Headers, Plugs and Sockets(86764)
| Image | Product Number | Pricing(USD) | Quantity | ECAD | Quantity Available | Weight(Kg) | Mfr | Series | Package | Product Status | Operating Temperature | Mounting Type | Type | Features | Base Product Number | Color | Ingress Protection | Termination Style | DataSheet | RoHS Status | Moisture Sensitivity Level (MSL) | REACH Status | ECCN | HTSUS | Standard Package | Pitch | Contact Material | Housing Material | Material Flammability Rating | Number of Positions | Insulation Height | Wire Gauge or Range - AWG | Wire Gauge or Range - mm² | Screw Size | Positions Per Level | Number of Levels | Header Orientation | Plug Wire Entry | Current - IEC | Current - UL | Voltage - UL | Contact Mating Finish | Torque - Screw | Wire Strip Length | Contact Tail Length |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
TS23515D0000G | 3.8401 |  |
5454 | 0.00000000 | Amphenol Anytek | TS | Bulk | Active | -40°C ~ 115°C | Free Hanging (In-Line) | Plug, Female Sockets | Mating Flange, Retention Latches (Non-Wire Side) | TS23 | Green | - | Screw - Leaf Spring, Wire Guard | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8536.69.8000 | 2,000 | 0.200" (5.08mm) | Phosphor Bronze | Thermoplastic | UL94 V-0 | 23 | 1.024" (26.01mm) | 12-24 AWG | 0.34-2.5mm² | M3 | 23 | 1 | - | 270° | - | 15 A | 300 V | Tin | 0.4 Nm (3.5 Lb-In) | 6-7mm | - | |
|
TS24515C0000G | 4.1491 | |
8705 | 0.00000000 | Amphenol Anytek | TS | Bulk | Active | -40°C ~ 115°C | Free Hanging (In-Line) | Plug, Female Sockets | Mating Flange, Retention Latches (Wire Side) | TS24 | Green | - | Screw - Leaf Spring, Wire Guard | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8536.69.8000 | 2,000 | 0.200" (5.08mm) | Phosphor Bronze | Thermoplastic | UL94 V-0 | 24 | 1.024" (26.01mm) | 12-24 AWG | 0.34-2.5mm² | M3 | 24 | 1 | - | 90° | - | 15 A | 300 V | Tin | 0.4 Nm (3.5 Lb-In) | 6-7mm | - | |
|
TS24715C0000G | 4.3114 | |
3048 | 0.00000000 | Amphenol Anytek | TS | Bulk | Active | -40°C ~ 115°C | Free Hanging (In-Line) | Plug, Female Sockets | Mating Flange, Retention Latches (Wire Side) | TS24 | Green | - | Screw - Leaf Spring, Wire Guard | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8536.69.8000 | 2,000 | 0.197" (5.00mm) | Phosphor Bronze | Thermoplastic | UL94 V-0 | 24 | 1.024" (26.01mm) | 12-24 AWG | 0.34-2.5mm² | M3 | 24 | 1 | - | 90° | - | 15 A | 300 V | Tin | 0.4 Nm (3.5 Lb-In) | 6-7mm | - | |
|
TT0341500000G | 0.3363 | |
3177 | 0.00000000 | Amphenol Anytek | TT | Bulk | Active | -40°C ~ 115°C | Free Hanging (In-Line) | Plug for Unshrouded Header | Interlocking (Side) | TT03 | Green | - | Screw - Rising Cage Clamp | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8536.69.8000 | 1,620 | 0.150" (3.81mm) | Phosphor Bronze | Thermoplastic | UL94 V-0 | 3 | 0.441" (11.20mm) | 16-28 AWG | - | M2 | 3 | 1 | - | 90° | - | 10 A | 300 V | Tin | 0.2 Nm (1.7 Lb-In) | 5-6mm | - | |
|
TT0441500000G | 0.4320 | |
1700 | 0.00000000 | Amphenol Anytek | TT | Bulk | Active | -40°C ~ 115°C | Free Hanging (In-Line) | Plug for Unshrouded Header | Interlocking (Side) | TT04 | Green | - | Screw - Rising Cage Clamp | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8536.69.8000 | 2,000 | 0.150" (3.81mm) | Phosphor Bronze | Thermoplastic | UL94 V-0 | 4 | 0.441" (11.20mm) | 16-28 AWG | - | M2 | 4 | 1 | - | 90° | - | 10 A | 300 V | Tin | 0.2 Nm (1.7 Lb-In) | 5-6mm | - | |
|
TT0601800000G | 0.8236 | |
5467 | 0.00000000 | Amphenol Anytek | TT | Bulk | Active | -40°C ~ 115°C | Free Hanging (In-Line) | Plug for Unshrouded Header | Interlocking (Side) | TT06 | Gray | - | Screw - Rising Cage Clamp | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8536.69.8000 | 2,200 | 0.197" (5.00mm) | Phosphor Bronze | Thermoplastic | UL94 V-0 | 6 | 0.449" (11.40mm) | 16-22 AWG | - | M3 | 6 | 1 | - | 90° | - | 10 A | 300 V | Gold | 0.2 Nm (1.7 Lb-In) | 5-7mm | - | |
|
TT0601810000G | 0.7390 | |
6224 | 0.00000000 | Amphenol Anytek | TT | Bulk | Active | -40°C ~ 115°C | Free Hanging (In-Line) | Plug for Unshrouded Header | - | TT06 | Gray | - | Screw - Rising Cage Clamp | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8536.69.8000 | 2,240 | 0.197" (5.00mm) | Phosphor Bronze | Thermoplastic | UL94 V-0 | 6 | 0.449" (11.40mm) | 16-22 AWG | - | M3 | 6 | 1 | - | 90° | - | 10 A | 300 V | Gold | 0.2 Nm (1.7 Lb-In) | 5-6mm | - | |
|
TT1001800000G | 1.3209 | |
8989 | 0.00000000 | Amphenol Anytek | TT | Bulk | Active | -40°C ~ 115°C | Free Hanging (In-Line) | Plug for Unshrouded Header | Interlocking (Side) | TT10 | Gray | - | Screw - Rising Cage Clamp | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8536.69.8000 | 2,090 | 0.197" (5.00mm) | Phosphor Bronze | Thermoplastic | UL94 V-0 | 10 | 0.449" (11.40mm) | 16-22 AWG | - | M3 | 10 | 1 | - | 90° | - | 10 A | 300 V | Gold | 0.2 Nm (1.7 Lb-In) | 5-7mm | - | |
|
TT1141500000G | 1.1044 | |
2611 | 0.00000000 | Amphenol Anytek | TT | Bulk | Active | -40°C ~ 115°C | Free Hanging (In-Line) | Plug for Unshrouded Header | Interlocking (Side) | TT11 | Green | - | Screw - Rising Cage Clamp | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8536.69.8000 | 2,100 | 0.150" (3.81mm) | Phosphor Bronze | Thermoplastic | UL94 V-0 | 11 | 0.441" (11.20mm) | 16-28 AWG | - | M2 | 11 | 1 | - | 90° | - | 10 A | 300 V | Tin | 0.2 Nm (1.7 Lb-In) | 5-6mm | - | |
|
TT1221500000G | 1.1862 | |
8576 | 0.00000000 | Amphenol Anytek | TT | Bulk | Active | -40°C ~ 115°C | Free Hanging (In-Line) | Plug for Unshrouded Header | Interlocking (Side) | TT12 | Green | - | Screw - Rising Cage Clamp | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8536.69.8000 | 2,100 | 0.138" (3.50mm) | Phosphor Bronze | Thermoplastic | UL94 V-0 | 12 | 0.441" (11.20mm) | 16-28 AWG | - | M2 | 12 | 1 | - | 90° | - | 10 A | 300 V | Tin | 0.2 Nm (1.7 Lb-In) | 5-6mm | - | |
|
TT1441500000G | 1.3537 | |
5608 | 0.00000000 | Amphenol Anytek | TT | Bulk | Active | -40°C ~ 115°C | Free Hanging (In-Line) | Plug for Unshrouded Header | Interlocking (Side) | TT14 | Green | - | Screw - Rising Cage Clamp | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8536.69.8000 | 2,100 | 0.150" (3.81mm) | Phosphor Bronze | Thermoplastic | UL94 V-0 | 14 | 0.441" (11.20mm) | 16-28 AWG | - | M2 | 14 | 1 | - | 90° | - | 10 A | 300 V | Tin | 0.2 Nm (1.7 Lb-In) | 5-6mm | - | |
|
TT2441500000G | 2.3214 | |
9386 | 0.00000000 | Amphenol Anytek | TT | Bulk | Active | -40°C ~ 115°C | Free Hanging (In-Line) | Plug for Unshrouded Header | Interlocking (Side) | TT24 | Green | - | Screw - Rising Cage Clamp | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8536.69.8000 | 1,960 | 0.150" (3.81mm) | Phosphor Bronze | Thermoplastic | UL94 V-0 | 24 | 0.441" (11.20mm) | 16-28 AWG | - | M2 | 24 | 1 | - | 90° | - | 10 A | 300 V | Tin | 0.2 Nm (1.7 Lb-In) | 5-6mm | - | |
|
OQ1954010300G | 0.8324 | |
1189 | 0.00000000 | Amphenol Anytek | OQ | Bulk | Active | -40°C ~ 115°C | Through Hole | Header, Male Pins, Shrouded (4 Side) | Locking Ramp | OQ19 | Black | - | Solder | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8536.69.4040 | 3,000 | 0.200" (5.08mm) | Copper | Thermoplastic | UL94 V-0 | 19 | 0.335" (8.51mm) | - | - | - | 19 | 1 | 90°, Right Angle | - | - | 20 A | 300 V | Tin | - | - | 0.138" (3.50mm) | |
|
OQ1954810300G | 0.8324 | |
4495 | 0.00000000 | Amphenol Anytek | OQ | Bulk | Active | -40°C ~ 115°C | Through Hole | Header, Male Pins, Shrouded (4 Side) | Locking Ramp | OQ19 | Gray | - | Solder | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8536.69.4040 | 3,000 | 0.200" (5.08mm) | Copper | Thermoplastic | UL94 V-0 | 19 | 0.335" (8.51mm) | - | - | - | 19 | 1 | 90°, Right Angle | - | - | 20 A | 300 V | Tin | - | - | 0.138" (3.50mm) | |
|
OQ1970800000G | 0.7786 | |
1386 | 0.00000000 | Amphenol Anytek | OQ | Bulk | Active | -40°C ~ 115°C | Through Hole | Header, Male Pins, Shrouded (2 Side) | - | OQ19 | Green | - | Solder | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8536.69.4040 | 3,060 | 0.197" (5.00mm) | Copper | Thermoplastic | UL94 V-0 | 19 | 0.472" (12.00mm) | - | - | - | 19 | 1 | Vertical | - | - | 20 A | 300 V | Tin | - | - | 0.157" (4.00mm) | |
|
OQ1975010000G | 1.3148 | |
9418 | 0.00000000 | Amphenol Anytek | OQ | Bulk | Active | -40°C ~ 115°C | Through Hole | Header, Male Pins, Shrouded (4 Side) | Mating Flange | OQ19 | Black | - | Solder | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8536.69.4040 | 3,000 | 0.197" (5.00mm) | Copper | Thermoplastic | UL94 V-0 | 19 | 0.335" (8.51mm) | - | - | - | 19 | 1 | 90°, Right Angle | - | - | 20 A | 300 V | Tin | - | - | 0.138" (3.50mm) | |
|
OQ2053000000G | 0.8246 | |
9728 | 0.00000000 | Amphenol Anytek | OQ | Bulk | Active | -40°C ~ 115°C | Through Hole | Header, Male Pins, Shrouded (2 Side) | - | OQ20 | Black | - | Solder | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8536.69.4040 | 3,060 | 0.200" (5.08mm) | Copper | Thermoplastic | UL94 V-0 | 20 | 0.472" (12.00mm) | - | - | - | 20 | 1 | Vertical | - | - | 20 A | 300 V | Tin | - | - | 0.157" (4.00mm) | |
|
OQ2054800000G | 0.8246 | |
9458 | 0.00000000 | Amphenol Anytek | OQ | Bulk | Active | -40°C ~ 115°C | Through Hole | Header, Male Pins, Shrouded (4 Side) | - | OQ20 | Gray | - | Solder | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8536.69.4040 | 3,040 | 0.200" (5.08mm) | Copper | Thermoplastic | UL94 V-0 | 20 | 0.472" (12.00mm) | - | - | - | 20 | 1 | Vertical | - | - | 20 A | 300 V | Tin | - | - | 0.157" (4.00mm) | |
|
OQ2071810300G | 0.9296 | |
3531 | 0.00000000 | Amphenol Anytek | OQ | Bulk | Active | -40°C ~ 115°C | Through Hole | Header, Male Pins, Shrouded (4 Side) | Locking Ramp | OQ20 | Green | - | Solder | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8536.69.4040 | 3,010 | 0.197" (5.00mm) | Copper | Thermoplastic | UL94 V-0 | 2 | 0.335" (8.51mm) | - | - | - | 2 | 1 | 90°, Right Angle | - | - | 20 A | 300 V | Tin | - | - | - | |
|
OQ2115810000G | 1.1226 | |
9176 | 0.00000000 | Amphenol Anytek | OQ | Bulk | Active | -40°C ~ 115°C | Through Hole | Header, Male Pins, Shrouded (4 Side) | Mating Flange | OQ21 | Gray | - | Solder | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8536.69.4040 | 3,000 | 0.138" (3.50mm) | Copper | Thermoplastic | UL94 V-0 | 21 | 0.283" (7.19mm) | - | - | - | 21 | 1 | 90°, Right Angle | - | - | 10 A | 300 V | Tin | - | - | 0.138" (3.50mm) | |
|
OQ2135800000G | 1.2631 | |
7661 | 0.00000000 | Amphenol Anytek | OQ | Bulk | Active | -40°C ~ 115°C | Through Hole | Header, Male Pins, Shrouded (4 Side) | Mating Flange | OQ21 | Gray | - | Solder | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8536.69.4040 | 3,105 | 0.150" (3.81mm) | Copper | Thermoplastic | UL94 V-0 | 21 | 0.362" (9.20mm) | - | - | - | 21 | 1 | Vertical | - | - | 10 A | 300 V | Tin | - | - | 0.138" (3.50mm) | |
|
OQ2154810300G | 0.9204 | |
2851 | 0.00000000 | Amphenol Anytek | OQ | Bulk | Active | -40°C ~ 115°C | Through Hole | Header, Male Pins, Shrouded (4 Side) | Locking Ramp | OQ21 | Gray | - | Solder | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8536.69.4040 | 3,010 | 0.200" (5.08mm) | Copper | Thermoplastic | UL94 V-0 | 21 | 0.335" (8.51mm) | - | - | - | 21 | 1 | 90°, Right Angle | - | - | 20 A | 300 V | Tin | - | - | 0.138" (3.50mm) | |
|
OQ2171000300G | 0.9139 | |
4843 | 0.00000000 | Amphenol Anytek | OQ | Bulk | Active | -40°C ~ 115°C | Through Hole | Header, Male Pins, Shrouded (4 Side) | Locking Ramp | OQ21 | Black | - | Solder | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8536.69.4040 | 3,040 | 0.197" (5.00mm) | Copper | Thermoplastic | UL94 V-0 | 21 | 0.472" (12.00mm) | - | - | - | 21 | 1 | Vertical | - | - | 20 A | 300 V | Tin | - | - | 0.157" (4.00mm) | |
|
OQ2175000000G | 1.3702 | |
6705 | 0.00000000 | Amphenol Anytek | OQ | Bulk | Active | -40°C ~ 115°C | Through Hole | Header, Male Pins, Shrouded (4 Side) | Mating Flange | OQ21 | Black | - | Solder | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8536.69.4040 | 3,040 | 0.197" (5.00mm) | Copper | Thermoplastic | UL94 V-0 | 21 | 0.472" (12.00mm) | - | - | - | 21 | 1 | Vertical | - | - | 20 A | 300 V | Tin | - | - | 0.157" (4.00mm) | |
|
OQ21B1810000G | 1.2040 | |
7456 | 0.00000000 | Amphenol Anytek | OQ | Bulk | Active | -40°C ~ 115°C | Through Hole | Header, Male Pins, Shrouded (4 Side) | - | OQ21 | Gray | - | Solder | - | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8536.69.4040 | 3,055 | 0.098" (2.50mm) | Copper | Thermoplastic | UL94 V-0 | 21 | 0.319" (8.10mm) | - | - | - | 21 | 1 | 90°, Right Angle | - | - | 4 A | 150 V | Tin | - | - | 0.150" (3.81mm) | |
|
OQ2212010000G | 0.8443 | |
5932 | 0.00000000 | Amphenol Anytek | OQ | Bulk | Active | -40°C ~ 115°C | Through Hole | Header, Male Pins, Shrouded (4 Side) | - | OQ22 | Black | - | Solder | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8536.69.4040 | 3,120 | 0.138" (3.50mm) | Copper | Thermoplastic | UL94 V-0 | 22 | 0.283" (7.19mm) | - | - | - | 22 | 1 | 90°, Right Angle | - | - | 10 A | 300 V | Tin | - | - | 0.138" (3.50mm) | |
|
OQ2253810000G | 0.9756 | |
9720 | 0.00000000 | Amphenol Anytek | OQ | Bulk | Active | -40°C ~ 115°C | Through Hole | Header, Male Pins, Shrouded (2 Side) | - | OQ22 | Gray | - | Solder | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8536.69.4040 | 3,055 | 0.200" (5.08mm) | Copper | Thermoplastic | UL94 V-0 | 22 | 0.335" (8.51mm) | - | - | - | 22 | 1 | 90°, Right Angle | - | - | 20 A | 300 V | Tin | - | - | 0.138" (3.50mm) | |
|
OQ2255810000G | 1.4513 | |
5798 | 0.00000000 | Amphenol Anytek | OQ | Bulk | Active | -40°C ~ 115°C | Through Hole | Header, Male Pins, Shrouded (4 Side) | Mating Flange | OQ22 | Gray | - | Solder | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8536.69.4040 | 3,010 | 0.200" (5.08mm) | Copper | Thermoplastic | UL94 V-0 | 2 | 0.335" (8.51mm) | - | - | - | 22 | 1 | 90°, Right Angle | - | - | 20 A | 300 V | Tin | - | - | 0.138" (3.50mm) | |
|
OQ2270810000G | 0.9690 | |
4946 | 0.00000000 | Amphenol Anytek | OQ | Bulk | Active | -40°C ~ 115°C | Through Hole | Header, Male Pins, Shrouded (2 Side) | - | OQ22 | Gray | - | Solder | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8536.69.4040 | 3,000 | 0.197" (5.00mm) | Copper | Thermoplastic | UL94 V-0 | 22 | 0.335" (8.51mm) | - | - | - | 22 | 1 | 90°, Right Angle | - | - | 20 A | 300 V | Tin | - | - | 0.138" (3.50mm) | |
|
OQ22B1800000G | 1.1988 | |
1556 | 0.00000000 | Amphenol Anytek | OQ | Bulk | Active | -40°C ~ 115°C | Through Hole | Header, Male Pins, Shrouded (4 Side) | - | OQ22 | Gray | - | Solder | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8536.69.4040 | 3,240 | 0.098" (2.50mm) | Copper | Thermoplastic | UL94 V-0 | 22 | 0.398" (10.11mm) | - | - | - | 22 | 1 | Vertical | - | - | 4 A | 150 V | Tin | - | - | 0.138" (3.50mm) |
