In the field of embedded development, both ESP32 and STM32 are highly favored microcontrollers, each with unique features and advantages. When facing project development, how do you choose between them? This requires comprehensive consideration of multiple factors. The following detailed comparison analyzes ESP32 and STM32 from various dimensions to help you make the right decision.
I. Processor Architecture and Performance
(1) ESP32
Power Consumption:
Active state: ~80mA.
Low-power modes: ~5mA in Modem-sleep; ~100μA in deep sleep (with only RTC active).
The ULP coprocessor can operate independently, enabling efficient multitasking and balancing performance with power consumption for applications requiring comprehensive power management.
(2) STM32
Core Types: Ranging from entry-level Cortex-M0/M0+ to mainstream Cortex-M3/M4, high-performance Cortex-M7, and Cortex-M33 with TrustZone security features.
Clock Speed: Ranges from 16MHz to 550MHz (e.g., STM32H7).
Memory: SRAM from several KB to over 1MB; Flash from 16KB to 2MB. Some models support external memory interfaces (FSMC/FMC), and high-end models include Cache.
Power Consumption: Varies by model, with operating current from several mA to over 100mA. Low-power series (e.g., STM32L) are optimized for ultra-low power: ~30μA/MHz in run mode, ~1μA in stop mode, and ~100nA in standby mode.
II. Wireless Connectivity Capability
(1) ESP32
Wi-Fi: Supports 802.11 b/g/n (2.4GHz) with STA/AP/STA+AP modes and WPA/WPA2/WPA3 security.
Bluetooth: Dual-mode (BR/EDR and BLE). ESP32 features Bluetooth 4.2, while ESP32-S3/C3 upgrades to Bluetooth 5.0. Some models (e.g., ESP32-H2) support Thread/Zigbee.
(2) STM32
STM32WB: Supports BLE 5.0.
STM32WL: Supports LoRa.
Overall, STM32 lags behind ESP32 in wireless connectivity convenience.
III. Peripheral Interfaces
(1) ESP32
General Peripherals:
34 GPIOs (some input-only), 12-bit 18-channel ADC, 2-channel 8-bit DAC, 16-channel PWM.
2–3 I2C interfaces, 4 SPI interfaces (2 usable), 3 UARTs (including debug port).
Special Features:
10-channel capacitive touch sensors, Hall sensor, ULP coprocessor.
Some models (e.g., ESP32-S3) include a camera interface and neural network acceleration, enabling advantages in touch control, magnetic field detection, image processing, and simple AI tasks.
(2) STM32
General Peripherals:
GPIOs vary by package (16–100+). ADCs: 12-bit or 16-bit (channel count varies). DACs: 12-bit (1–2 channels). PWM via advanced timers.
Multiple I2C, SPI, UART interfaces; most models have USB (OTG/Host/Device); most include CAN 2.0A/B; some integrate Ethernet (10/100M).
Special Features:True random number generator (TRNG), encryption accelerators (e.g., AES, HASH), graphics accelerators (some models), motor control timers, and high-precision timers (ps-level). These excel in industrial control, security encryption, and motor control requiring real-time performance, precision, and safety.
IV. Development Ecosystem and Toolchain
(1) ESP32
Software Support:
Official framework: ESP-IDF (based on FreeRTOS). Compatible with Arduino IDE, MicroPython, and JavaScript (LVGL).
Toolchain: GCC-based, cross-platform. Debugging: JTAG/SWD.
Community & Resources:
Abundant Chinese documentation, active open-source communities (e.g., GitHub, forums), and numerous third-party libraries/projects. Ideal for quick prototyping.
Cost:
Development boards: ~20–100 CNY. No dedicated debugger needed. Open-source toolchain. Modules: ~20–50 CNY, suitable for cost-sensitive projects.
(2) STM32
Software Support:
Official tools: STM32CubeIDE/STM32CubeMX. Supports RTOS (FreeRTOS, ThreadX), Arduino, and Mbed.
Toolchains: Keil, IAR, GCC. Debugging: SWD/JTAG with a mature ecosystem.
Community & Resources:
Widely used globally, with comprehensive documentation and professional technical support. Manufacturers offer long-term supply commitments (10+ years) and training systems, critical for large projects.
Cost:
Development boards: ~50–300 CNY. Recommended to use ST-Link debugger. Some professional tools require licensing. Chips: ~5–100+ CNY.
V. Performance Benchmark Comparison
| Metric | ESP32-WROOM-32 | STM32F407VG | STM32H743VI | ESP32-S3 |
|---|---|---|---|---|
| CoreMark/MHz | 3.55 | 3.4 | 4.4 | 4.1 |
| DMIPS/MHz | 1.15 | 1.25 | 2.14 | 1.3 |
| Floating-point Performance | Single-precision | Single-precision | Double-precision | Single-precision |
| Neural Network Performance | None | None | None | ~50 GOPS |
Different models excel in various metrics. Choose based on project requirements, such as intensive floating-point calculations or neural network tasks.
VI. Typical Application Scenarios
(1) ESP32
IoT End Devices: Ideal for smart home devices (e.g., smart bulbs, sockets, locks) requiring Wi-Fi/Bluetooth for cloud or APP connectivity.
Wireless Sensor Networks: Low-power design suits battery-powered remote monitoring nodes (e.g., environmental humidity/temperature sensors, soil moisture detectors).
Rapid Prototyping: Rich resources, easy development, and low cost make it perfect for student projects and maker products.
Audio Processing: Performs well in voice recognition and audio streaming (e.g., smart speakers).
Low-Cost Solutions: Cost-effective for mass-produced consumer electronics.
(2) STM32
Industrial Control Systems:
Motor drive control: High-resolution PWM from advanced timers enables precise stepper/servo motor control.
CAN bus: Widely used in automotive electronics and PLC systems (e.g., factory automation line communication).
Automotive Electronics: Participates in critical vehicle systems (e.g., ABS, infotainment) with stable performance and rich peripherals.
Medical Devices: Enables data acquisition and processing for devices like ECG monitors and blood glucose meters, leveraging high-precision ADCs and reliable real-time performance.
Aerospace: Used in flight control and avionics systems requiring extreme reliability and real-time performance.
ESP32 vs. STM32: Equivalents/Alternatives
| ESP32 | STM32 |
|---|---|
| - Raspberry Pi Pico - STM32 Series - Arduino Nano - Teensy - nRF5xxxx - Other ESP versions | - GD32 Series (GigaDevice) - Nuvoton (NuMicro) Series - Microchip PIC32 Series - Silicon Labs EFM32 Series - Texas Instruments MSP430 Series |
ESP32 vs. STM32: Comparison of Advantages and Disadvantages
| Features | ESP32 | STM32 |
| Advantages | ||
| Applicable Fields | Outstanding output in industrial domains and elevated dependability | Outstanding output in industrial domains andelevated dependability |
| Cost Advantage | Reasonably priced overall development costs combined with strong performance | Growing costs of pricing |
| Arduino Environment Support | less difficult to program, robust open-source community | Slightly challenging to begin with, high learning curve |
| Built-in Bluetooth and Wi-Fi | Bluetooth and Wi-Fi integration lowers the cost of extra modules | - |
| Dual-core Processor | Allows for real-time multi-threaded processing | - |
| High-speed Main Frequency | Higher processing speed and computing power up to 240MHz | - |
| Pure Hardware Debugging | very simple hardware debugging, which makes development easier | Higher hardware debugging costs despite a simpler debugging toolchain |
| Disadvantages | ||
| Limited Number of Pins | comparatively few pins, making it less appropriate for projects requiring a large number of IO ports | - |
| Complex Debugging Tool Chain | intricate toolchain that necessitates a thorough understanding of compilation procedures and command-line tools | - |
| Slow Compilation Process | slower compilation speed than some other options | Effective compilation, but costs are increasing |
| Debugging Complexity | somewhat difficult debugging and software breakpoint restrictions | Simpler debugging toolchain, but more expensive hardware debugging |
| Reasonably priced overall development costs combined with strong performance | - | Effective burning and compiling |
Conclusion: How to Choose?
Choose ESP32 if:
Your project requires built-in Wi-Fi/Bluetooth for IoT or smart home applications.
You prioritize low development costs and rapid prototyping.
You need simple AI or audio processing capabilities.
Choose STM32 if:
Your project demands high-reliability industrial control, automotive, or medical applications.
You require complex peripherals (CAN, USB, Ethernet) or high-precision real-time control.
You need long-term technical support and mass production with strict certification standards.
Ultimately, the best choice depends on your project’s specific requirements, technical constraints, and budget. Both microcontrollers offer robust solutions—ESP32 for connectivity and cost efficiency, and STM32 for performance and versatility in complex systems.
