Single Diodes(57622)
| Image | Product Number | Pricing(USD) | Quantity | ECAD | Quantity Available | Weight(Kg) | Mfr | Series | Package | Product Status | Mounting Type | Package / Case | Base Product Number | Technology | Supplier Device Package | DataSheet | RoHS Status | Moisture Sensitivity Level (MSL) | REACH Status | Other Names | ECCN | HTSUS | Standard Package | Speed | Voltage - DC Reverse (Vr) (Max) | Voltage - Forward (Vf) (Max) @ If | Reverse Recovery Time (trr) | Current - Reverse Leakage @ Vr | Operating Temperature - Junction | Current - Average Rectified (Io) | Capacitance @ Vr, F |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
VS-15ETL06SPBF | - |  |
8708 | 0.00000000 | Vishay General Semiconductor - Diodes Division | Automotive, AEC-Q101, FRED Pt® | Tube | Discontinued at SIC | Surface Mount | TO-263-3, D²Pak (2 Leads + Tab), TO-263AB | 15ETL06 | Standard | TO-263AB (D²PAK) | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | VS15ETL06SPBF | EAR99 | 8541.10.0080 | 50 | Fast Recovery =< 500ns, > 200mA (Io) | 600 V | 2.2 V @ 15 A | 29 ns | 50 µA @ 600 V | -65°C ~ 175°C | 15A | - | |
 |
VS-15ETX06-1PBF | - | |
9217 | 0.00000000 | Vishay General Semiconductor - Diodes Division | Automotive, AEC-Q101, FRED Pt® | Tube | Discontinued at SIC | Through Hole | TO-262-3 Long Leads, I²Pak, TO-262AA | 15ETX06 | Standard | TO-262AA | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | VS15ETX061PBF | EAR99 | 8541.10.0080 | 50 | Fast Recovery =< 500ns, > 200mA (Io) | 600 V | 3.2 V @ 15 A | 18 ns | 50 µA @ 600 V | -65°C ~ 175°C | 15A | - | |
 |
VS-6EWH06FNHM3 | 1.0025 | |
3246 | 0.00000000 | Vishay General Semiconductor - Diodes Division | Automotive, AEC-Q101, FRED Pt® | Tube | Active | Surface Mount | TO-252-3, DPak (2 Leads + Tab), SC-63 | 6EWH06 | Standard | D-PAK (TO-252AA) | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | VS6EWH06FNHM3 | EAR99 | 8541.10.0080 | 3,000 | Fast Recovery =< 500ns, > 200mA (Io) | 600 V | 2.1 V @ 6 A | 27 ns | 50 µA @ 600 V | -65°C ~ 175°C | 6A | - | |
|
VS-6TQ040SPBF | - | |
6359 | 0.00000000 | Vishay General Semiconductor - Diodes Division | Automotive, AEC-Q101 | Tube | Discontinued at SIC | Surface Mount | TO-263-3, D²Pak (2 Leads + Tab), TO-263AB | 6TQ040 | Schottky | TO-263AB (D²PAK) | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | VS6TQ040SPBF | EAR99 | 8541.10.0080 | 50 | Fast Recovery =< 500ns, > 200mA (Io) | 40 V | 600 mV @ 6 A | 800 µA @ 40 V | -55°C ~ 175°C | 6A | 400pF @ 5V, 1MHz | ||
 |
VS-80APF04PBF | - | |
7952 | 0.00000000 | Vishay General Semiconductor - Diodes Division | - | Tube | Obsolete | Through Hole | TO-247-3 | 80APF04 | Standard | TO-247AC | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | VS80APF04PBF | EAR99 | 8541.10.0080 | 500 | Fast Recovery =< 500ns, > 200mA (Io) | 400 V | 1.25 V @ 80 A | 190 ns | 100 µA @ 400 V | -40°C ~ 150°C | 80A | - | |
|
VS-80APF10-M3 | 11.7200 | |
7817 | 0.00000000 | Vishay General Semiconductor - Diodes Division | - | Tube | Active | Through Hole | TO-247-3 | 80APF10 | Standard | TO-247AC | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8541.10.0080 | 25 | Fast Recovery =< 500ns, > 200mA (Io) | 1000 V | 1.35 V @ 80 A | 480 ns | 100 µA @ 1000 V | -40°C ~ 150°C | 80A | - | ||
 |
VS-80EBU02HF4 | 4.6084 | |
2231 | 0.00000000 | Vishay General Semiconductor - Diodes Division | Automotive, AEC-Q101, FRED Pt® | Tube | Active | Chassis Mount | PowerTab® | 80EBU02 | Standard | PowerTab® | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | VS80EBU02HF4 | EAR99 | 8541.10.0080 | 25 | Fast Recovery =< 500ns, > 200mA (Io) | 200 V | 1.1 V @ 80 A | 40 ns | 50 µA @ 200 V | -55°C ~ 175°C | 80A | - | |
 |
VS-8ETH06-N3 | - | |
5820 | 0.00000000 | Vishay General Semiconductor - Diodes Division | FRED Pt® | Tube | Obsolete | Through Hole | TO-220-2 | 8ETH06 | Standard | TO-220AC | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | VS8ETH06N3 | EAR99 | 8541.10.0080 | 1,000 | Fast Recovery =< 500ns, > 200mA (Io) | 600 V | 2.4 V @ 8 A | 25 ns | 50 µA @ 600 V | -65°C ~ 175°C | 8A | - | |
 |
VS-8ETL06FP-N3 | 1.0959 | |
5180 | 0.00000000 | Vishay General Semiconductor - Diodes Division | FRED Pt® | Tube | Active | Through Hole | TO-220-2 Full Pack | 8ETL06 | Standard | TO-220-2 Full Pack | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | VS8ETL06FPN3 | EAR99 | 8541.10.0080 | 1,000 | Fast Recovery =< 500ns, > 200mA (Io) | 600 V | 2.4 V @ 8 A | 25 ns | 50 µA @ 600 V | -65°C ~ 175°C | 8A | - | |
|
VS-8ETX06FP-N3 | 1.7900 | |
50 | 0.00000000 | Vishay General Semiconductor - Diodes Division | - | Tube | Active | Through Hole | TO-220-2 Full Pack | 8ETX06 | Standard | TO-220-2 Full Pack | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8541.10.0080 | 50 | Fast Recovery =< 500ns, > 200mA (Io) | 600 V | 3 V @ 8 A | 17 ns | 50 µA @ 600 V | -65°C ~ 175°C | 8A | - | ||
|
VS-8EWF12S-M3 | 3.3300 | |
2 | 0.00000000 | Vishay General Semiconductor - Diodes Division | - | Tube | Active | Surface Mount | TO-252-3, DPak (2 Leads + Tab), SC-63 | 8EWF12 | Standard | TO-252, (D-Pak) | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | VS8EWF12SM3 | EAR99 | 8541.10.0080 | 75 | Fast Recovery =< 500ns, > 200mA (Io) | 1200 V | 1.3 V @ 8 A | 270 ns | 100 µA @ 1200 V | -40°C ~ 150°C | 8A | - | |
|
VS-8EWH06FNHM3 | 1.3015 | |
8409 | 0.00000000 | Vishay General Semiconductor - Diodes Division | Automotive, AEC-Q101, FRED Pt® | Tube | Active | Surface Mount | TO-252-3, DPak (2 Leads + Tab), SC-63 | 8EWH06 | Standard | TO-252, (D-Pak) | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | VS8EWH06FNHM3 | EAR99 | 8541.10.0080 | 3,000 | Fast Recovery =< 500ns, > 200mA (Io) | 600 V | 2.4 V @ 8 A | 25 ns | 50 µA @ 600 V | -55°C ~ 150°C | 8A | - | |
|
VS-8EWS12SPBF | - | |
8492 | 0.00000000 | Vishay General Semiconductor - Diodes Division | - | Tube | Obsolete | Surface Mount | TO-252-3, DPak (2 Leads + Tab), SC-63 | 8EWS12 | Standard | TO-252, (D-Pak) | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | VS8EWS12SPBF | EAR99 | 8541.10.0080 | 75 | Standard Recovery >500ns, > 200mA (Io) | 1200 V | 1.1 V @ 8 A | 50 µA @ 1200 V | -55°C ~ 150°C | 8A | - | ||
|
VS-8EWS16SPBF | - | |
8730 | 0.00000000 | Vishay General Semiconductor - Diodes Division | - | Tube | Obsolete | Surface Mount | TO-252-3, DPak (2 Leads + Tab), SC-63 | 8EWS16 | Standard | TO-252, (D-Pak) | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | VS8EWS16SPBF | EAR99 | 8541.10.0080 | 75 | Standard Recovery >500ns, > 200mA (Io) | 1600 V | 1.1 V @ 8 A | 50 µA @ 1600 V | -40°C ~ 150°C | 8A | - | ||
|
VS-APH3006HN3 | 1.8492 | |
2940 | 0.00000000 | Vishay General Semiconductor - Diodes Division | FRED Pt® | Tube | Active | Through Hole | TO-247-3 | APH3006 | Standard | TO-247AC | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | VSAPH3006HN3 | EAR99 | 8541.10.0080 | 500 | Standard Recovery >500ns, > 200mA (Io) | 600 V | 2.65 V @ 30 A | 30 µA @ 600 V | -65°C ~ 175°C | 30A | - | ||
|
VS-APU3006HN3 | 2.0302 | |
4334 | 0.00000000 | Vishay General Semiconductor - Diodes Division | Automotive, AEC-Q101, FRED Pt® | Tube | Active | Through Hole | TO-247-3 | APU3006 | Standard | TO-247AC | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | VSAPU3006HN3 | EAR99 | 8541.10.0080 | 500 | Fast Recovery =< 500ns, > 200mA (Io) | 600 V | 2 V @ 30 A | 45 ns | 30 µA @ 600 V | -40°C ~ 150°C | 30A | - | |
|
VS-APU6006-N3 | 3.2200 | |
45 | 0.00000000 | Vishay General Semiconductor - Diodes Division | FRED Pt® | Tube | Active | Through Hole | TO-247-3 | APU6006 | Standard | TO-247AC | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8541.10.0080 | 25 | Fast Recovery =< 500ns, > 200mA (Io) | 600 V | 2 V @ 30 A | 45 ns | 30 µA @ 600 V | -40°C ~ 150°C | 30A | - | ||
|
VS-EBU15006HF4 | 7.0278 | |
8045 | 0.00000000 | Vishay General Semiconductor - Diodes Division | Automotive, AEC-Q101, FRED Pt® | Tube | Active | Chassis Mount | PowerTab® | EBU15006 | Standard | PowerTab® | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | VSEBU15006HF4 | EAR99 | 8541.10.0080 | 25 | Fast Recovery =< 500ns, > 200mA (Io) | 600 V | 1.63 V @ 150 A | 100 ns | 8 µA @ 600 V | -55°C ~ 175°C | 150A | - | |
|
VS-HFA08TB120-N3 | - | |
5503 | 0.00000000 | Vishay General Semiconductor - Diodes Division | HEXFRED® | Tube | Obsolete | Through Hole | TO-220-2 | HFA08 | Standard | TO-220AC | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | VSHFA08TB120N3 | EAR99 | 8541.10.0080 | 1,000 | Fast Recovery =< 500ns, > 200mA (Io) | 1200 V | 3.3 V @ 8 A | 95 ns | 10 µA @ 1200 V | -55°C ~ 150°C | 8A | - | |
|
VS-MBRD320-M3 | 0.2764 | |
3920 | 0.00000000 | Vishay General Semiconductor - Diodes Division | - | Tube | Active | Surface Mount | TO-252-3, DPak (2 Leads + Tab), SC-63 | MBRD320 | Schottky | TO-252, (D-Pak) | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | VSMBRD320M3 | EAR99 | 8541.10.0080 | 3,000 | Fast Recovery =< 500ns, > 200mA (Io) | 20 V | 600 mV @ 3 A | 200 µA @ 20 V | -40°C ~ 150°C | 3A | 189pF @ 5V, 1MHz | ||
 |
VT1080SHM3/4W | - | |
2579 | 0.00000000 | Vishay General Semiconductor - Diodes Division | Automotive, AEC-Q101 | Tube | Obsolete | Through Hole | TO-220-3 | VT1080 | Schottky | TO-220-3 | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | VT1080SHM34W | EAR99 | 8541.10.0080 | 1,000 | Fast Recovery =< 500ns, > 200mA (Io) | 80 V | 810 mV @ 10 A | 600 µA @ 80 V | -55°C ~ 150°C | 10A | - | ||
 |
VS-16F120M | 11.4300 | |
9884 | 0.00000000 | Vishay General Semiconductor - Diodes Division | - | Tube | Active | Chassis, Stud Mount | DO-203AA, DO-4, Stud | 16F120 | Standard | DO-203AA (DO-4) | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8541.10.0080 | 100 | Fast Recovery =< 500ns, > 200mA (Io) | 1200 V | 1.23 V @ 50 A | 29 ns | -65°C ~ 175°C | 16A | - | |||
|
VS-16FL100S10 | - | |
9098 | 0.00000000 | Vishay General Semiconductor - Diodes Division | - | Tube | Active | Chassis, Stud Mount | DO-203AA, DO-4, Stud | 16FL100 | Standard | DO-203AA (DO-4) | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | VS16FL100S10 | EAR99 | 8541.10.0080 | 100 | Fast Recovery =< 500ns, > 200mA (Io) | 1000 V | 1.4 V @ 16 A | 500 ns | -65°C ~ 150°C | 16A | - | ||
|
VS-20ETF10FP-M3 | 2.1161 | |
4609 | 0.00000000 | Vishay General Semiconductor - Diodes Division | - | Tube | Active | Through Hole | TO-220-2 Full Pack | 20ETF10 | Standard | TO-220-2 Full Pack | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | VS20ETF10FPM3 | EAR99 | 8541.10.0080 | 1,000 | Fast Recovery =< 500ns, > 200mA (Io) | 1000 V | 1.31 V @ 20 A | 95 ns | 100 µA @ 1000 V | -40°C ~ 150°C | 20A | - | |
 |
VS-20ETS12-M3 | 2.8600 | |
2 | 0.00000000 | Vishay General Semiconductor - Diodes Division | - | Tube | Active | Through Hole | TO-220-2 | 20ETS12 | Standard | TO-220AC | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | VS20ETS12M3 | EAR99 | 8541.10.0080 | 50 | Standard Recovery >500ns, > 200mA (Io) | 1200 V | 1 V @ 10 A | 100 µA @ 1200 V | -40°C ~ 150°C | 20A | - | ||
|
VS-20ETS12SPBF | - | |
4045 | 0.00000000 | Vishay General Semiconductor - Diodes Division | - | Tube | Discontinued at SIC | Surface Mount | TO-263-3, D²Pak (2 Leads + Tab), TO-263AB | 20ETS12 | Standard | TO-263AB (D²PAK) | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | VS20ETS12SPBF | EAR99 | 8541.10.0080 | 50 | Standard Recovery >500ns, > 200mA (Io) | 1200 V | 1.1 V @ 20 A | 100 µA @ 1200 V | -40°C ~ 150°C | 20A | - | ||
|
VS-20ETS16PBF | - | |
7152 | 0.00000000 | Vishay General Semiconductor - Diodes Division | - | Tube | Discontinued at SIC | Through Hole | TO-220-3 | 20ETS16 | Standard | TO-220-3 | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | VS20ETS16PBF | EAR99 | 8541.10.0080 | 50 | Standard Recovery >500ns, > 200mA (Io) | 1600 V | 1.1 V @ 20 A | 100 µA @ 1600 V | -40°C ~ 150°C | 20A | - | ||
|
VS-20TQ035-N3 | - | |
4931 | 0.00000000 | Vishay General Semiconductor - Diodes Division | - | Tube | Obsolete | Through Hole | TO-220-2 | 20TQ035 | Schottky | TO-220AC | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | VS20TQ035N3 | EAR99 | 8541.10.0080 | 1,000 | Fast Recovery =< 500ns, > 200mA (Io) | 35 V | 570 mV @ 20 A | 2.7 mA @ 35 V | -55°C ~ 150°C | 20A | - | ||
|
VS-20TQ040SPBF | - | |
7195 | 0.00000000 | Vishay General Semiconductor - Diodes Division | - | Tube | Discontinued at SIC | Surface Mount | TO-263-3, D²Pak (2 Leads + Tab), TO-263AB | 20TQ040 | Schottky | TO-263AB (D²PAK) | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | VS20TQ040SPBF | EAR99 | 8541.10.0080 | 50 | Fast Recovery =< 500ns, > 200mA (Io) | 40 V | 570 mV @ 20 A | 2.7 mA @ 40 V | -55°C ~ 150°C | 20A | 1400pF @ 5V, 1MHz | ||
|
VS-30APF02-M3 | 3.4444 | |
5730 | 0.00000000 | Vishay General Semiconductor - Diodes Division | - | Tube | Active | Through Hole | TO-247-3 | 30APF02 | Schottky | TO-247AC | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | VS30APF02M3 | EAR99 | 8541.10.0080 | 500 | Fast Recovery =< 500ns, > 200mA (Io) | 100 V | 790 mV @ 3 A | 500 µA @ 100 V | -55°C ~ 175°C | 3A | 115pF @ 5V, 1MHz |
