled UL94 V-0 7 0.449" (11.40mm) - - - 7 1 90°, Right Angle - 41A 35 A 300 V Tin - - 0.138" (3.50mm) 1 kV
1929630000 Weidmüller 1929630000 3.2520
RFQ
 ECAD 9244 0.00000000 Weidmüller Omnimate BV Bulk Active -50°C ~ 125°C Free Hanging (In-Line) Plug, Blade Sockets Mating Flange Black IP20 Screw - Clamping Yoke (Tension Sleeve) - RoHS Compliant 1 (Unlimited) REACH Unaffected BVZ 7.62HP/02/180FC SN BK BX EAR99 8536.69.8000 100 0.300" (7.62mm) Copper Alloy Polyamide (PA), Nylon, Glass Filled UL94 V-0 2 1.010" (25.65mm) 8-24 AWG 0.2-6mm² M3 2 1 - 180° 41A 40.5 A 600 V Tin 0.5-0.6 Nm (4.4-5.3 Lb-In) 12mm - 1 kV
1929650000 Weidmüller 1929650000 5.6961
RFQ
 ECAD 5076 0.00000000 Weidmüller Omnimate BV Bulk Active -50°C ~ 125°C Free Hanging (In-Line) Plug, Blade Sockets Mating Flange Black IP20 Screw - Clamping Yoke (Tension Sleeve) - RoHS Compliant 1 (Unlimited) REACH Unaffected BVZ 7.62HP/04/180FC SN BK BX EAR99 8536.69.8000 100 0.300" (7.62mm) Copper Alloy Polyamide (PA), Nylon, Glass Filled UL94 V-0 4 1.010" (25.65mm) 8-24 AWG 0.2-6mm² M3 4 1 - 180° 41A 40.5 A 600 V Tin 0.5-0.6 Nm (4.4-5.3 Lb-In) 12mm - 1 kV
1930080000 Weidmüller 1930080000 6.9670
RFQ
 ECAD 4864 0.00000000 Weidmüller Omnimate BV Bulk Active -50°C ~ 125°C Free Hanging (In-Line) Plug, Blade Sockets Latch Lock, Mating Flange Black IP20 Screw - Clamping Yoke (Tension Sleeve) - RoHS Compliant 1 (Unlimited) REACH Unaffected EAR99 8536.69.8000 50 0.300" (7.62mm) Copper Alloy Polyamide (PA), Nylon, Glass Filled UL94 V-0 5 0.909" (23.09mm) 8-24 AWG 0.2-6mm² M3 5 1 - 180° 41A 40.5 A 600 V Tin 0.5-0.6 Nm (4.4-5.3 Lb-In) 12mm - 1 kV
1933450000 Weidmüller 1933450000 9.8220
RFQ
 ECAD 7176 0.00000000 Weidmüller Omnimate SV Bulk Active -50°C ~ 125°C Free Hanging (In-Line) Plug, Blade Sockets Mating Flange, Strain Relief Black IP20 Screw - Clamping Yoke (Tension Sleeve) - RoHS Compliant 1 (Unlimited) REACH Unaffected BVZ 7.62HP/05/180SH210 SN BK EAR99 8536.69.8000 25 0.300" (7.62mm) Copper Alloy Polyamide (PA), Nylon, Glass Filled UL94 V-0 5 - 8-24 AWG 0.2-6mm² M3 5 1 - 180° 41A 40.5 A 600 V Tin 0.5-0.6 Nm (4.4-5.3 Lb-In) 12mm - 1 kV
1929970000 Weidmüller 1929970000 10.8000
RFQ
 ECAD 100 0.00000000 Weidmüller Omnimate BV Bulk Active -50°C ~ 125°C Free Hanging (In-Line) Plug, Blade Sockets - Black IP20 Screw - Clamping Yoke (Tension Sleeve) - RoHS Compliant 1 (Unlimited) REACH Unaffected BVZ 7.62HP/06/180 SN BK BX EAR99 8536.69.8000 50 0.300" (7.62mm) Copper Alloy Polyamide (PA), Nylon, Glass Filled UL94 V-0 6 0.909" (23.09mm) 8-24 AWG 0.2-6mm² M3 6 1 - 180° 41A 40.5 A 600 V Tin 0.5-0.6 Nm (4.4-5.3 Lb-In) 12mm - 1 kV
1929880000 Weidmüller 1929880000 11.1036
RFQ
 ECAD 1151 0.00000000 Weidmüller Omnimate BV Bulk Active -50°C ~ 125°C Free Hanging (In-Line) Plug, Blade Sockets Mating Flange, Strain Relief Black IP20 Screw - Clamping Yoke (Tension Sleeve) - RoHS Compliant 1 (Unlimited) REACH Unaffected BVZ 7.62HP/06/180SH150 SN BK EAR99 8536.69.8000 25 0.300" (7.62mm) Copper Alloy Polyamide (PA), Nylon, Glass Filled UL94 V-0 6 - 8-24 AWG 0.2-6mm² M3 6 1 - 180° 41A 40.5 A 600 V Tin 0.5-0.6 Nm (4.4-5.3 Lb-In) 12mm - 1 kV
1929890000 Weidmüller 1929890000 7.3906
RFQ
 ECAD 1673 0.00000000 Weidmüller Omnimate BV Bulk Active -50°C ~ 125°C Free Hanging (In-Line) Plug, Blade Sockets Mating Flange, Strain Relief Black IP20 Screw - Clamping Yoke (Tension Sleeve) - RoHS Compliant 1 (Unlimited) REACH Unaffected BVZ7.62HP/03/180SH150C BK BX EAR99 8536.69.8000 50 0.300" (7.62mm) Copper Alloy Polyamide (PA), Nylon, Glass Filled UL94 V-0 3 - 8-24 AWG 0.2-6mm² M3 3 1 - 180° 41A 40.5 A 600 V Tin 0.5-0.6 Nm (4.4-5.3 Lb-In) 12mm - 1 kV
1933480000 Weidmüller 1933480000 8.5408
RFQ
 ECAD 4471 0.00000000 Weidmüller Omnimate SV Bulk Active -50°C ~ 125°C Free Hanging (In-Line) Plug, Blade Sockets Mating Flange, Strain Relief Black IP20 Screw - Clamping Yoke (Tension Sleeve) - RoHS Compliant 1 (Unlimited) REACH Unaffected BVZ7.62HP/04/180SH210C BK BX EAR99 8536.69.8000 25 0.300" (7.62mm) Copper Alloy Polyamide (PA), Nylon, Glass Filled UL94 V-0 4 - 8-24 AWG 0.2-6mm² M3 4 1 - 180° 41A 40.5 A 600 V Tin 0.5-0.6 Nm (4.4-5.3 Lb-In) 12mm - 1 kV
1821750000 Weidmüller 1821750000 -
RFQ
 ECAD 4500 0.00000000 Weidmüller Omnimate BV Bulk Obsolete - Free Hanging (In-Line) Plug, Blade Sockets - Black - Screwless - Spring Cage, Tension Clamp - RoHS Compliant 1 (Unlimited) REACH Unaffected EAR99 8536.69.8000 100 0.300" (7.62mm) Copper Alloy Polybutylene Terephthalate (PBT) UL94 V-0 3 0.787" (19.99mm) 10-22 AWG 0.32-6mm² - 3 1 - 180° 38A 27 A 300 V Tin - 8mm - 500 V
1853200000 Weidmüller 1853200000 -
RFQ
 ECAD 4528 0.00000000 Weidmüller Omnimate BV Bulk Obsolete - Free Hanging (In-Line) Plug, Blade Sockets Latch Lock, Mating Flange Black - Screwless - Spring Cage, Tension Clamp - RoHS Compliant 1 (Unlimited) REACH Unaffected EAR99 8536.69.8000 100 0.300" (7.62mm) Copper Alloy Polybutylene Terephthalate (PBT) UL94 V-0 3 0.787" (19.99mm) 10-22 AWG 0.32-6mm² - 3 1 - 180° 38A 27 A 300 V Tin - 8mm - 500 V
1853220000 Weidmüller 1853220000 -
RFQ
 ECAD 2114 0.00000000 Weidmüller Omnimate BV Bulk Obsolete - Free Hanging (In-Line) Plug, Blade Sockets Latch Lock, Mating Flange Black - Screwless - Spring Cage, Tension Clamp - 1 (Unlimited) REACH Unaffected EAR99 8536.69.8000 50 0.300" (7.62mm) Copper Alloy Polybutylene Terephthalate (PBT) UL94 V-0 5 0.787" (19.99mm) 10-22 AWG 0.32-6mm² - 5 1 - 180° 38A 27 A 300 V Tin - 8mm - 500 V
1821890000 Weidmüller 1821890000 -
RFQ
 ECAD 3380 0.00000000 Weidmüller Omnimate BV Bulk Obsolete - Free Hanging (In-Line) Plug, Blade Sockets Latch Lock, Mating Flange Black - Screwless - Spring Cage, Tension Clamp - RoHS Compliant 1 (Unlimited) REACH Unaffected EAR99 8536.69.8000 50 0.300" (7.62mm) Copper Alloy Polybutylene Terephthalate (PBT) UL94 V-0 6 0.787" (19.99mm) 10-22 AWG 0.32-6mm² - 6 1 - 180° 38A 27 A 300 V Tin - 8mm - 500 V
1983650000 Weidmüller 1983650000 -
RFQ
 ECAD 2835 0.00000000 Weidmüller * Bulk Obsolete - 1 (Unlimited) REACH Unaffected DK4 BE/TS 35 FOR CIRCUIT BOARD OBSOLETE 0000.00.0000 50
1380360000 Weidmüller 1380360000 -
RFQ
 ECAD 5395 0.00000000 Weidmüller * Bulk Obsolete - RoHS Compliant 1 (Unlimited) REACH Unaffected LPK 3/30 OBSOLETE 10
1496960000 Weidmüller 1496960000 -
RFQ
 ECAD 7816 0.00000000 Weidmüller * Bulk Obsolete - RoHS Compliant 1 (Unlimited) REACH Unaffected LPKH FA 3 OBSOLETE 100
1650140000 Weidmüller 1650140000 13.9130
RFQ
 ECAD 1090 0.00000000 Weidmüller * Bulk Active - RoHS Compliant 1 (Unlimited) REACH Unaffected MSV 3 LEFT EAR99 8536.90.4000 50
1815210000 Weidmüller 1815210000 5.1508
RFQ
 ECAD 9023 0.00000000 Weidmüller Z Bulk Active -50°C ~ 120°C Free Hanging (In-Line) Plug, Female Sockets - Beige - Screwless - Spring Cage, Tension Clamp download RoHS Compliant 1 (Unlimited) REACH Unaffected ZP 2.5/1AN/QV3 EAR99 8536.69.8000 25 - - Thermoplastic, Wemid UL94 V-0 3 - 12-26 AWG 0.5-2.5mm² - 3 1 - 180° 24A 5 A 600 V - - 10mm - 690 V
1815230000 Weidmüller 1815230000 7.2912
RFQ
 ECAD 6096 0.00000000 Weidmüller Z Bulk Active -50°C ~ 120°C Free Hanging (In-Line) Plug, Female Sockets - Beige - Screwless - Spring Cage, Tension Clamp download RoHS Compliant 1 (Unlimited) REACH Unaffected ZP 2.5/1AN/QV/5 EAR99 8536.69.8000 25 - - Thermoplastic, Wemid UL94 V-0 5 - 12-26 AWG 0.5-2.5mm² - 5 1 - 180° 24A 5 A 600 V - - 10mm - 690 V
1815260000 Weidmüller 1815260000 10.5115
RFQ
 ECAD 7886 0.00000000 Weidmüller Z Bulk Active -50°C ~ 120°C Free Hanging (In-Line) Plug, Female Sockets - Beige - Screwless - Spring Cage, Tension Clamp download RoHS Compliant 1 (Unlimited) REACH Unaffected ZP 2.5/1AN/QV/8 EAR99 8536.69.8000 20 - - Thermoplastic, Wemid UL94 V-0 8 - 12-26 AWG 0.5-2.5mm² - 8 1 - 180° 24A 5 A 600 V - - 10mm - 690 V
1815750000 Weidmüller 1815750000 -
RFQ
 ECAD 8341 0.00000000 Weidmüller Z Bulk Obsolete -50°C ~ 120°C Free Hanging (In-Line) Plug, Female Sockets - Beige - Screwless - Spring Cage, Tension Clamp download RoHS Compliant 1 (Unlimited) REACH Unaffected EAR99 8536.69.8000 20 - - Thermoplastic, Wemid UL94 V-0 3 (Mate), 6 (Input) - 12-26 AWG 0.5-2.5mm² - 3 (Mate), 6 (Input) 1 (Mate), 2 (Input) - 180° 24A 5 A 600 V - - 10mm - 690 V
1815830000 Weidmüller 1815830000 -
RFQ
 ECAD 7205 0.00000000 Weidmüller Z Bulk Obsolete -50°C ~ 120°C Free Hanging (In-Line) Plug, Female Sockets - Beige - Screwless - Spring Cage, Tension Clamp download RoHS Compliant 1 (Unlimited) REACH Unaffected EAR99 8536.69.8000 10 - - Thermoplastic, Wemid UL94 V-0 11 (Mate), 22 (Input) - 12-26 AWG 0.5-2.5mm² - 11 (Mate), 22 (Input) 1 (Mate), 2 (Input) - 180° 24A 5 A 600 V - - 10mm - 690 V
1854990000 Weidmüller 1854990000 6.7132
RFQ
 ECAD 2584 0.00000000 Weidmüller Z Bulk Active -50°C ~ 120°C Free Hanging (In-Line) Plug, Female Sockets - Beige - Screwless - Spring Cage, Tension Clamp download RoHS Compliant 1 (Unlimited) REACH Unaffected ZP 4/1AN/2 EAR99 8536.69.8000 25 - - Thermoplastic, Wemid UL94 V-0 2 - 10-26 AWG 0.5-4mm² - 2 1 - 180° 32A 28 A 600 V - - 12mm - 800 V
1855040000 Weidmüller 1855040000 -
RFQ
 ECAD 8581 0.00000000 Weidmüller Z Bulk Obsolete -50°C ~ 120°C Free Hanging (In-Line) Plug, Female Sockets - Beige - Screwless - Spring Cage, Tension Clamp download RoHS Compliant 1 (Unlimited) REACH Unaffected EAR99 8536.69.8000 25 - - Thermoplastic, Wemid UL94 V-0 7 - 10-26 AWG 0.5-4mm² - 7 1 - 180° 32A 28 A 600 V - - 12mm - 800 V
1043640000 Weidmüller 1043640000 -
RFQ
 ECAD 8102 0.00000000 Weidmüller Omnimate SL Bulk Obsolete - Free Hanging (In-Line) Plug, Male Pins Mating Flange Orange - Screwless - Leg Spring, Push-In Spring - RoHS Compliant 1 (Unlimited) REACH Unaffected EAR99 8536.69.8000 100 0.300" (7.62mm) - - - 3 0.593" (15.06mm) - - - 3 1 - 180° - - - - -
1043650000 Weidmüller 1043650000 5.1152
RFQ
 ECAD 2419 0.00000000 Weidmüller Omnimate SL Bulk Active - Free Hanging (In-Line) Plug, Male Pins Mating Flange Orange - Screwless - Leg Spring, Push-In Spring - RoHS Compliant 1 (Unlimited) REACH Unaffected SLF 7.62HP/04/180F SN OR BX EAR99 8536.69.8000 42 0.300" (7.62mm) - - - 4 0.593" (15.06mm) - - - 4 1 - 180° - - - - -
1043580000 Weidmüller 1043580000 -
RFQ
 ECAD 7062 0.00000000 Weidmüller Omnimate SL Bulk Obsolete - Free Hanging (In-Line) Plug, Male Pins - Orange - Screwless - Leg Spring, Push-In Spring - RoHS Compliant 1 (Unlimited) REACH Unaffected SLF 7.62HP/05/180G SN OR BX EAR99 8536.69.8000 50 0.300" (7.62mm) - - - 5 0.592" (15.04mm) - - - 5 1 - 180° - - - - -
1846210000 Weidmüller 1846210000 2.0567
RFQ
 ECAD 2876 0.00000000 Weidmüller Omnimate SL Bulk Active -50°C ~ 100°C Free Hanging (In-Line) Plug, Male Pins Mating Flange Orange - Screw - Clamping Yoke (Tension Sleeve) - RoHS Compliant 1 (Unlimited) REACH Unaffected SLS 5.08/02/180FI SN OR BX EAR99 8536.69.8000 90 0.200" (5.08mm) Copper Alloy Polybutylene Terephthalate (PBT), Glass Filled UL94 V-0 2 0.598" (15.19mm) 12-26 AWG 0.2-2.5mm² M2.5 2 1 - 180° 21.5A 14 A 300 V Tin 0.4-0.5 Nm (3.5-4.4 Lb-In) 7mm - 400 V
1846370000 Weidmüller 1846370000 2.6622
RFQ
 ECAD 4586 0.00000000 Weidmüller Omnimate SL Bulk Active -50°C ~ 100°C Free Hanging (In-Line) Plug, Male Pins Mating Flange Orange - Screw - Clamping Yoke (Tension Sleeve) - 1 (Unlimited) REACH Unaffected EAR99 8536.69.8000 72 0.200" (5.08mm) Copper Alloy Polybutylene Terephthalate (PBT), Glass Filled UL94 V-0 3 0.598" (15.19mm) 12-26 AWG 0.2-2.5mm² M2.5 3 1 - 180° 21.5A 14 A 300 V Tin 0.4-0.5 Nm (3.5-4.4 Lb-In) 7mm - 400 V
