Single Diodes(57622)
| Image | Product Number | Pricing(USD) | Quantity | ECAD | Quantity Available | Weight(Kg) | Mfr | Series | Package | Product Status | Mounting Type | Package / Case | Base Product Number | Technology | Supplier Device Package | DataSheet | RoHS Status | Moisture Sensitivity Level (MSL) | REACH Status | ECCN | HTSUS | Standard Package | Speed | Voltage - DC Reverse (Vr) (Max) | Voltage - Forward (Vf) (Max) @ If | Reverse Recovery Time (trr) | Current - Reverse Leakage @ Vr | Operating Temperature - Junction | Current - Average Rectified (Io) | Capacitance @ Vr, F |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
NRVTS10120EMFST3G | 0.4321 |  |
9578 | 0.00000000 | onsemi | Automotive, AEC-Q101 | Tape & Reel (TR) | Active | Surface Mount | 8-PowerTDFN, 5 Leads | NRVTS10120 | Schottky | 5-DFN (5x6) (8-SOFL) | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8541.10.0080 | 5,000 | Fast Recovery =< 500ns, > 200mA (Io) | 120 V | 820 mV @ 10 A | 30 µA @ 120 V | -55°C ~ 175°C | 10A | - | ||
|
NRVTS12120EMFST3G | 0.4403 | |
6919 | 0.00000000 | onsemi | Automotive, AEC-Q101 | Tape & Reel (TR) | Active | Surface Mount | 8-PowerTDFN, 5 Leads | NRVTS12120 | Schottky | 5-DFN (5x6) (8-SOFL) | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8541.10.0080 | 5,000 | Fast Recovery =< 500ns, > 200mA (Io) | 120 V | 830 mV @ 12 A | 55 µA @ 120 V | -55°C ~ 175°C | 12A | - | ||
|
NRVTS12120MFST3G | 1.0800 | |
9239 | 0.00000000 | onsemi | Automotive, AEC-Q101 | Tape & Reel (TR) | Active | Surface Mount | 8-PowerTDFN, 5 Leads | NRVTS12120 | Schottky | 5-DFN (5x6) (8-SOFL) | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8541.10.0080 | 5,000 | Fast Recovery =< 500ns, > 200mA (Io) | 120 V | 830 mV @ 12 A | 75 µA @ 120 V | -55°C ~ 150°C | 12A | - | ||
 |
NRVTS245ESFT3G | 0.5100 | |
4071 | 0.00000000 | onsemi | Automotive, AEC-Q101 | Tape & Reel (TR) | Active | Surface Mount | SOD-123F | NRVTS245 | Schottky | SOD-123FL | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8541.10.0080 | 10,000 | Fast Recovery =< 500ns, > 200mA (Io) | 45 V | 650 mV @ 2 A | 75 µA @ 45 V | -65°C ~ 175°C | 2A | - | ||
|
NRVTS260ESFT3G | - | |
1119 | 0.00000000 | onsemi | Automotive, AEC-Q101 | Tape & Reel (TR) | Obsolete | Surface Mount | SOD-123F | NRVTS260 | Schottky | SOD-123FL | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8541.10.0080 | 10,000 | Fast Recovery =< 500ns, > 200mA (Io) | 60 V | 650 mV @ 2 A | 12 µA @ 60 V | -65°C ~ 175°C | 2A | - | ||
 |
NSVBAS16WT3G | 0.0653 | |
7006 | 0.00000000 | onsemi | Automotive, AEC-Q101 | Tape & Reel (TR) | Active | Surface Mount | SC-70, SOT-323 | NSVBAS16 | Standard | SC-70-3 (SOT323) | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8541.10.0070 | 10,000 | Small Signal =< 200mA (Io), Any Speed | 100 V | 1.25 V @ 200 mA | 6 ns | 1 µA @ 100 V | -55°C ~ 150°C | 200mA | - | |
 |
NSVR0320XV6T1G | 0.6000 | |
3 | 0.00000000 | onsemi | Automotive, AEC-Q101 | Tape & Reel (TR) | Active | Surface Mount | SOT-563, SOT-666 | NSVR0320 | Schottky | SOT-563 | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8541.10.0080 | 4,000 | Fast Recovery =< 500ns, > 200mA (Io) | 23 V | 270 mV @ 10 mA | 50 µA @ 15 V | -55°C ~ 150°C | 1A | 35pF @ 5V, 1MHz | ||
 |
NSVR05F40NXT5G | 0.4500 | |
4 | 0.00000000 | onsemi | Automotive, AEC-Q101 | Tape & Reel (TR) | Active | Surface Mount | 0402 (1006 Metric) | NSVR05 | Schottky | 2-DSN (1x0.6), (0402) | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8541.10.0070 | 5,000 | Fast Recovery =< 500ns, > 200mA (Io) | 40 V | 460 mV @ 500 mA | 75 µA @ 40 V | -40°C ~ 150°C | 500mA | 35pF @ 10V, 1MHz | ||
|
NTS10100EMFST1G | - | |
8803 | 0.00000000 | onsemi | - | Tape & Reel (TR) | Obsolete | Surface Mount | 8-PowerTDFN, 5 Leads | NTS10100 | Schottky | 5-DFN (5x6) (8-SOFL) | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8541.10.0080 | 1,500 | Fast Recovery =< 500ns, > 200mA (Io) | 100 V | 720 mV @ 10 A | 50 µA @ 100 V | -55°C ~ 175°C | 10A | - | ||
|
NTS10100MFST1G | - | |
8165 | 0.00000000 | onsemi | - | Tape & Reel (TR) | Obsolete | Surface Mount | 8-PowerTDFN, 5 Leads | NTS10100 | Schottky | 5-DFN (5x6) (8-SOFL) | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8541.10.0080 | 1,500 | Fast Recovery =< 500ns, > 200mA (Io) | 100 V | 720 mV @ 10 A | 70 µA @ 100 V | -55°C ~ 150°C | 10A | - | ||
|
NRVTS10120MFST1G | 0.4175 | |
9848 | 0.00000000 | onsemi | Automotive, AEC-Q101 | Tape & Reel (TR) | Last Time Buy | Surface Mount | 8-PowerTDFN, 5 Leads | NRVTS10120 | Schottky | 5-DFN (5x6) (8-SOFL) | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8541.10.0080 | 1,500 | Fast Recovery =< 500ns, > 200mA (Io) | 120 V | 820 mV @ 10 A | 30 µA @ 120 V | -55°C ~ 175°C | 10A | - | ||
|
NRVTS12120EMFST1G | 1.1400 | |
5538 | 0.00000000 | onsemi | Automotive, AEC-Q101 | Tape & Reel (TR) | Active | Surface Mount | 8-PowerTDFN, 5 Leads | NRVTS12120 | Schottky | 5-DFN (5x6) (8-SOFL) | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8541.10.0080 | 1,500 | Fast Recovery =< 500ns, > 200mA (Io) | 120 V | 830 mV @ 12 A | 55 µA @ 120 V | -55°C ~ 175°C | 12A | - | ||
 |
DLLFSD01T-7 | 0.2900 | |
59 | 0.00000000 | Diodes Incorporated | - | Tape & Reel (TR) | Active | Surface Mount | SC-79, SOD-523 | DLLFSD01 | Standard | SOD-523 | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8541.10.0070 | 3,000 | Small Signal =< 200mA (Io), Any Speed | 80 V | 1.2 V @ 100 mA | 4 ns | 200 nA @ 80 V | -65°C ~ 150°C | 100mA | 2.5pF @ 0V, 1MHz | |
 |
GKN130/18 | 35.5490 | |
9985 | 0.00000000 | GeneSiC Semiconductor | - | Bulk | Active | Chassis, Stud Mount | DO-205AA, DO-8, Stud | GKN130 | Standard | DO-205AA (DO-8) | - | RoHS Compliant | 1 (Unlimited) | EAR99 | 8541.10.0080 | 10 | Standard Recovery >500ns, > 200mA (Io) | 1800 V | 1.5 V @ 60 A | 22 mA @ 1800 V | -55°C ~ 150°C | 165A | - | |||
 |
MBRH15040RL | - | |
7961 | 0.00000000 | GeneSiC Semiconductor | - | Bulk | Obsolete | Chassis Mount | D-67 | Schottky, Reverse Polarity | D-67 | - | 1 (Unlimited) | EAR99 | 8541.10.0080 | 50 | Fast Recovery =< 500ns, > 200mA (Io) | 40 V | 600 mV @ 150 A | 5 mA @ 40 V | 150A | - | ||||||
|
MBRH20030RL | - | |
8472 | 0.00000000 | GeneSiC Semiconductor | - | Bulk | Obsolete | Chassis Mount | D-67 | Schottky, Reverse Polarity | D-67 | - | 1 (Unlimited) | EAR99 | 8541.10.0080 | 50 | Fast Recovery =< 500ns, > 200mA (Io) | 30 V | 580 mV @ 200 A | 3 mA @ 30 V | -55°C ~ 150°C | 200A | - | |||||
 |
SD4145R | 14.3280 | |
5296 | 0.00000000 | GeneSiC Semiconductor | - | Bulk | Active | Chassis, Stud Mount | DO-203AA, DO-4, Stud | SD4145 | Schottky, Reverse Polarity | DO-4 | download | RoHS Compliant | 1 (Unlimited) | EAR99 | 8541.10.0080 | 250 | Fast Recovery =< 500ns, > 200mA (Io) | 45 V | 680 mV @ 30 A | 1.5 mA @ 35 V | -55°C ~ 150°C | 30A | - | |||
 |
1SS427,L3M | 0.2700 | |
55 | 0.00000000 | Toshiba Semiconductor and Storage | - | Tape & Reel (TR) | Active | Surface Mount | SOD-923 | 1SS427 | Standard | SOD-923 | download | ROHS3 Compliant | 1 (Unlimited) | EAR99 | 8541.10.0070 | 10,000 | Small Signal =< 200mA (Io), Any Speed | 80 V | 1.2 V @ 100 mA | 1.6 ns | 500 nA @ 80 V | -55°C ~ 150°C | 100mA | 0.3pF @ 0V, 1MHz | ||
 |
FSV20120V | 1.7100 | |
8 | 0.00000000 | onsemi | - | Tape & Reel (TR) | Not For New Designs | Surface Mount | TO-277, 3-PowerDFN | FSV20120 | Schottky | TO-277-3 | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8541.10.0080 | 5,000 | Fast Recovery =< 500ns, > 200mA (Io) | 120 V | 790 mV @ 20 A | 35 µA @ 120 V | -55°C ~ 150°C | 20A | - | ||
 |
PDS340Q-13 | 0.4788 | |
1476 | 0.00000000 | Diodes Incorporated | Automotive, AEC-Q101 | Tape & Reel (TR) | Active | Surface Mount | PowerDI™ 5 | PDS340 | Schottky | PowerDI™ 5 | download | ROHS3 Compliant | 1 (Unlimited) | REACH Affected | EAR99 | 8541.10.0080 | 5,000 | Fast Recovery =< 500ns, > 200mA (Io) | 40 V | 490 mV @ 3 A | 500 µA @ 40 V | -55°C ~ 150°C | 3A | - | ||
|
PDS5100Q-13D | 1.0600 | |
8198 | 0.00000000 | Diodes Incorporated | Automotive, AEC-Q101 | Tape & Reel (TR) | Active | Surface Mount | PowerDI™ 5 | PDS5100 | Schottky | PowerDI™ 5 | download | ROHS3 Compliant | 1 (Unlimited) | REACH Affected | EAR99 | 8541.10.0080 | 5,000 | Fast Recovery =< 500ns, > 200mA (Io) | 100 V | 790 mV @ 5 A | 200 µA @ 100 V | -55°C ~ 150°C | 5A | - | ||
 |
SBR2U10LP-7 | - | |
5037 | 0.00000000 | Diodes Incorporated | SBR® | Tape & Reel (TR) | Obsolete | Surface Mount | 3-UDFN | SBR2U10 | Super Barrier | X1-DFN1411-3 | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8541.10.0080 | 3,000 | Fast Recovery =< 500ns, > 200mA (Io) | 10 V | 460 mV @ 2 A | 60 ns | 2 mA @ 10 V | -65°C ~ 150°C | 2A | 102pF @ 5V, 1MHz | |
|
SBRT10U50SP5-13D | 0.7100 | |
4 | 0.00000000 | Diodes Incorporated | Automotive, AEC-Q101 | Tape & Reel (TR) | Active | Surface Mount | PowerDI™ 5 | SBRT10 | Super Barrier | PowerDI™ 5 | download | ROHS3 Compliant | 1 (Unlimited) | REACH Affected | EAR99 | 8541.10.0080 | 5,000 | Standard Recovery >500ns, > 200mA (Io) | 50 V | 450 mV @ 10 A | 300 µA @ 50 V | -55°C ~ 150°C | 10A | - | ||
 |
SBRT4U60LP-7 | - | |
6478 | 0.00000000 | Diodes Incorporated | - | Tape & Reel (TR) | Obsolete | Surface Mount | 8-PowerUDFN | SBRT4 | Super Barrier | U-DFN3030-8 | - | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8541.10.0080 | 3,000 | Standard Recovery >500ns, > 200mA (Io) | 60 V | 520 mV @ 4 A | 150 µA @ 60 V | -55°C ~ 175°C | 4A | 180pF @ 5V, 1MHz | ||
 |
S2DHE3_A/I | 0.1040 | |
9026 | 0.00000000 | Vishay General Semiconductor - Diodes Division | Automotive, AEC-Q101 | Tape & Reel (TR) | Active | Surface Mount | DO-214AA, SMB | S2D | Standard | DO-214AA (SMB) | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8541.10.0080 | 3,200 | Standard Recovery >500ns, > 200mA (Io) | 200 V | 1.15 V @ 1.5 A | 2 µs | 1 µA @ 200 V | -55°C ~ 150°C | 1.5A | 16pF @ 4V, 1MHz | |
|
S2GHE3_A/H | 0.3800 | |
3 | 0.00000000 | Vishay General Semiconductor - Diodes Division | Automotive, AEC-Q101 | Tape & Reel (TR) | Active | Surface Mount | DO-214AA, SMB | S2G | Standard | DO-214AA (SMB) | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8541.10.0080 | 750 | Standard Recovery >500ns, > 200mA (Io) | 400 V | 1.15 V @ 1.5 A | 2 µs | 1 µA @ 400 V | -55°C ~ 150°C | 1.5A | 16pF @ 4V, 1MHz | |
|
S2KHE3_A/H | 0.1119 | |
1815 | 0.00000000 | Vishay General Semiconductor - Diodes Division | Automotive, AEC-Q101 | Tape & Reel (TR) | Active | Surface Mount | DO-214AA, SMB | S2K | Standard | DO-214AA (SMB) | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8541.10.0080 | 750 | Standard Recovery >500ns, > 200mA (Io) | 800 V | 1.15 V @ 1.5 A | 2 µs | 1 µA @ 800 V | -55°C ~ 150°C | 1.5A | 16pF @ 4V, 1MHz | |
|
S2KHE3_A/I | 0.1056 | |
9667 | 0.00000000 | Vishay General Semiconductor - Diodes Division | Automotive, AEC-Q101 | Tape & Reel (TR) | Active | Surface Mount | DO-214AA, SMB | S2K | Standard | DO-214AA (SMB) | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8541.10.0080 | 3,200 | Standard Recovery >500ns, > 200mA (Io) | 800 V | 1.15 V @ 1.5 A | 2 µs | 1 µA @ 800 V | -55°C ~ 150°C | 1.5A | 16pF @ 4V, 1MHz | |
 |
PMEG10020AELRX | 0.4500 | |
28 | 0.00000000 | Nexperia USA Inc. | Automotive, AEC-Q101 | Tape & Reel (TR) | Active | Surface Mount | SOD-123W | PMEG10020 | Schottky | SOD-123W | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8541.10.0080 | 3,000 | Fast Recovery =< 500ns, > 200mA (Io) | 100 V | 770 mV @ 2 A | 5 ns | 300 nA @ 100 V | 175°C (Max) | 2A | 135pF @ 1V, 1MHz | |
 |
PMEG1201AESFYL | - | |
5128 | 0.00000000 | Nexperia USA Inc. | - | Tape & Reel (TR) | Obsolete | Surface Mount | 0201 (0603 Metric) | Schottky | DSN0603-2 | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8541.10.0070 | 9,000 | Fast Recovery =< 500ns, > 200mA (Io) | 12 V | 200 mV @ 30 mA | 2.2 ns | 2 mA @ 12 V | 125°C (Max) | 100mA | 26pF @ 1V, 1MHz |
