Transistors(427)
| Image | Product Number | Pricing(USD) | Quantity | ECAD | Quantity Available | Weight(Kg) | Mfr | Series | Package | Product Status | Operating Temperature | Mounting Type | Package / Case | Base Product Number | Technology | Power - Max | Supplier Device Package | DataSheet | RoHS Status | Moisture Sensitivity Level (MSL) | REACH Status | Other Names | ECCN | HTSUS | Standard Package | Configuration | FET Type | Drain to Source Voltage (Vdss) | Current - Continuous Drain (Id) @ 25°C | Drive Voltage (Max Rds On, Min Rds On) | Rds On (Max) @ Id, Vgs | Vgs(th) (Max) @ Id | Gate Charge (Qg) (Max) @ Vgs | Vgs (Max) | Input Capacitance (Ciss) (Max) @ Vds | FET Feature | Power Dissipation (Max) | Voltage - Collector Emitter Breakdown (Max) | Current - Collector (Ic) (Max) | Current - Collector Cutoff (Max) | Transistor Type | Vce Saturation (Max) @ Ib, Ic | DC Current Gain (hFE) (Min) @ Ic, Vce | Frequency - Transition |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
CSD17507Q5AT | 0.6216 |  |
5366 | 0.00000000 | Texas Instruments | NexFET™ | Tape & Reel (TR) | Not For New Designs | -55°C ~ 150°C (TJ) | Surface Mount | 8-PowerTDFN | CSD17507 | MOSFET (Metal Oxide) | 8-VSONP (5x6) | - | Not applicable | 1 (Unlimited) | 296-CSD17507Q5ATTR | EAR99 | 8541.29.0095 | 250 | N-Channel | 30 V | 13A (Ta), 65A (Tc) | 4.5V, 10V | 10.8mOhm @ 11A, 10V | 2.1V @ 250µA | 3.6 nC @ 4.5 V | ±20V | 530 pF @ 15 V | - | 3W (Ta) | |||||||||||
 |
CSD18563Q5A-P | - | |
1961 | 0.00000000 | Texas Instruments | NexFET™ | Tape & Reel (TR) | Active | -55°C ~ 150°C (TJ) | Surface Mount | 8-PowerTDFN | CSD18563 | MOSFET (Metal Oxide) | 8-VSON (5x6) | - | ROHS3 Compliant | 1 (Unlimited) | 296-CSD18563Q5A-PTR | EAR99 | 8541.29.0095 | 1 | N-Channel | 60 V | 15A (Ta), 93A (Tc) | 4.5V, 10V | 6.8mOhm @ 18A, 10V | 2.4V @ 250µA | 20 nC @ 10 V | ±20V | 1500 pF @ 30 V | - | 3.2W (Ta), 116W (Tc) | |||||||||||
|
CSD16411Q3T | - | |
1656 | 0.00000000 | Texas Instruments | NexFET™ | Bulk | Active | -55°C ~ 150°C (TJ) | Surface Mount | 8-PowerTDFN | CSD16411 | MOSFET (Metal Oxide) | 8-VSON-CLIP (3.3x3.3) | download | ROHS3 Compliant | 1 (Unlimited) | 296-CSD16411Q3T | EAR99 | 8541.29.0095 | 1 | N-Channel | 25 V | 50A (Tc) | 4.5V, 10V | 10mOhm @ 10A, 10V | 2.3V @ 250µA | 3.8 nC @ 4.5 V | +16V, -12V | 570 pF @ 12.5 V | - | 35W (Tc) | |||||||||||
|
SN75468N-A | - | |
2192 | 0.00000000 | Texas Instruments | SN7546x | Bulk | Active | 0°C ~ 70°C (TA) | Through Hole | 16-DIP (0.300", 7.62mm) | SN75468 | - | 16-PDIP | - | ROHS3 Compliant | 296-SN75468N-A | 1 | 100V | 500mA | - | - | 1.6V @ 500µA, 350mA | - | - | ||||||||||||||||||
 |
CSD86330Q3D | 2.1100 | |
23 | 0.00000000 | Texas Instruments | NexFET™ | Tape & Reel (TR) | Active | -55°C ~ 150°C (TJ) | Surface Mount | 8-PowerLDFN | CSD86330Q3 | MOSFET (Metal Oxide) | 6W | 8-LSON (3.3x3.3) | download | ROHS3 Compliant | 1 (Unlimited) | REACH Affected | EAR99 | 8541.29.0095 | 2,500 | 2 N-Channel (Half Bridge) | 25V | 20A | 9.6mOhm @ 14A, 8V | 2.1V @ 250µA | 6.2nC @ 4.5V | 920pF @ 12.5V | Logic Level Gate | |||||||||||||
|
CSD17506Q5A | 1.6900 | |
1 | 0.00000000 | Texas Instruments | NexFET™ | Tape & Reel (TR) | Active | -55°C ~ 150°C (TJ) | Surface Mount | 8-PowerTDFN | CSD17506 | MOSFET (Metal Oxide) | 8-VSONP (5x6) | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8541.29.0095 | 2,500 | N-Channel | 30 V | 100A (Tc) | 4.5V, 10V | 4mOhm @ 20A, 10V | 1.8V @ 250µA | 11 nC @ 4.5 V | ±20V | 1650 pF @ 15 V | - | 3.2W (Ta) | |||||||||||
|
CSD17553Q5A | 1.5300 | |
9 | 0.00000000 | Texas Instruments | NexFET™ | Tape & Reel (TR) | Active | -55°C ~ 150°C (TJ) | Surface Mount | 8-PowerTDFN | CSD17553 | MOSFET (Metal Oxide) | 8-VSONP (5x6) | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8541.29.0095 | 2,500 | N-Channel | 30 V | 23.5A (Ta), 100A (Tc) | 4.5V, 10V | 3.1mOhm @ 20A, 10V | 1.9V @ 250µA | 21.5 nC @ 4.5 V | ±20V | 3252 pF @ 15 V | - | 3.1W (Ta) | |||||||||||
 |
CSD13306WT | 1.0900 | |
930 | 0.00000000 | Texas Instruments | NexFET™ | Tape & Reel (TR) | Active | -55°C ~ 150°C (TJ) | Surface Mount | 6-UFBGA, DSBGA | CSD13306 | MOSFET (Metal Oxide) | 6-DSBGA (1x1.5) | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8541.29.0095 | 250 | N-Channel | 12 V | 3.5A (Ta) | 2.5V, 4.5V | 10.2mOhm @ 1.5A, 4.5V | 1.3V @ 250µA | 11.2 nC @ 4.5 V | ±10V | 1370 pF @ 6 V | - | 1.9W (Ta) | |||||||||||
 |
CSD85301Q2T | 1.1300 | |
6130 | 0.00000000 | Texas Instruments | NexFET™ | Tape & Reel (TR) | Active | -55°C ~ 150°C (TJ) | Surface Mount | 6-WDFN Exposed Pad | CSD85301 | MOSFET (Metal Oxide) | 2.3W | 6-WSON (2x2) | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8541.29.0095 | 250 | 2 N-Channel (Dual) | 20V | 5A | 27mOhm @ 5A, 4.5V | 1.2V @ 250µA | 5.4nC @ 4.5V | 469pF @ 10V | Logic Level Gate, 5V Drive | |||||||||||||
|
CSD13306W | 0.5400 | |
3 | 0.00000000 | Texas Instruments | NexFET™ | Tape & Reel (TR) | Active | -55°C ~ 150°C (TJ) | Surface Mount | 6-UFBGA, DSBGA | CSD13306 | MOSFET (Metal Oxide) | 6-DSBGA (1x1.5) | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8541.29.0095 | 3,000 | N-Channel | 12 V | 3.5A (Ta) | 2.5V, 4.5V | 10.2mOhm @ 1.5A, 4.5V | 1.3V @ 250µA | 11.2 nC @ 4.5 V | ±10V | 1370 pF @ 6 V | - | 1.9W (Ta) | |||||||||||
|
CSD18531Q5AT | 2.0600 | |
250 | 0.00000000 | Texas Instruments | NexFET™ | Tape & Reel (TR) | Active | -55°C ~ 150°C (TJ) | Surface Mount | 8-PowerTDFN | CSD18531 | MOSFET (Metal Oxide) | 8-VSONP (5x6) | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8541.29.0095 | 250 | N-Channel | 60 V | 100A (Ta) | 4.5V, 10V | 4.6mOhm @ 22A, 10V | 2.3V @ 250µA | 43 nC @ 10 V | ±20V | 3840 pF @ 30 V | - | 3.1W (Ta), 156W (Tc) | |||||||||||
 |
CSD18536KCS | 4.7600 | |
478 | 0.00000000 | Texas Instruments | NexFET™ | Tube | Active | -55°C ~ 175°C (TJ) | Through Hole | TO-220-3 | CSD18536 | MOSFET (Metal Oxide) | TO-220-3 | download | ROHS3 Compliant | 1 (Unlimited) | REACH Affected | EAR99 | 8541.29.0095 | 50 | N-Channel | 60 V | 200A (Ta) | 4.5V, 10V | 1.6mOhm @ 100A, 10V | 2.2V @ 250µA | 108 nC @ 10 V | ±20V | 11430 pF @ 30 V | - | 375W (Tc) | |||||||||||
|
CSD18509Q5B | 2.4900 | |
2 | 0.00000000 | Texas Instruments | NexFET™ | Tape & Reel (TR) | Active | -55°C ~ 150°C (TJ) | Surface Mount | 8-PowerTDFN | CSD18509 | MOSFET (Metal Oxide) | 8-VSON-CLIP (5x6) | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8541.29.0095 | 2,500 | N-Channel | 40 V | 100A (Ta) | 4.5V, 10V | 1.2mOhm @ 32A, 10V | 2.2V @ 250µA | 195 nC @ 10 V | ±20V | 13900 pF @ 20 V | - | 3.1W (Ta), 195W (Tc) | |||||||||||
 |
CSD13302WT | 0.9700 | |
965 | 0.00000000 | Texas Instruments | NexFET™ | Tape & Reel (TR) | Active | -55°C ~ 150°C (TJ) | Surface Mount | 4-UFBGA, DSBGA | CSD13302 | MOSFET (Metal Oxide) | 4-DSBGA (1x1) | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8541.29.0095 | 250 | N-Channel | 12 V | 1.6A (Ta) | 2.5V, 4.5V | 17.1mOhm @ 1A, 4.5V | 1.3V @ 250µA | 7.8 nC @ 4.5 V | ±10V | 862 pF @ 6 V | - | 1.8W (Ta) | |||||||||||
 |
CSD16340Q3T | 1.4300 | |
2 | 0.00000000 | Texas Instruments | NexFET™ | Tape & Reel (TR) | Active | -55°C ~ 150°C (TJ) | Surface Mount | 8-PowerTDFN | CSD16340 | MOSFET (Metal Oxide) | 8-VSON-CLIP (3.3x3.3) | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8541.29.0095 | 250 | N-Channel | 25 V | 60A (Tc) | 2.5V, 8V | 4.5mOhm @ 20A, 8V | 1.1V @ 250µA | 9.2 nC @ 4.5 V | +10V, -8V | 1350 pF @ 12.5 V | - | 3W (Ta) | |||||||||||
|
CSD17559Q5T | 3.1800 | |
396 | 0.00000000 | Texas Instruments | NexFET™ | Tape & Reel (TR) | Active | -55°C ~ 150°C (TJ) | Surface Mount | 8-PowerTDFN | CSD17559 | MOSFET (Metal Oxide) | 8-VSON-CLIP (5x6) | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8541.29.0095 | 250 | N-Channel | 30 V | 100A (Ta) | 4.5V, 10V | 1.15mOhm @ 40A, 10V | 1.7V @ 250µA | 51 nC @ 4.5 V | ±20V | 9200 pF @ 15 V | - | 3.2W (Ta), 96W (Tc) | |||||||||||
|
CSD18502Q5BT | 2.7900 | |
341 | 0.00000000 | Texas Instruments | NexFET™ | Tape & Reel (TR) | Active | -55°C ~ 150°C (TJ) | Surface Mount | 8-PowerTDFN | CSD18502 | MOSFET (Metal Oxide) | 8-VSON-CLIP (5x6) | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8541.29.0095 | 250 | N-Channel | 40 V | 100A (Ta) | 4.5V, 10V | 2.3mOhm @ 30A, 10V | 2.2V @ 250µA | 33 nC @ 4.5 V | ±20V | 5070 pF @ 20 V | - | 3.2W (Ta), 156W (Tc) | |||||||||||
 |
CPH3448-TL-W | - | |
4744 | 0.00000000 | Texas Instruments | - | Bulk | Active | 150°C (TJ) | Surface Mount | SC-96 | MOSFET (Metal Oxide) | 3-CPH | download | 0000.00.0000 | 1 | N-Channel | 30 V | 4A (Ta) | 1.8V, 4.5V | 50mOhm @ 2A, 4.5V | - | 4.7 nC @ 4.5 V | ±12V | 430 pF @ 10 V | - | 1W (Ta) | ||||||||||||||||
|
EFC4C002NLTDG | 1.0000 | |
5976 | 0.00000000 | Texas Instruments | - | Bulk | Active | 150°C (TJ) | Surface Mount | 8-XFBGA, WLCSP | EFC4C002 | MOSFET (Metal Oxide) | 2.6W | 8-WLCSP (6x2.5) | download | 0000.00.0000 | 1 | 2 N-Channel (Dual) Common Drain | - | - | - | 2.2V @ 1mA | 45nC @ 4.5V | 6200pF @ 15V | Logic Level Gate | |||||||||||||||||
|
SN74ACT202LA15NP | - | |
1750 | 0.00000000 | Texas Instruments | * | Bulk | Active | 74ACT202 | - | 0000.00.0000 | 1 | |||||||||||||||||||||||||||||||
|
CSD75301W1015 | - | |
8370 | 0.00000000 | Texas Instruments | NexFET™ | Tape & Reel (TR) | Obsolete | -55°C ~ 150°C (TJ) | Surface Mount | 6-UFBGA, DSBGA | CSD75301 | MOSFET (Metal Oxide) | 800mW | 6-DSBGA (1x1.5) | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8541.21.0095 | 3,000 | 2 P-Channel (Dual) | 20V | 1.2A | 100mOhm @ 1A, 4.5V | 1V @ 250µA | 2.1nC @ 4.5V | 195pF @ 10V | Logic Level Gate | |||||||||||||
|
CSD25304W1015T | 1.1100 | |
982 | 0.00000000 | Texas Instruments | NexFET™ | Tape & Reel (TR) | Active | -55°C ~ 150°C (TJ) | Surface Mount | 6-UFBGA, DSBGA | CSD25304W1015 | MOSFET (Metal Oxide) | 6-DSBGA (1x1.5) | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8541.21.0095 | 250 | P-Channel | 20 V | 3A (Ta) | 1.8V, 4.5V | 32.5mOhm @ 1.5A, 4.5V | 1.15V @ 250µA | 4.4 nC @ 4.5 V | ±8V | 595 pF @ 10 V | - | 750mW (Ta) | |||||||||||
|
ULN2803ADW-P | - | |
3595 | 0.00000000 | Texas Instruments | - | Bulk | Obsolete | -40°C ~ 85°C (TA) | Surface Mount | 18-SOIC (0.295", 7.50mm Width) | ULN2803 | - | 18-SOIC | - | ROHS3 Compliant | 296-ULN2803ADW-P | EAR99 | 8541.29.0095 | 1 | 50V | 500mA | 50µA | 8 NPN Darlington | 1.6V @ 500µA, 350mA | - | - | ||||||||||||||||
 |
TPS1120DR | 2.1000 | |
1 | 0.00000000 | Texas Instruments | - | Tape & Reel (TR) | Active | -40°C ~ 150°C (TJ) | Surface Mount | 8-SOIC (0.154", 3.90mm Width) | TPS1120 | MOSFET (Metal Oxide) | 840mW | 8-SOIC | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8541.21.0095 | 2,500 | 2 P-Channel (Dual) | 15V | 1.17A | 180mOhm @ 1.5A, 10V | 1.5V @ 250µA | 5.45nC @ 10V | - | Logic Level Gate | |||||||||||||
|
CSD16410Q5A | 0.9600 | |
8 | 0.00000000 | Texas Instruments | NexFET™ | Tape & Reel (TR) | Active | -55°C ~ 150°C (TJ) | Surface Mount | 8-PowerTDFN | CSD16410 | MOSFET (Metal Oxide) | 8-VSONP (5x6) | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8541.29.0095 | 2,500 | N-Channel | 25 V | 16A (Ta), 59A (Tc) | 4.5V, 10V | 8.5mOhm @ 17A, 10V | 2.3V @ 250µA | 5 nC @ 4.5 V | +16V, -12V | 740 pF @ 12.5 V | - | 3W (Ta) | |||||||||||
|
CSD16321Q5 | 1.6600 | |
26 | 0.00000000 | Texas Instruments | NexFET™ | Tape & Reel (TR) | Active | -55°C ~ 150°C (TJ) | Surface Mount | 8-PowerTDFN | CSD16321 | MOSFET (Metal Oxide) | 8-VSON-CLIP (5x6) | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8541.29.0095 | 2,500 | N-Channel | 25 V | 31A (Ta), 100A (Tc) | 3V, 8V | 2.4mOhm @ 25A, 8V | 1.4V @ 250µA | 19 nC @ 4.5 V | +10V, -8V | 3100 pF @ 12.5 V | - | 3.1W (Ta) | |||||||||||
 |
LP395Z/NOPB | 1.8000 | |
4 | 0.00000000 | Texas Instruments | - | Bulk | Active | 0°C ~ 125°C (TA) | Through Hole | TO-226-3, TO-92-3 (TO-226AA) | LP395 | TO-92-3 | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8541.29.0095 | 1,800 | 36 V | - | NPN | - | - | - | |||||||||||||||||
|
CSD16414Q5 | 2.0900 | |
2 | 0.00000000 | Texas Instruments | NexFET™ | Tape & Reel (TR) | Active | -55°C ~ 150°C (TJ) | Surface Mount | 8-PowerTDFN | CSD16414 | MOSFET (Metal Oxide) | 8-VSON-CLIP (5x6) | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8541.29.0095 | 2,500 | N-Channel | 25 V | 34A (Ta), 100A (Tc) | 4.5V, 10V | 1.9mOhm @ 30A, 10V | 2V @ 250µA | 21 nC @ 4.5 V | +16V, -12V | 3650 pF @ 12.5 V | - | 3.2W (Ta) | |||||||||||
|
CSD17556Q5BT | 3.0000 | |
442 | 0.00000000 | Texas Instruments | NexFET™ | Tape & Reel (TR) | Active | -55°C ~ 150°C (TJ) | Surface Mount | 8-PowerTDFN | CSD17556 | MOSFET (Metal Oxide) | 8-VSON-CLIP (5x6) | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8541.29.0095 | 250 | N-Channel | 30 V | 100A (Ta) | 4.5V, 10V | 1.4mOhm @ 40A, 10V | 1.65V @ 250µA | 39 nC @ 4.5 V | ±20V | 7020 pF @ 15 V | - | 3.1W (Ta), 191W (Tc) | |||||||||||
|
CSD16323Q3C | - | |
1183 | 0.00000000 | Texas Instruments | NexFET™ | Tape & Reel (TR) | Obsolete | -55°C ~ 150°C (TJ) | Surface Mount | 8-PowerTDFN | CSD16323 | MOSFET (Metal Oxide) | 8-SON-EP (3x3) | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8541.29.0095 | 2,500 | N-Channel | 25 V | 21A (Ta), 60A (Tc) | 3V, 8V | 4.5mOhm @ 24A, 8V | 1.4V @ 250µA | 8.4 nC @ 4.5 V | +10V, -8V | 1300 pF @ 12.5 V | - | 3W (Ta) |
