Connectors, Interconnects(829794)

Image Product Number Pricing(USD) Quantity ECAD Quantity Available Weight(Kg) Mfr Series Package Product Status Operating Temperature Applications Mounting Type Features Base Product Number Termination Ingress Protection Style DataSheet RoHS Status Moisture Sensitivity Level (MSL) ECCN HTSUS Standard Package Connector Type Number of Rows Current Rating (Amps) Contact Material Material Flammability Rating Contact Type Pitch - Mating Number of Positions Row Spacing - Mating Number of Positions Loaded Shrouding Fastening Type Contact Length - Mating Contact Length - Post Overall Contact Length Insulation Height Contact Shape Contact Finish - Mating Contact Finish Thickness - Mating Contact Finish - Post Insulation Material Insulation Color Voltage Rating Mated Stacking Heights Contact Finish Thickness - Post
MTSW-150-10-S-S-130-RE Samtec Inc. MTSW-150-10-S-S-130-RE 10.7300
RFQ
 ECAD 8651 0.00000000 Samtec Inc. Flex Stack, MTSW Bulk Active -55°C ~ 125°C - Through Hole, Right Angle - MTSW-150 Solder - Board to Board or Cable download ROHS3 Compliant Not Applicable EAR99 8536.69.4040 1 Header, Cuttable 1 3A Phosphor Bronze UL94 V-0 Male Pin 0.100" (2.54mm) 50 - All Unshrouded Push-Pull 0.130" (3.30mm) 0.090" (2.29mm) - 0.119" (3.02mm) Square Gold 30.0µin (0.76µm) Tin Polyester, Glass Filled Black - - -
MTSW-150-10-S-S-550 Samtec Inc. MTSW-150-10-S-S-550 9.7600
RFQ
 ECAD 2878 0.00000000 Samtec Inc. Flex Stack, MTSW Bulk Active -55°C ~ 125°C - Through Hole - MTSW-150 Solder - Board to Board or Cable download ROHS3 Compliant Not Applicable EAR99 8536.69.4040 1 Header, Cuttable 1 3A Phosphor Bronze UL94 V-0 Male Pin 0.100" (2.54mm) 50 - All Unshrouded Push-Pull 0.550" (13.97mm) 0.180" (4.57mm) 0.830" (21.08mm) 0.100" (2.54mm) Square Gold 30.0µin (0.76µm) Tin Polyester, Glass Filled Black - - -
MTSW-150-10-S-T-555 Samtec Inc. MTSW-150-10-S-T-555 25.9700
RFQ
 ECAD 1089 0.00000000 Samtec Inc. Flex Stack, MTSW Bulk Active -55°C ~ 125°C - Through Hole - MTSW-150 Solder - Board to Board or Cable download ROHS3 Compliant Not Applicable EAR99 8536.69.4040 1 Header, Cuttable 3 3A Phosphor Bronze UL94 V-0 Male Pin 0.100" (2.54mm) 150 0.100" (2.54mm) All Unshrouded Push-Pull 0.555" (14.10mm) 0.175" (4.45mm) 0.830" (21.08mm) 0.100" (2.54mm) Square Gold 30.0µin (0.76µm) Tin Polyester, Glass Filled Black - - -
MTSW-150-11-G-D-750 Samtec Inc. MTSW-150-11-G-D-750 14.7500
RFQ
 ECAD 5652 0.00000000 Samtec Inc. Flex Stack, MTSW Bulk Active -55°C ~ 125°C - Through Hole - MTSW-150 Solder - Board to Board or Cable download ROHS3 Compliant Not Applicable EAR99 8536.69.4040 1 Header, Cuttable 2 3A Phosphor Bronze UL94 V-0 Male Pin 0.100" (2.54mm) 100 0.100" (2.54mm) All Unshrouded Push-Pull 0.750" (19.05mm) 0.080" (2.03mm) 0.930" (23.62mm) 0.100" (2.54mm) Square Gold 10.0µin (0.25µm) Gold Polyester, Glass Filled Black - - 3.00µin (0.076µm)
MTSW-150-11-G-S-345 Samtec Inc. MTSW-150-11-G-S-345 -
RFQ
 ECAD 9924 0.00000000 Samtec Inc. Flex Stack, MTSW Bulk Active -55°C ~ 125°C - Through Hole - MTSW-150 Solder - Board to Board or Cable download ROHS3 Compliant 1 (Unlimited) EAR99 8536.69.4040 1 Header, Cuttable 1 3A Phosphor Bronze UL94 V-0 Male Pin 0.100" (2.54mm) 50 - All Unshrouded Push-Pull 0.345" (8.76mm) 0.485" (12.32mm) 0.930" (23.62mm) 0.100" (2.54mm) Square Gold 10.0µin (0.25µm) Gold Polyester, Glass Filled Black - - 3.00µin (0.076µm)
MTSW-150-11-G-S-715 Samtec Inc. MTSW-150-11-G-S-715 8.0500
RFQ
 ECAD 9963 0.00000000 Samtec Inc. Flex Stack, MTSW Bulk Active -55°C ~ 125°C - Through Hole - MTSW-150 Solder - Board to Board or Cable download ROHS3 Compliant Not Applicable EAR99 8536.69.4040 1 Header, Cuttable 1 3A Phosphor Bronze UL94 V-0 Male Pin 0.100" (2.54mm) 50 - All Unshrouded Push-Pull 0.715" (18.16mm) 0.115" (2.92mm) 0.930" (23.62mm) 0.100" (2.54mm) Square Gold 10.0µin (0.25µm) Gold Polyester, Glass Filled Black - - 3.00µin (0.076µm)
MTSW-150-11-G-S-740 Samtec Inc. MTSW-150-11-G-S-740 8.0500
RFQ
 ECAD 8035 0.00000000 Samtec Inc. Flex Stack, MTSW Bulk Active -55°C ~ 125°C - Through Hole - MTSW-150 Solder - Board to Board or Cable download ROHS3 Compliant Not Applicable EAR99 8536.69.4040 1 Header, Cuttable 1 3A Phosphor Bronze UL94 V-0 Male Pin 0.100" (2.54mm) 50 - All Unshrouded Push-Pull 0.740" (18.80mm) 0.090" (2.29mm) 0.930" (23.62mm) 0.100" (2.54mm) Square Gold 10.0µin (0.25µm) Gold Polyester, Glass Filled Black - - 3.00µin (0.076µm)
MTSW-150-11-L-D-575-RA Samtec Inc. MTSW-150-11-L-D-575-RA 13.4000
RFQ
 ECAD 4696 0.00000000 Samtec Inc. Flex Stack, MTSW Bulk Active -55°C ~ 125°C - Through Hole, Right Angle - MTSW-150 Solder - Board to Board or Cable download ROHS3 Compliant Not Applicable EAR99 8536.69.4040 1 Header, Cuttable 2 3A Phosphor Bronze UL94 V-0 Male Pin 0.100" (2.54mm) 100 0.100" (2.54mm) All Unshrouded Push-Pull 0.575" (14.61mm) 0.090" (2.29mm) - 0.219" (5.56mm) Square Gold 10.0µin (0.25µm) Tin Polyester, Glass Filled Black - - -
MTSW-150-11-S-S-290-RA Samtec Inc. MTSW-150-11-S-S-290-RA 11.1700
RFQ
 ECAD 3057 0.00000000 Samtec Inc. Flex Stack, MTSW Bulk Active -55°C ~ 125°C - Through Hole, Right Angle - MTSW-150 Solder - Board to Board or Cable download ROHS3 Compliant Not Applicable EAR99 8536.69.4040 1 Header, Cuttable 1 3A Phosphor Bronze UL94 V-0 Male Pin 0.100" (2.54mm) 50 - All Unshrouded Push-Pull 0.290" (7.37mm) 0.090" (2.29mm) - 0.119" (3.02mm) Square Gold 30.0µin (0.76µm) Tin Polyester, Glass Filled Black - - -
MTSW-150-11-T-D-730 Samtec Inc. MTSW-150-11-T-D-730 -
RFQ
 ECAD 7565 0.00000000 Samtec Inc. Flex Stack, MTSW Bulk Active -55°C ~ 105°C - Through Hole - MTSW-150 Solder - Board to Board or Cable download ROHS3 Compliant 1 (Unlimited) EAR99 8536.69.4040 1 Header, Cuttable 2 3A Phosphor Bronze UL94 V-0 Male Pin 0.100" (2.54mm) 100 0.100" (2.54mm) All Unshrouded Push-Pull 0.730" (18.54mm) 0.100" (2.54mm) 0.930" (23.62mm) 0.100" (2.54mm) Square Tin - Tin Polyester, Glass Filled Black - - -
MTSW-150-24-G-D-230 Samtec Inc. MTSW-150-24-G-D-230 12.4400
RFQ
 ECAD 7205 0.00000000 Samtec Inc. Flex Stack, MTSW Bulk Active -55°C ~ 125°C - Through Hole - MTSW-150 Solder - Board to Board or Cable download ROHS3 Compliant Not Applicable EAR99 8536.69.4040 1 Header, Cuttable 2 3A Phosphor Bronze UL94 V-0 Male Pin 0.100" (2.54mm) 100 0.100" (2.54mm) All Unshrouded Push-Pull 0.230" (5.84mm) 0.150" (3.81mm) 0.480" (12.19mm) 0.100" (2.54mm) Square Gold 10.0µin (0.25µm) Gold Polyester, Glass Filled Black - - 3.00µin (0.076µm)
MTSW-150-24-L-D-024 Samtec Inc. MTSW-150-24-L-D-024 10.7600
RFQ
 ECAD 2287 0.00000000 Samtec Inc. Flex Stack, MTSW Bulk Active -55°C ~ 125°C - Through Hole - MTSW-150 Solder - Board to Board or Cable download ROHS3 Compliant Not Applicable EAR99 8536.69.4040 1 Header, Cuttable 2 3A Phosphor Bronze UL94 V-0 Male Pin 0.100" (2.54mm) 100 0.100" (2.54mm) All Unshrouded Push-Pull 0.024" (0.61mm) 0.356" (9.04mm) 0.480" (12.19mm) 0.100" (2.54mm) Square Gold 10.0µin (0.25µm) Tin Polyester, Glass Filled Black - - -
MTSW-150-24-L-S-255 Samtec Inc. MTSW-150-24-L-S-255 -
RFQ
 ECAD 8940 0.00000000 Samtec Inc. Flex Stack, MTSW Bulk Active -55°C ~ 125°C - Through Hole - MTSW-150 Solder - Board to Board or Cable download ROHS3 Compliant 1 (Unlimited) EAR99 8536.69.4040 1 Header, Cuttable 1 3A Phosphor Bronze UL94 V-0 Male Pin 0.100" (2.54mm) 50 - All Unshrouded Push-Pull 0.255" (6.48mm) 0.125" (3.18mm) 0.480" (12.19mm) 0.100" (2.54mm) Square Gold 10.0µin (0.25µm) Tin Polyester, Glass Filled Black - - -
MTSW-150-27-L-D-225 Samtec Inc. MTSW-150-27-L-D-225 -
RFQ
 ECAD 5167 0.00000000 Samtec Inc. Flex Stack, MTSW Bulk Active -55°C ~ 125°C - Through Hole - MTSW-150 Solder - Board to Board or Cable download ROHS3 Compliant 1 (Unlimited) EAR99 8536.69.4040 1 Header, Cuttable 2 3A Phosphor Bronze UL94 V-0 Male Pin 0.100" (2.54mm) 100 0.100" (2.54mm) All Unshrouded Push-Pull 0.225" (5.72mm) 1.005" (25.53mm) 1.330" (33.78mm) 0.100" (2.54mm) Square Gold 10.0µin (0.25µm) Tin Polyester, Glass Filled Black - - -
MTSW-150-28-G-T-940 Samtec Inc. MTSW-150-28-G-T-940 -
RFQ
 ECAD 4982 0.00000000 Samtec Inc. Flex Stack, MTSW Bulk Active -55°C ~ 125°C - Through Hole - MTSW-150 Solder - Board to Board or Cable download ROHS3 Compliant 1 (Unlimited) EAR99 8536.69.4040 1 Header, Cuttable 3 3A Phosphor Bronze UL94 V-0 Male Pin 0.100" (2.54mm) 150 0.100" (2.54mm) All Unshrouded Push-Pull 0.940" (23.88mm) 0.090" (2.29mm) 1.130" (28.70mm) 0.100" (2.54mm) Square Gold 10.0µin (0.25µm) Gold Polyester, Glass Filled Black - - 3.00µin (0.076µm)
MTSW-150-28-S-D-010 Samtec Inc. MTSW-150-28-S-D-010 -
RFQ
 ECAD 1094 0.00000000 Samtec Inc. Flex Stack, MTSW Bulk Active -55°C ~ 125°C - Through Hole - MTSW-150 Solder - Board to Board or Cable download ROHS3 Compliant 1 (Unlimited) EAR99 8536.69.4040 1 Header, Cuttable 2 3A Phosphor Bronze UL94 V-0 Male Pin 0.100" (2.54mm) 100 0.100" (2.54mm) All Unshrouded Push-Pull 0.010" (0.25mm) 1.020" (25.91mm) 1.130" (28.70mm) 0.100" (2.54mm) Square Gold 30.0µin (0.76µm) Tin Polyester, Glass Filled Black - - -
MTSW-150-28-S-D-225 Samtec Inc. MTSW-150-28-S-D-225 -
RFQ
 ECAD 6558 0.00000000 Samtec Inc. Flex Stack, MTSW Bulk Active -55°C ~ 125°C - Through Hole - MTSW-150 Solder - Board to Board or Cable download ROHS3 Compliant 1 (Unlimited) EAR99 8536.69.4040 1 Header, Cuttable 2 3A Phosphor Bronze UL94 V-0 Male Pin 0.100" (2.54mm) 100 0.100" (2.54mm) All Unshrouded Push-Pull 0.225" (5.72mm) 0.805" (20.45mm) 1.130" (28.70mm) 0.100" (2.54mm) Square Gold 30.0µin (0.76µm) Tin Polyester, Glass Filled Black - - -
MTSW-150-28-S-S-930-LL Samtec Inc. MTSW-150-28-S-S-930-LL 11.3400
RFQ
 ECAD 9781 0.00000000 Samtec Inc. Flex Stack, MTSW Bulk Active -55°C ~ 125°C - Through Hole - MTSW-150 Kinked Pin, Solder - Board to Board or Cable download ROHS3 Compliant Not Applicable EAR99 8536.69.4040 1 Header, Cuttable 1 3A Phosphor Bronze UL94 V-0 Male Pin 0.100" (2.54mm) 50 - All Unshrouded Push-Pull 0.930" (23.62mm) 0.100" (2.54mm) 1.130" (28.70mm) 0.100" (2.54mm) Square Gold 30.0µin (0.76µm) Tin Polyester, Glass Filled Black - - -
MTSW-150-28-T-S-510 Samtec Inc. MTSW-150-28-T-S-510 5.0000
RFQ
 ECAD 3616 0.00000000 Samtec Inc. Flex Stack, MTSW Bulk Active -55°C ~ 105°C - Through Hole - MTSW-150 Solder - Board to Board or Cable download ROHS3 Compliant Not Applicable EAR99 8536.69.4040 1 Header, Cuttable 1 3A Phosphor Bronze UL94 V-0 Male Pin 0.100" (2.54mm) 50 - All Unshrouded Push-Pull 0.510" (12.95mm) 0.520" (13.21mm) 1.130" (28.70mm) 0.100" (2.54mm) Square Tin - Tin Polyester, Glass Filled Black - - -
MTSW-202-07-G-S-048 Samtec Inc. MTSW-202-07-G-S-048 -
RFQ
 ECAD 5901 0.00000000 Samtec Inc. Flex Stack, MTSW Bulk Active -55°C ~ 125°C - Through Hole - MTSW-202 Solder - Board to Board or Cable download ROHS3 Compliant 1 (Unlimited) EAR99 8536.69.4040 1 Header, Cuttable 1 3A Phosphor Bronze UL94 V-0 Male Pin 0.200" (5.08mm) 2 - All Unshrouded Push-Pull 0.048" (1.22mm) 0.282" (7.16mm) 0.430" (10.92mm) 0.100" (2.54mm) Square Gold 10.0µin (0.25µm) Gold Polyester, Glass Filled Black - - 3.00µin (0.076µm)
MTSW-202-08-S-T-374 Samtec Inc. MTSW-202-08-S-T-374 -
RFQ
 ECAD 1733 0.00000000 Samtec Inc. Flex Stack, MTSW Bulk Active -55°C ~ 125°C - Through Hole - MTSW-202 Solder - Board to Board or Cable download ROHS3 Compliant 1 (Unlimited) EAR99 8536.69.4040 1 Header, Cuttable 3 3A Phosphor Bronze UL94 V-0 Male Pin 0.200" (5.08mm) 6 0.100" (2.54mm) All Unshrouded Push-Pull 0.374" (9.50mm) 0.056" (1.42mm) 0.530" (13.46mm) 0.100" (2.54mm) Square Gold 30.0µin (0.76µm) Tin Polyester, Glass Filled Black - - -
MTSW-202-09-T-S-500 Samtec Inc. MTSW-202-09-T-S-500 0.5200
RFQ
 ECAD 5606 0.00000000 Samtec Inc. Flex Stack, MTSW Bulk Active -55°C ~ 105°C - Through Hole - MTSW-202 Solder - Board to Board or Cable download ROHS3 Compliant Not Applicable EAR99 8536.69.4040 1 Header, Cuttable 1 3A Phosphor Bronze UL94 V-0 Male Pin 0.200" (5.08mm) 2 - All Unshrouded Push-Pull 0.500" (12.70mm) 0.130" (3.30mm) 0.730" (18.54mm) 0.100" (2.54mm) Square Tin - Tin Polyester, Glass Filled Black - - -
SFMC-102-L3-FM-D Samtec Inc. SFMC-102-L3-FM-D -
RFQ
 ECAD 4306 0.00000000 Samtec Inc. Tiger Eye™ SFMC Bulk Active -55°C ~ 125°C - Through Hole - SFMC-102 Solder - Board to Board or Cable download ROHS3 Compliant Not Applicable EAR99 8536.69.4040 1 Receptacle 2 2.9A per Contact Beryllium Copper UL94 V-0 Female Socket 0.050" (1.27mm) 4 0.050" (1.27mm) All Push-Pull 0.075" (1.91mm) 0.180" (4.57mm) Square Gold 3.00µin (0.076µm) Tin Liquid Crystal Polymer (LCP) Black - - -
MTSW-150-22-L-D-265-NA Samtec Inc. MTSW-150-22-L-D-265-NA -
RFQ
 ECAD 8135 0.00000000 Samtec Inc. Flex Stack, MTSW Bulk Active -55°C ~ 125°C - Through Hole, Right Angle - MTSW-150 Solder - Board to Board or Cable download ROHS3 Compliant 1 (Unlimited) EAR99 8536.69.4040 1 Header, Cuttable 2 3A Phosphor Bronze UL94 V-0 Male Pin 0.100" (2.54mm) 100 0.100" (2.54mm) All Unshrouded Push-Pull 0.265" (6.73mm) 0.090" (2.29mm) - 0.219" (5.56mm) Square Gold 10.0µin (0.25µm) Tin Polyester, Glass Filled Black - - -
MTSW-150-22-L-D-330-RA Samtec Inc. MTSW-150-22-L-D-330-RA -
RFQ
 ECAD 2370 0.00000000 Samtec Inc. Flex Stack, MTSW Bulk Active -55°C ~ 125°C - Through Hole, Right Angle - MTSW-150 Solder - Board to Board or Cable download ROHS3 Compliant 1 (Unlimited) EAR99 8536.69.4040 1 Header, Cuttable 2 3A Phosphor Bronze UL94 V-0 Male Pin 0.100" (2.54mm) 100 0.100" (2.54mm) All Unshrouded Push-Pull 0.330" (8.38mm) 0.090" (2.29mm) - 0.219" (5.56mm) Square Gold 10.0µin (0.25µm) Tin Polyester, Glass Filled Black - - -
MTSW-150-22-L-S-033 Samtec Inc. MTSW-150-22-L-S-033 -
RFQ
 ECAD 8872 0.00000000 Samtec Inc. Flex Stack, MTSW Bulk Active -55°C ~ 125°C - Through Hole - MTSW-150 Solder - Board to Board or Cable download ROHS3 Compliant 1 (Unlimited) EAR99 8536.69.4040 1 Header, Cuttable 1 3A Phosphor Bronze UL94 V-0 Male Pin 0.100" (2.54mm) 50 - All Unshrouded Push-Pull 0.033" (0.84mm) 0.497" (12.62mm) 0.630" (16.00mm) 0.100" (2.54mm) Square Gold 10.0µin (0.25µm) Tin Polyester, Glass Filled Black - - -
MTSW-150-22-L-S-400 Samtec Inc. MTSW-150-22-L-S-400 5.9800
RFQ
 ECAD 1342 0.00000000 Samtec Inc. Flex Stack, MTSW Bulk Active -55°C ~ 125°C - Through Hole - MTSW-150 Solder - Board to Board or Cable download ROHS3 Compliant Not Applicable EAR99 8536.69.4040 1 Header, Cuttable 1 3A Phosphor Bronze UL94 V-0 Male Pin 0.100" (2.54mm) 50 - All Unshrouded Push-Pull 0.400" (10.16mm) 0.130" (3.30mm) 0.630" (16.00mm) 0.100" (2.54mm) Square Gold 10.0µin (0.25µm) Tin Polyester, Glass Filled Black - - -
MTSW-150-08-T-S-335 Samtec Inc. MTSW-150-08-T-S-335 3.6600
RFQ
 ECAD 1722 0.00000000 Samtec Inc. Flex Stack, MTSW Bulk Active -55°C ~ 105°C - Through Hole - MTSW-150 Solder - Board to Board or Cable download ROHS3 Compliant Not Applicable EAR99 8536.69.4040 1 Header, Cuttable 1 3A Phosphor Bronze UL94 V-0 Male Pin 0.100" (2.54mm) 50 - All Unshrouded Push-Pull 0.335" (8.51mm) 0.095" (2.41mm) 0.530" (13.46mm) 0.100" (2.54mm) Square Tin - Tin Polyester, Glass Filled Black - - -
MTSW-150-09-G-D-090 Samtec Inc. MTSW-150-09-G-D-090 -
RFQ
 ECAD 2255 0.00000000 Samtec Inc. Flex Stack, MTSW Bulk Active -55°C ~ 125°C - Through Hole - MTSW-150 Solder - Board to Board or Cable download ROHS3 Compliant 1 (Unlimited) EAR99 8536.69.4040 1 Header, Cuttable 2 3A Phosphor Bronze UL94 V-0 Male Pin 0.100" (2.54mm) 100 0.100" (2.54mm) All Unshrouded Push-Pull 0.090" (2.29mm) 0.540" (13.72mm) 0.730" (18.54mm) 0.100" (2.54mm) Square Gold 10.0µin (0.25µm) Gold Polyester, Glass Filled Black - - 3.00µin (0.076µm)
MTSW-150-12-S-Q-200 Samtec Inc. MTSW-150-12-S-Q-200 -
RFQ
 ECAD 7711 0.00000000 Samtec Inc. Flex Stack, MTSW Bulk Active -55°C ~ 125°C - Through Hole - MTSW-150 Solder - Board to Board or Cable download ROHS3 Compliant 1 (Unlimited) EAR99 8536.69.4040 1 Header, Cuttable 2 3A Phosphor Bronze UL94 V-0 Male Pin 0.100" (2.54mm) 100 0.200" (5.08mm) All Unshrouded Push-Pull 0.200" (5.08mm) 0.730" (18.54mm) 1.030" (26.16mm) 0.100" (2.54mm) Square Gold 30.0µin (0.76µm) Tin Polyester, Glass Filled Black - - -
