Discrete Semiconductor Products(27586)

Image Product Number Pricing(USD) Quantity ECAD Quantity Available Weight(Kg) Mfr Series Package Product Status Tolerance Operating Temperature Mounting Type Package / Case Type Base Product Number Input Type Technology Power - Max Input Supplier Device Package DataSheet RoHS Status Moisture Sensitivity Level (MSL) REACH Status Other Names ECCN HTSUS Standard Package Configuration Speed FET Type Test Condition Current Voltage Voltage - Isolation Drain to Source Voltage (Vdss) Current - Continuous Drain (Id) @ 25°C Drive Voltage (Max Rds On, Min Rds On) Rds On (Max) @ Id, Vgs Vgs(th) (Max) @ Id Gate Charge (Qg) (Max) @ Vgs Vgs (Max) Input Capacitance (Ciss) (Max) @ Vds FET Feature Power Dissipation (Max) Voltage - DC Reverse (Vr) (Max) Voltage - Forward (Vf) (Max) @ If Reverse Recovery Time (trr) Current - Reverse Leakage @ Vr Operating Temperature - Junction Current - Average Rectified (Io) Capacitance @ Vr, F IGBT Type Voltage - Collector Emitter Breakdown (Max) Current - Collector (Ic) (Max) Current - Collector Pulsed (Icm) Vce(on) (Max) @ Vge, Ic Switching Energy Gate Charge Td (on/off) @ 25°C Current - Collector Cutoff (Max) NTC Thermistor Voltage - Zener (Nom) (Vz) Impedance (Max) (Zzt) Input Capacitance (Cies) @ Vce
NTHL160N120SC1 onsemi NTHL160N120SC1 9.6900
RFQ
 ECAD 118 0.00000000 onsemi - Tube Active -55°C ~ 175°C (TJ) Through Hole TO-247-3 NTHL160 SiCFET (Silicon Carbide) TO-247-3 download ROHS3 Compliant Not Applicable REACH Unaffected 488-NTHL160N120SC1 EAR99 8541.29.0095 30 N-Channel 1200 V 17A (Tc) 20V 224mOhm @ 12A, 20V 4.3V @ 2.5mA 34 nC @ 20 V +25V, -15V 665 pF @ 800 V - 119W (Tc)
NVBGS4D1N15MC onsemi NVBGS4D1N15MC 18.2500
RFQ
 ECAD 394 0.00000000 onsemi Automotive, AEC-Q101 Tape & Reel (TR) Last Time Buy -55°C ~ 175°C (TJ) Surface Mount TO-263-7, D²Pak (6 Leads + Tab) NVBGS4 MOSFET (Metal Oxide) D2PAK (TO-263) download ROHS3 Compliant 1 (Unlimited) REACH Unaffected EAR99 8541.29.0095 800 N-Channel 150 V 20A (Ta), 185A (Tc) 8V, 10V 4.1mOhm @ 104A, 10V 4.5V @ 574µA 88.9 nC @ 10 V ±20V 7285 pF @ 75 V - 3.7W (Ta), 316W (Tc)
NTTFS2D1N04HLTWG onsemi NTTFS2D1N04HLTWG 2.1800
RFQ
 ECAD 2 0.00000000 onsemi - Tape & Reel (TR) Active -55°C ~ 150°C (TJ) Surface Mount 8-PowerWDFN NTTFS2 MOSFET (Metal Oxide) 8-PQFN (3.3x3.3) download ROHS3 Compliant 1 (Unlimited) REACH Unaffected EAR99 8541.29.0095 3,000 N-Channel 40 V 24A (Ta), 150A (Tc) 4.5V, 10V 2.1mOhm @ 23A, 10V 2V @ 120µA 43.6 nC @ 10 V ±20V 2745 pF @ 20 V - 2.2W (Ta), 83W (Tc)
AFGHL50T65SQ onsemi AFGHL50T65SQ 4.5800
RFQ
 ECAD 8794 0.00000000 onsemi Automotive, AEC-Q101 Tube Active -55°C ~ 175°C (TJ) Through Hole TO-247-3 AFGHL50 Standard 268 W TO-247-3 download ROHS3 Compliant Not Applicable REACH Unaffected 488-AFGHL50T65SQ EAR99 8541.29.0095 30 400V, 50A, 4.7Ohm, 15V Trench Field Stop 650 V 80 A 200 A 2.1V @ 15V, 50A 950µJ (on), 460µJ (off) 99 nC 20ns/81ns
FSB50450BL onsemi FSB50450BL 7.8200
RFQ
 ECAD 269 0.00000000 onsemi Motion SPM® 5 Tube Obsolete Through Hole 23-PowerDIP Module (0.551", 14.00mm) MOSFET FSB50450 download ROHS3 Compliant Not Applicable REACH Unaffected 488-FSB50450BL EAR99 8542.39.0001 15 3 Phase Inverter 2.2 A 500 V 1500Vrms
AFGHL50T65SQD onsemi AFGHL50T65SQD 5.8500
RFQ
 ECAD 6109 0.00000000 onsemi Automotive, AEC-Q101 Tube Active -55°C ~ 175°C (TJ) Through Hole TO-247-3 AFGHL50 Standard 268 W TO-247-3 download ROHS3 Compliant Not Applicable REACH Unaffected 488-AFGHL50T65SQD EAR99 8541.29.0095 30 400V, 50A, 4.7Ohm, 15V Trench Field Stop 650 V 80 A 200 A 2.1V @ 15V, 50A 950µJ (on), 460µJ (off) 102 nC 20ns/81ns
FSB50450BSL onsemi FSB50450BSL -
RFQ
 ECAD 8759 0.00000000 onsemi Motion SPM® 5 Tape & Reel (TR) Obsolete Surface Mount 23-PowerSMD Module, Gull Wing MOSFET FSB50450 download ROHS3 Compliant 3 (168 Hours) REACH Unaffected EAR99 8542.39.0001 450 3 Phase Inverter 2.2 A 500 V 1500Vrms
NFAQ1060L36T onsemi NFAQ1060L36T 15.6300
RFQ
 ECAD 6683 0.00000000 onsemi - Tube Active Through Hole 38-PowerDIP Module (0.610", 24.00mm), 24 Leads IGBT NFAQ1060 download ROHS3 Compliant Not Applicable REACH Unaffected 488-NFAQ1060L36T EAR99 8542.39.0001 400 3 Phase Inverter 10 A 600 V 2000Vrms
NVH4L020N120SC1 onsemi NVH4L020N120SC1 52.5100
RFQ
 ECAD 643 0.00000000 onsemi Automotive, AEC-Q101 Tube Active -55°C ~ 175°C (TJ) Through Hole TO-247-4 NVH4L020 SiCFET (Silicon Carbide) TO-247-4L download ROHS3 Compliant Not Applicable REACH Unaffected 488-NVH4L020N120SC1 EAR99 8541.29.0095 30 N-Channel 1200 V 102A (Tc) 20V 28mOhm @ 60A, 20V 4.3V @ 20mA 220 nC @ 20 V +25V, -15V 2943 pF @ 800 V - 510W (Tc)
NTBGS6D5N15MC onsemi NTBGS6D5N15MC 6.2700
RFQ
 ECAD 12 0.00000000 onsemi - Tape & Reel (TR) Active -55°C ~ 175°C (TJ) Surface Mount TO-263-7, D²Pak (6 Leads + Tab) NTBGS6 MOSFET (Metal Oxide) D2PAK (TO-263) download ROHS3 Compliant 1 (Unlimited) REACH Unaffected EAR99 8541.29.0095 800 N-Channel 150 V 15A (Ta), 121A (Tc) 8V, 10V 7mOhm @ 69A, 10V 4.5V @ 379µA 57 nC @ 10 V ±20V 4745 pF @ 75 V - 3.7W (Ta), 238W (Tc)
NVBG040N120SC1 onsemi NVBG040N120SC1 33.1400
RFQ
 ECAD 8695 0.00000000 onsemi Automotive, AEC-Q101 Tape & Reel (TR) Active -55°C ~ 175°C (TJ) Surface Mount TO-263-8, D²Pak (7 Leads + Tab), TO-263CA NVBG040 SiCFET (Silicon Carbide) D2PAK-7 download ROHS3 Compliant 1 (Unlimited) REACH Unaffected EAR99 8541.29.0095 800 N-Channel 1200 V 60A (Tc) 20V 56mOhm @ 35A, 20V 4.3V @ 10mA 106 nC @ 20 V +25V, -15V 1789 pF @ 800 V - 357W (Tc)
NXH35C120L2C2SG onsemi NXH35C120L2C2SG 106.6000
RFQ
 ECAD 17 0.00000000 onsemi - Tube Active -40°C ~ 150°C (TJ) Through Hole 26-PowerDIP Module (1.199", 47.20mm) NXH35 20 mW Three Phase Bridge Rectifier 26-DIP download ROHS3 Compliant Not Applicable REACH Unaffected EAR99 8541.29.0095 6 Three Phase Inverter with Brake - 1200 V 35 A 2.4V @ 15V, 35A 250 µA Yes 8.33 nF @ 20 V
NVH4L160N120SC1 onsemi NVH4L160N120SC1 12.6800
RFQ
 ECAD 438 0.00000000 onsemi Automotive, AEC-Q101 Tube Active -55°C ~ 175°C (TJ) Through Hole TO-247-4 NVH4L160 SiCFET (Silicon Carbide) TO-247-4L download ROHS3 Compliant Not Applicable REACH Unaffected 488-NVH4L160N120SC1 EAR99 8541.29.0095 34 N-Channel 1200 V 17.3A (Tc) 20V 224mOhm @ 12A, 20V 4.3V @ 2.5mA 34 nC @ 20 V +25V, -15V 665 pF @ 800 V - 111W (Tc)
SMMUN2215LT1G-M01 onsemi SMMUN2215LT1G-M01 -
RFQ
 ECAD 7816 0.00000000 onsemi - Tape & Reel (TR) Obsolete SMMUN2215 - ROHS3 Compliant 1 (Unlimited) REACH Unaffected 488-SMMUN2215LT1G-M01TR OBSOLETE 3,000
BASH20LT1G onsemi BASH20LT1G 0.0270
RFQ
 ECAD 2308 0.00000000 onsemi - Tape & Reel (TR) Active Surface Mount TO-236-3, SC-59, SOT-23-3 BASH20 Standard SOT-23-3 (TO-236) - ROHS3 Compliant 1 (Unlimited) REACH Unaffected 488-BASH20LT1GTR EAR99 8541.10.0070 3,000 Fast Recovery =< 500ns, > 200mA (Io) 200 V 1.25 V @ 200 mA 50 ns 100 nA @ 150 V -55°C ~ 175°C 200mA 5pF @ 0V, 1MHz
SZMM5Z4687T1G onsemi SZMM5Z4687T1G 0.0574
RFQ
 ECAD 3760 0.00000000 onsemi Automotive, AEC-Q101 Tape & Reel (TR) Active ±5% -55°C ~ 150°C (TJ) Surface Mount SC-79, SOD-523 SZMM5 500 mW SOD-523 - ROHS3 Compliant 1 (Unlimited) REACH Unaffected 488-SZMM5Z4687T1GTR EAR99 8541.10.0050 3,000 900 mV @ 10 mA 4 µA @ 2 V 4.3 V
SBRD8360T4G onsemi SBRD8360T4G -
RFQ
 ECAD 2494 0.00000000 onsemi - Tape & Reel (TR) Obsolete Surface Mount TO-252-3, DPak (2 Leads + Tab), SC-63 SBRD8360 Schottky DPAK - ROHS3 Compliant 1 (Unlimited) REACH Unaffected 488-SBRD8360T4GTR EAR99 8541.10.0080 2,500 Fast Recovery =< 500ns, > 200mA (Io) 60 V 600 mV @ 3 A 200 µA @ 60 V -65°C ~ 175°C 3A -
FGD2736G3-F085V onsemi FGD2736G3-F085V -
RFQ
 ECAD 2732 0.00000000 onsemi Automotive, AEC-Q101, EcoSPARK® Tape & Reel (TR) Obsolete -40°C ~ 175°C (TJ) Surface Mount TO-252-3, DPak (2 Leads + Tab), SC-63 FGD2736 Standard 150 W DPAK - ROHS3 Compliant 1 (Unlimited) REACH Unaffected 488-FGD2736G3-F085VTR EAR99 8541.29.0095 2,500 300V, 6.5A, 470Ohm, 5V 3 µs - 360 V 37.5 A 1.65V @ 4.5V, 10A - 18 nC 900ns/4.4µs
PCFFS50120AF onsemi PCFFS50120AF 23.9400
RFQ
 ECAD 1019 0.00000000 onsemi - Tray Active Surface Mount Die PCFFS50120 SiC (Silicon Carbide) Schottky Die - ROHS3 Compliant Not Applicable REACH Unaffected 488-PCFFS50120AF EAR99 8541.10.0080 1 No Recovery Time > 500mA (Io) 1200 V 1.75 V @ 50 A 0 ns 200 µA @ 1200 V 175°C (Max) 50A -
NRVBS310FA onsemi NRVBS310FA 0.7200
RFQ
 ECAD 587 0.00000000 onsemi Automotive, AEC-Q101 Tape & Reel (TR) Active Surface Mount SOD-123F NRVBS310 Schottky SOD-123FL download ROHS3 Compliant 1 (Unlimited) REACH Unaffected EAR99 8541.10.0080 3,000 Fast Recovery =< 500ns, > 200mA (Io) 100 V 850 mV @ 3 A 8 ns 100 µA @ 100 V -55°C ~ 150°C 3A 78pF @ 4V, 1MHz
SURHD8560W1T4G onsemi SURHD8560W1T4G -
RFQ
 ECAD 4920 0.00000000 onsemi Automotive, AEC-Q101 Tape & Reel (TR) Obsolete Surface Mount TO-252-3, DPak (2 Leads + Tab), SC-63 SURHD8560 Standard DPAK - ROHS3 Compliant 1 (Unlimited) REACH Unaffected EAR99 8541.10.0080 2,500 Fast Recovery =< 500ns, > 200mA (Io) 600 V 2.7 V @ 5 A 30 ns 10 µA @ 600 V -65°C ~ 175°C 5A -
MMSZ56T3G onsemi MMSZ56T3G 0.0353
RFQ
 ECAD 1895 0.00000000 onsemi Automotive, AEC-Q101 Tape & Reel (TR) Active ±5% -55°C ~ 150°C (TJ) Surface Mount SOD-123 MMSZ56 500 mW SOD-123 - ROHS3 Compliant 1 (Unlimited) REACH Unaffected 488-MMSZ56T3GTR EAR99 8541.10.0050 10,000 900 mV @ 10 mA 50 nA @ 39.2 V 56 V 200 Ohms
NVD6415ANT4G-VF01 onsemi NVD6415ANT4G-VF01 -
RFQ
 ECAD 5738 0.00000000 onsemi Automotive, AEC-Q101 Tape & Reel (TR) Obsolete -55°C ~ 175°C (TJ) Surface Mount TO-252-3, DPak (2 Leads + Tab), SC-63 NVD6415 MOSFET (Metal Oxide) DPAK-3 - ROHS3 Compliant 1 (Unlimited) REACH Unaffected 488-NVD6415ANT4G-VF01TR EAR99 8541.29.0095 2,500 N-Channel 100 V 23A (Tc) 10V 55mOhm @ 23A, 10V 4V @ 250µA 29 nC @ 10 V ±20V 700 pF @ 25 V - 83W (Tc)
NVMFS6H852NLT1G onsemi NVMFS6H852NLT1G 0.9700
RFQ
 ECAD 2934 0.00000000 onsemi Automotive, AEC-Q101 Tape & Reel (TR) Active -55°C ~ 175°C (TJ) Surface Mount 8-PowerTDFN, 5 Leads NVMFS6 MOSFET (Metal Oxide) 5-DFN (5x6) (8-SOFL) download ROHS3 Compliant 1 (Unlimited) REACH Unaffected EAR99 8541.29.0095 1,500 N-Channel 80 V 11A (Ta), 42A (Tc) 4.5V, 10V 13.1mOhm @ 10A, 10V 2V @ 45µA 17 nC @ 10 V ±20V 906 pF @ 40 V - 3.6W (Ta), 54W (Tc)
FSB50825TB2 onsemi FSB50825TB2 -
RFQ
 ECAD 4169 0.00000000 onsemi SPM® Tube Obsolete Through Hole 23-PowerDIP Module (0.748", 19.00mm) IGBT FSB50825 - ROHS3 Compliant Not Applicable REACH Unaffected 488-FSB50825TB2 EAR99 8542.39.0001 180 3 Phase 4 A 250 V 1500Vrms
PCFA86210F onsemi PCFA86210F -
RFQ
 ECAD 5586 0.00000000 onsemi - Tray Active PCFA86210 - ROHS3 Compliant Not Applicable REACH Unaffected 488-PCFA86210F 1
PCFFS3065AF onsemi PCFFS3065AF -
RFQ
 ECAD 7520 0.00000000 onsemi - Tray Last Time Buy Surface Mount Die PCFFS3065 SiC (Silicon Carbide) Schottky Die - ROHS3 Compliant Not Applicable REACH Unaffected 488-PCFFS3065AF EAR99 8541.10.0080 1 No Recovery Time > 500mA (Io) 650 V 1.75 V @ 30 A 0 ns 200 µA @ 650 V 175°C (Max) 30A -
NTBLS002N08MC onsemi NTBLS002N08MC 4.1293
RFQ
 ECAD 7335 0.00000000 onsemi - Tape & Reel (TR) Active -55°C ~ 150°C (TJ) Surface Mount 8-PowerSFN NTBLS002 MOSFET (Metal Oxide) 8-HPSOF - ROHS3 Compliant 1 (Unlimited) REACH Unaffected 488-NTBLS002N08MCTR EAR99 8541.29.0095 2,000 N-Channel 80 V 28A (Ta), 238A (Tc) 6V, 10V 2mOhm @ 80A, 10V 4V @ 530µA 92 nC @ 10 V ±20V 6580 pF @ 40 V - 2.9W (Ta), 208W (Tc)
NRVBA210LNT3G onsemi NRVBA210LNT3G 0.5400
RFQ
 ECAD 9560 0.00000000 onsemi Automotive, AEC-Q101 Tape & Reel (TR) Active Surface Mount DO-214AC, SMA NRVBA210 Schottky SMA - ROHS3 Compliant 1 (Unlimited) REACH Unaffected EAR99 8541.10.0080 5,000 Fast Recovery =< 500ns, > 200mA (Io) 10 V 350 mV @ 2 A 700 µA @ 10 V -55°C ~ 125°C 2A -
PCFFS4065AF onsemi PCFFS4065AF 11.3100
RFQ
 ECAD 1 0.00000000 onsemi - Tray Last Time Buy Surface Mount Die PCFFS4065 SiC (Silicon Carbide) Schottky Die - ROHS3 Compliant Not Applicable REACH Unaffected 488-PCFFS4065AF EAR99 8541.10.0080 112 No Recovery Time > 500mA (Io) 650 V 1.75 V @ 40 A 0 ns 200 µA @ 650 V -55°C ~ 175°C 40A 1989pf @ 1V, 100kHz
