Transistors(427)
| Image | Product Number | Pricing(USD) | Quantity | ECAD | Quantity Available | Weight(Kg) | Mfr | Series | Package | Product Status | Operating Temperature | Mounting Type | Package / Case | Base Product Number | Technology | Power - Max | Supplier Device Package | DataSheet | RoHS Status | Moisture Sensitivity Level (MSL) | REACH Status | ECCN | HTSUS | Standard Package | Configuration | FET Type | Drain to Source Voltage (Vdss) | Current - Continuous Drain (Id) @ 25°C | Drive Voltage (Max Rds On, Min Rds On) | Rds On (Max) @ Id, Vgs | Vgs(th) (Max) @ Id | Gate Charge (Qg) (Max) @ Vgs | Vgs (Max) | Input Capacitance (Ciss) (Max) @ Vds | FET Feature | Power Dissipation (Max) | Voltage - Collector Emitter Breakdown (Max) | Current - Collector (Ic) (Max) | Voltage - Breakdown (V(BR)GSS) | Voltage - Cutoff (VGS off) @ Id | Current - Collector Cutoff (Max) | Transistor Type | Vce Saturation (Max) @ Ib, Ic | DC Current Gain (hFE) (Min) @ Ic, Vce | Frequency - Transition | Current Drain (Id) - Max |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
TPIC5424LDW | 1.8700 |  |
600 | 0.00000000 | Texas Instruments | * | Bulk | Active | download | RoHS non-compliant | 1 (Unlimited) | REACH Affected | EAR99 | 8541.29.0095 | 1 | ||||||||||||||||||||||||||||||
 |
CSD87352Q5D | 1.8500 | |
15 | 0.00000000 | Texas Instruments | NexFET™ | Tape & Reel (TR) | Active | -55°C ~ 150°C (TJ) | Surface Mount | 8-PowerLDFN | CSD87352Q5 | MOSFET (Metal Oxide) | 8.5W | 8-LSON (5x6) | download | ROHS3 Compliant | 1 (Unlimited) | REACH Affected | EAR99 | 8541.29.0095 | 2,500 | 2 N-Channel (Dual) | 30V | 25A | - | 1.15V @ 250µA | 12.5nC @ 4.5V | 1800pF @ 15V | Logic Level Gate | |||||||||||||||
 |
CSD18510KCS | 2.2300 | |
3 | 0.00000000 | Texas Instruments | NexFET™ | Tube | Active | -55°C ~ 175°C (TJ) | Through Hole | TO-220-3 | CSD18510 | MOSFET (Metal Oxide) | TO-220-3 | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8541.29.0095 | 50 | N-Channel | 40 V | 200A (Ta) | 4.5V, 10V | 1.7mOhm @ 100A, 10V | 2.3V @ 250µA | 75 nC @ 4.5 V | ±20V | 11400 pF @ 20 V | - | 250W (Ta) | |||||||||||||
 |
CSD19534KCS | 1.5900 | |
545 | 0.00000000 | Texas Instruments | - | Tube | Active | -55°C ~ 175°C (TJ) | Through Hole | TO-220-3 | CSD19534 | MOSFET (Metal Oxide) | TO-220-3 | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8541.29.0095 | 50 | N-Channel | 100 V | 100A (Ta) | 6V, 10V | 16.5mOhm @ 30A, 10V | 3.4V @ 250µA | 22.2 nC @ 10 V | ±20V | 1670 pF @ 50 V | - | 118W (Tc) | |||||||||||||
 |
CSD25480F3 | 0.4600 | |
11 | 0.00000000 | Texas Instruments | FemtoFET™ | Tape & Reel (TR) | Active | -55°C ~ 150°C (TJ) | Surface Mount | 3-XFDFN | CSD25480 | MOSFET (Metal Oxide) | 3-PICOSTAR | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8541.21.0095 | 3,000 | P-Channel | 20 V | 1.7A (Ta) | 1.8V, 8V | 132mOhm @ 400mA, 8V | 1.2V @ 250µA | 0.91 nC @ 4.5 V | -12V | 155 pF @ 10 V | - | 500mW (Ta) | |||||||||||||
 |
CSD16340Q3 | 1.2000 | |
25 | 0.00000000 | Texas Instruments | NexFET™ | Tape & Reel (TR) | Active | -55°C ~ 150°C (TJ) | Surface Mount | 8-PowerTDFN | CSD16340 | MOSFET (Metal Oxide) | 8-VSON-CLIP (3.3x3.3) | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8541.29.0095 | 2,500 | N-Channel | 25 V | 21A (Ta), 60A (Tc) | 2.5V, 8V | 4.5mOhm @ 20A, 8V | 1.1V @ 250µA | 9.2 nC @ 4.5 V | +10V, -8V | 1350 pF @ 12.5 V | - | 3W (Ta) | |||||||||||||
 |
CSD17307Q5A | 0.8300 | |
8 | 0.00000000 | Texas Instruments | NexFET™ | Tape & Reel (TR) | Active | -55°C ~ 150°C (TJ) | Surface Mount | 8-PowerTDFN | CSD17307 | MOSFET (Metal Oxide) | 8-VSONP (5x6) | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8541.29.0095 | 2,500 | N-Channel | 30 V | 14A (Ta), 73A (Tc) | 3V, 8V | 10.5mOhm @ 11A, 8V | 1.8V @ 250µA | 5.2 nC @ 4.5 V | +10V, -8V | 700 pF @ 15 V | - | 3W (Ta) | |||||||||||||
 |
TPS1100PW | 1.7900 | |
523 | 0.00000000 | Texas Instruments | - | Tube | Active | -40°C ~ 150°C (TJ) | Surface Mount | 8-TSSOP (0.173", 4.40mm Width) | TPS1100 | MOSFET (Metal Oxide) | 8-TSSOP | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8541.21.0095 | 150 | P-Channel | 15 V | 1.27A (Ta) | 2.7V, 10V | 180mOhm @ 1.5A, 10V | 1.5V @ 250µA | 5.45 nC @ 10 V | +2V, -15V | - | 504mW (Ta) | ||||||||||||||
 |
SN75468DE4 | - | |
4930 | 0.00000000 | Texas Instruments | Automotive, AEC-Q100 | Tube | Discontinued at SIC | 150°C (TJ) | Surface Mount | 16-SOIC (0.154", 3.90mm Width) | 75468 | - | 16-SOIC | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8541.29.0095 | 40 | 100V | 500mA | - | 7 NPN Darlington | 1.6V @ 500µA, 350mA | - | - | |||||||||||||||||
 |
CSD87333Q3DT | 1.5500 | |
325 | 0.00000000 | Texas Instruments | NexFET™ | Tape & Reel (TR) | Active | 125°C (TJ) | Surface Mount | 8-PowerTDFN | CSD87333Q3 | MOSFET (Metal Oxide) | 6W | 8-VSON (3.3x3.3) | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8541.29.0095 | 250 | 2 N-Channel (Dual) Asymmetrical | 30V | 15A | 14.3mOhm @ 4A, 8V | 1.2V @ 250µA | 4.6nC @ 4.5V | 662pF @ 15V | Logic Level Gate, 5V Drive | |||||||||||||||
 |
CSD22204W | 0.6500 | |
3 | 0.00000000 | Texas Instruments | NexFET™ | Tape & Reel (TR) | Active | -55°C ~ 150°C (TJ) | Surface Mount | 9-UFBGA, DSBGA | CSD22204 | MOSFET (Metal Oxide) | 9-DSBGA | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8541.29.0095 | 3,000 | P-Channel | 8 V | 5A (Ta) | 2.5V, 4.5V | 9.9mOhm @ 2A, 4.5V | 950mV @ 250µA | 24.6 nC @ 4.5 V | -6V | 1130 pF @ 4 V | - | 1.7W (Ta) | |||||||||||||
|
CSD17578Q5AT | 1.3600 | |
1 | 0.00000000 | Texas Instruments | NexFET™ | Tape & Reel (TR) | Active | -55°C ~ 150°C (TJ) | Surface Mount | 8-PowerTDFN | CSD17578 | MOSFET (Metal Oxide) | 8-VSONP (5x6) | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8541.29.0095 | 250 | N-Channel | 30 V | 25A (Ta) | 4.5V, 10V | 6.9mOhm @ 10A, 10V | 1.9V @ 250µA | 22.3 nC @ 10 V | ±20V | 1510 pF @ 15 V | - | 3.1W (Ta), 42W (Tc) | |||||||||||||
 |
TPIC1502DW | - | |
1602 | 0.00000000 | Texas Instruments | - | Tube | Obsolete | -40°C ~ 150°C (TJ) | Surface Mount | 24-SOIC (0.295", 7.50mm Width) | TPIC15 | MOSFET (Metal Oxide) | 2.86W | 24-SOIC | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8541.29.0095 | 1,000 | - | 20V | 1.5A | 300mOhm @ 1.5A, 10V | 2.2V @ 1mA | 2.1nC @ 10V | 98pF @ 14V | Logic Level Gate | |||||||||||||||
|
CSD25202W15T | 1.2800 | |
1 | 0.00000000 | Texas Instruments | NexFET™ | Tape & Reel (TR) | Active | -55°C ~ 150°C (TJ) | Surface Mount | 9-UFBGA, DSBGA | CSD25202W15 | MOSFET (Metal Oxide) | 9-DSBGA | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8541.29.0095 | 250 | P-Channel | 20 V | 4A (Ta) | 1.8V, 4.5V | 26mOhm @ 2A, 4.5V | 1.05V @ 250µA | 7.5 nC @ 4.5 V | -6V | 1010 pF @ 10 V | - | 500mW (Ta) | |||||||||||||
|
CSD17522Q5A | 1.2100 | |
14 | 0.00000000 | Texas Instruments | NexFET™ | Tape & Reel (TR) | Active | -55°C ~ 150°C (TJ) | Surface Mount | 8-PowerTDFN | CSD17522 | MOSFET (Metal Oxide) | 8-VSONP (5x6) | download | ROHS3 Compliant | 1 (Unlimited) | REACH Affected | EAR99 | 8541.29.0095 | 2,500 | N-Channel | 30 V | 87A (Tc) | 4.5V, 10V | 8.1mOhm @ 14A, 10V | 2V @ 250µA | 4.3 nC @ 4.5 V | ±20V | 695 pF @ 15 V | - | 3W (Ta) | |||||||||||||
 |
CSD22205LT | 1.0800 | |
30 | 0.00000000 | Texas Instruments | NexFET™ | Tape & Reel (TR) | Active | -55°C ~ 150°C (TJ) | Surface Mount | 4-XFLGA | CSD22205 | MOSFET (Metal Oxide) | 4-PICOSTAR | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8541.21.0095 | 250 | P-Channel | 8 V | 7.4A (Ta) | 1.5V, 4.5V | 9.9mOhm @ 1A, 4.5V | 1.05V @ 250µA | 8.5 nC @ 4.5 V | -6V | 1390 pF @ 4 V | - | 600mW (Ta) | |||||||||||||
 |
CSD87381PT | 1.1100 | |
26 | 0.00000000 | Texas Instruments | NexFET™ | Tape & Reel (TR) | Active | -55°C ~ 150°C (TJ) | Surface Mount | 5-LGA | CSD87381 | MOSFET (Metal Oxide) | 4W | 5-PTAB (3x2.5) | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8541.29.0095 | 250 | 2 N-Channel (Half Bridge) | 30V | 15A | 16.3mOhm @ 8A, 8V | 1.9V @ 250µA | 5nC @ 4.5V | 564pF @ 15V | Logic Level Gate | |||||||||||||||
 |
TPIC1533DWR | 2.3100 | |
5 | 0.00000000 | Texas Instruments | * | Bulk | Active | download | Not applicable | 1 (Unlimited) | Vendor Undefined | EAR99 | 8541.29.0095 | 1 | ||||||||||||||||||||||||||||||
|
CSD18514Q5AT | 1.0100 | |
890 | 0.00000000 | Texas Instruments | NexFET™ | Tape & Reel (TR) | Active | -55°C ~ 150°C (TJ) | Surface Mount | 8-PowerTDFN | CSD18514 | MOSFET (Metal Oxide) | 8-VSONP (5x6) | download | ROHS3 Compliant | 1 (Unlimited) | REACH Affected | EAR99 | 8541.29.0095 | 250 | N-Channel | 40 V | 89A (Tc) | 4.5V, 10V | 7.9mOhm @ 15A, 10V | 2.4V @ 250µA | 40 nC @ 10 V | ±20V | 2683 pF @ 20 V | - | 74W (Tc) | |||||||||||||
 |
JFE2140DR | 4.4800 | |
1 | 0.00000000 | Texas Instruments | - | Tape & Reel (TR) | Active | -55°C ~ 150°C (TJ) | Surface Mount | 8-SOIC (0.154", 3.90mm Width) | JFE2140 | 8-SOIC | download | Not applicable | 2 (1 Year) | EAR99 | 8541.29.0095 | 2,500 | 2 N-Channel (Dual) | 40 V | 13pF @ 5V | 40 V | 1.5 V @ 0.1 µA | 50 mA | ||||||||||||||||||||
 |
CSD87501L | 1.0000 | |
9 | 0.00000000 | Texas Instruments | NexFET™ | Tape & Reel (TR) | Active | -55°C ~ 150°C (TJ) | Surface Mount | 10-XFLGA | CSD87501 | MOSFET (Metal Oxide) | 2.5W | 10-Picostar (3.37x1.47) | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8541.29.0095 | 3,000 | 2 N-Channel (Dual) Common Drain | - | - | - | 2.3V @ 250µA | 40nC @ 10V | - | Logic Level Gate | |||||||||||||||
 |
CSD23202W10T | 1.0000 | |
15 | 0.00000000 | Texas Instruments | NexFET™ | Tape & Reel (TR) | Active | -55°C ~ 150°C (TJ) | Surface Mount | 4-UFBGA, DSBGA | CSD23202 | MOSFET (Metal Oxide) | 4-DSBGA (1x1) | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8541.29.0095 | 250 | P-Channel | 12 V | 2.2A (Ta) | 1.5V, 4.5V | 53mOhm @ 500mA, 4.5V | 900mV @ 250µA | 3.8 nC @ 4.5 V | -6V | 512 pF @ 6 V | - | 1W (Ta) | |||||||||||||
 |
CSD19536KTTT | 6.0500 | |
468 | 0.00000000 | Texas Instruments | NexFET™ | Tape & Reel (TR) | Active | -55°C ~ 175°C (TJ) | Surface Mount | TO-263-4, D²Pak (3 Leads + Tab), TO-263AA | CSD19536 | MOSFET (Metal Oxide) | DDPAK/TO-263-3 | download | ROHS3 Compliant | 2 (1 Year) | REACH Unaffected | EAR99 | 8541.29.0095 | 50 | N-Channel | 100 V | 200A (Ta) | 6V, 10V | 2.4mOhm @ 100A, 10V | 3.2V @ 250µA | 153 nC @ 10 V | ±20V | 12000 pF @ 50 V | - | 375W (Tc) | |||||||||||||
|
CSD17312Q5 | 2.3000 | |
4 | 0.00000000 | Texas Instruments | NexFET™ | Tape & Reel (TR) | Active | -55°C ~ 150°C (TJ) | Surface Mount | 8-PowerTDFN | CSD17312 | MOSFET (Metal Oxide) | 8-VSON-CLIP (5x6) | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8541.29.0095 | 2,500 | N-Channel | 30 V | 38A (Ta), 100A (Tc) | 3V, 8V | 1.5mOhm @ 35A, 8V | 1.5V @ 250µA | 36 nC @ 4.5 V | +10V, -8V | 5240 pF @ 15 V | - | 3.2W (Ta) | |||||||||||||
 |
CSD19532Q5B | 2.6400 | |
9 | 0.00000000 | Texas Instruments | NexFET™ | Tape & Reel (TR) | Active | -55°C ~ 150°C (TJ) | Surface Mount | 8-PowerTDFN | CSD19532 | MOSFET (Metal Oxide) | 8-VSON-CLIP (5x6) | download | ROHS3 Compliant | 1 (Unlimited) | REACH Affected | EAR99 | 8541.29.0095 | 2,500 | N-Channel | 100 V | 100A (Ta) | 6V, 10V | 4.9mOhm @ 17A, 10V | 3.2V @ 250µA | 62 nC @ 10 V | ±20V | 4810 pF @ 50 V | - | 3.1W (Ta), 195W (Tc) | |||||||||||||
|
CSD18563Q5AT | 1.6000 | |
23 | 0.00000000 | Texas Instruments | NexFET™ | Tape & Reel (TR) | Active | -55°C ~ 150°C (TJ) | Surface Mount | 8-PowerTDFN | CSD18563 | MOSFET (Metal Oxide) | 8-VSONP (5x6) | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8541.29.0095 | 250 | N-Channel | 60 V | 100A (Ta) | 4.5V, 10V | 6.8mOhm @ 18A, 10V | 2.4V @ 250µA | 20 nC @ 10 V | ±20V | 1500 pF @ 30 V | - | 3.2W (Ta), 116W (Tc) | |||||||||||||
|
CSD19503KCS | 1.7300 | |
1377 | 0.00000000 | Texas Instruments | NexFET™ | Tube | Active | -55°C ~ 175°C (TJ) | Through Hole | TO-220-3 | CSD19503 | MOSFET (Metal Oxide) | TO-220-3 | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8541.29.0095 | 50 | N-Channel | 80 V | 100A (Ta) | 6V, 10V | 9.2mOhm @ 60A, 10V | 3.4V @ 250µA | 36 nC @ 10 V | ±20V | 2730 pF @ 40 V | - | 188W (Tc) | |||||||||||||
 |
CSD17313Q2Q1T | 0.8664 | |
2 | 0.00000000 | Texas Instruments | NexFET™ | Tape & Reel (TR) | Obsolete | -55°C ~ 150°C (TJ) | Surface Mount | 6-WDFN Exposed Pad | CSD173 | MOSFET (Metal Oxide) | 6-WSON (2x2) | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8541.29.0095 | 250 | N-Channel | 30 V | 5A (Ta) | 3V, 8V | 30mOhm @ 4A, 8V | 1.8V @ 250µA | 2.7 nC @ 4.5 V | +10V, -8V | 340 pF @ 15 V | - | 2.4W (Ta), 17W (Tc) | |||||||||||||
 |
CSD23381F4 | 0.4500 | |
257 | 0.00000000 | Texas Instruments | NexFET™ | Tape & Reel (TR) | Active | -55°C ~ 150°C (TJ) | Surface Mount | 3-XFDFN | CSD23381 | MOSFET (Metal Oxide) | 3-PICOSTAR | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8541.21.0095 | 3,000 | P-Channel | 12 V | 2.3A (Ta) | 1.8V, 4.5V | 175mOhm @ 500mA, 4.5V | 1.2V @ 250µA | 1.14 nC @ 4.5 V | -8V | 236 pF @ 6 V | - | 500mW (Ta) | |||||||||||||
|
CSD25480F3T | 0.9500 | |
43 | 0.00000000 | Texas Instruments | FemtoFET™ | Tape & Reel (TR) | Active | -55°C ~ 150°C (TJ) | Surface Mount | 3-XFDFN | CSD25480 | MOSFET (Metal Oxide) | 3-PICOSTAR | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8541.21.0095 | 250 | P-Channel | 20 V | 1.7A (Ta) | 1.8V, 8V | 132mOhm @ 400mA, 8V | 1.2V @ 250µA | 0.91 nC @ 10 V | -12V | 155 pF @ 10 V | - | 500mW (Ta) |
