Headers, Plugs and Sockets(86784)
| Image | Product Number | Pricing(USD) | Quantity | ECAD | Quantity Available | Weight(Kg) | Mfr | Series | Package | Product Status | Operating Temperature | Mounting Type | Type | Features | Base Product Number | Color | Ingress Protection | Termination Style | DataSheet | RoHS Status | Moisture Sensitivity Level (MSL) | REACH Status | Other Names | ECCN | HTSUS | Standard Package | Pitch | Contact Material | Housing Material | Material Flammability Rating | Number of Positions | Insulation Height | Wire Gauge or Range - AWG | Wire Gauge or Range - mm² | Screw Size | Positions Per Level | Number of Levels | Header Orientation | Plug Wire Entry | Current - IEC | Current - UL | Voltage - UL | Contact Mating Finish | Torque - Screw | Wire Strip Length | Contact Tail Length | Voltage - IEC |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
0395325003 | 1.1200 |  |
106 | 0.00000000 | Molex | Eurostyle ESE 39532 | Bulk | Active | -40°C ~ 105°C | Through Hole | Header, Male Pins, Shrouded (2 Side) | - | 039532 | Green | - | Solder | download | ROHS3 Compliant | 1 (Unlimited) | EAR99 | 8536.69.4040 | 760 | 0.200" (5.08mm) | Brass | Polyamide (PA66), Nylon 6/6 | UL94 V-0 | 3 | 0.327" (8.30mm) | - | - | - | 3 | 1 | 90°, Right Angle | - | - | 15 A | 300 V | Tin | - | - | 0.150" (3.81mm) | ||||
 |
231-739/001-000 | 4.9200 | |
2808 | 0.00000000 | WAGO Corporation | MCSMIDI Classic | Box | Active | -60°C ~ 100°C | Through Hole | Header, Male Pins, Shrouded (4 Side) | - | Orange | - | Solder | download | ROHS3 Compliant | 1 (Unlimited) | EAR99 | 8536.90.4000 | 1 | 0.300" (7.62mm) | Electrolytic Copper | Polyamide (PA66), Nylon 6/6 | UL94 V-0 | 9 | 0.472" (12.00mm) | - | - | - | 9 | 1 | Vertical | - | 12A | 10 A | 600 V | Tin | - | - | 0.197" (5.00mm) | 1 kV | ||||
 |
1703490000 | - | |
6748 | 0.00000000 | Weidmüller | Omnimate BL | Bulk | Obsolete | -20°C ~ 100°C | Free Hanging (In-Line) | Plug, Female Sockets | Retention Latches (Non-Wire Side) | Black | - | Screw - Clamping Yoke (Tension Sleeve) | - | Not Applicable | REACH Unaffected | EAR99 | 8536.69.4040 | 50 | 0.300" (7.62mm) | Copper Alloy | Polybutylene Terephthalate (PBT) | UL94 V-0 | 7 | 0.551" (14.00mm) | 12-26 AWG | 0.08-2.5mm² | M2.5 | 7 | 1 | - | 270° | 13A | 15 A | 300 V | Tin | 0.4-0.5 Nm (3.5-4.4 Lb-In) | 7mm | - | 500 V | ||||
 |
VF2450510000G | 1.5270 | |
5719 | 0.00000000 | Amphenol Anytek | VF | Bulk | Active | -40°C ~ 115°C | Through Hole | Header, Male Pins, Shrouded (2 Side) | - | VF24 | Green | - | Solder | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8536.69.4040 | 2,016 | 0.200" (5.08mm) | Copper | Thermoplastic | UL94 V-0 | 24 | 0.866" (22.00mm) | - | - | - | 12 | 2 | 90°, Right Angle | - | - | 10 A | 300 V | Tin | - | - | 0.157" (4.00mm) | |||
 |
2020-202/122-000 | 10.0400 | |
6216 | 0.00000000 | WAGO Corporation | X-COM® S-Mini | Box | Active | - | Free Hanging (In-Line) | Plug, Female Sockets | Lever Actuated | Gray | - | Screwless - Push-In Spring | download | ROHS3 Compliant | 1 (Unlimited) | EAR99 | 8536.90.4000 | 1 | 0.138" (3.50mm) | Copper | Polyamide (PA66), Nylon 6/6 | UL94 V-0 | 2 (Mate), 4 (Input) | 1.071" (27.20mm) | 16-24 AWG | 0.14-1.5mm² | - | 2 (Mate), 4 (Input) | 1 (Mate), 2 (Input) | - | 180° | 13.5A | 15 A | 300 V | - | - | 9-11mm | - | 500 V | ||||
|
1900044 | - | |
1874 | 0.00000000 | Phoenix Contact | COMBICON EMSTBA | Bulk | Obsolete | - | Through Hole | Header, Male Pins, Shrouded (4 Side) | - | Green | - | Press-Fit | download | RoHS Compliant | 1 (Unlimited) | EMSTBA 2 5/22-G | EAR99 | 8536.69.4040 | 50 | 0.197" (5.00mm) | - | Polybutylene Terephthalate (PBT) | UL94 V-0 | 22 | 0.339" (8.61mm) | - | - | - | 22 | 1 | 90°, Right Angle | - | 12A | 15 A | 300 V | Tin | - | - | 0.165" (4.19mm) | 400 V | |||
|
1876710000 | - | |
8791 | 0.00000000 | Weidmüller | Omnimate SL | Tape & Reel (TR) | Obsolete | -50°C ~ 100°C | Through Hole | Header, Male Pins, Shrouded (4 Side) | Mating Flange, Solder Retention | Black | - | Solder | - | RoHS Compliant | 1 (Unlimited) | REACH Unaffected | SL-SMT5.08/4/270FL3.2SR | EAR99 | 8536.69.4040 | 350 | 0.200" (5.08mm) | Copper Alloy | Liquid Crystal Polymer (LCP), Glass Filled | UL94 V-0 | 4 | 0.335" (8.51mm) | - | - | - | 4 | 1 | 90°, Right Angle, Under Board | - | 27.5A | 18.5 A | 300 V | Tin | - | - | 0.126" (3.20mm) | 400 V | ||
|
282964-2 | 0.4397 | |
1570 | 0.00000000 | TE Connectivity AMP Connectors | Buchanan | Bulk | Active | -40°C ~ 110°C | Through Hole | Header, Male Pins, Shrouded (4 Side) | - | 282964 | Green | - | Solder | download | RoHS Compliant | 1 (Unlimited) | Vendor Undefined | EAR99 | 8536.69.4040 | 1,600 | 0.295" (7.50mm) | Copper Alloy | Polyamide (PA66), Nylon 6/6 | UL94 V-0 | 2 | 0.472" (12.00mm) | - | - | - | 2 | 1 | Vertical | - | - | 15 A | 300 V | Tin | - | - | 0.138" (3.50mm) | |||
|
5452149 | 3.6568 | |
3950 | 0.00000000 | Phoenix Contact | BCH | Bulk | Active | - | Through Hole | Header, Male Pins, Shrouded (4 Side) | - | Black | - | Solder | download | RoHS Compliant | 1 (Unlimited) | BCH-500VS-21 BK | EAR99 | 8536.69.4040 | 100 | 0.197" (5.00mm) | - | - | - | 21 | 0.472" (12.00mm) | - | - | - | 21 | 1 | Vertical | - | 12A | 15 A | 300 V | Tin | - | - | 0.154" (3.90mm) | 320 V | |||
|
1699020000 | - | |
2174 | 0.00000000 | Weidmüller | Omnimate SL | Bulk | Obsolete | -50°C ~ 130°C | Through Hole | Header, Male Pins, Shrouded (4 Side) | - | Black | - | Solder | - | Not Applicable | REACH Unaffected | EAR99 | 8536.69.4040 | 10 | 0.138" (3.50mm) | Copper Alloy | Polybutylene Terephthalate (PBT) | UL94 V-0 | 34 | 0.953" (24.20mm) | - | - | - | 17 | 2 | Vertical | - | 12A | 10 A | 300 V | Tin | - | - | 0.177" (4.50mm) | 125 V | ||||
|
OSTOQ095451 | 0.7435 | |
4135 | 0.00000000 | On Shore Technology Inc. | OSTOQ | Bulk | Active | -40°C ~ 115°C | Solder | Header, Male Pins, Shrouded (4 Side) | - | OSTOQ09 | - | - | - | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8536.69.4040 | 1 | 0.200" (5.08mm) | - | Thermoplastic | - | 9 | 0.157" (4.00mm) | - | - | - | 9 | 1 | 90°, Right Angle | - | - | 300 V | Tin | - | - | 0.157" (4.00mm) | ||||
 |
OSTTS08315A | 3.8500 | |
137 | 0.00000000 | On Shore Technology Inc. | OSTTS | Bulk | Active | -30°C ~ 105°C | Free Hanging (In-Line) | Plug, Female Sockets | - | OSTTS08 | Green | - | Screw | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8536.69.8000 | 1 | 0.150" (3.81mm) | Brass | Brass | - | 8 | - | 16-28 AWG | 1.5mm² | - | 8 | 1 | - | - | - | 300 V | - | 0.2 Nm (1.7 Lb-In) | 6-7mm | - | ||||
 |
1602460000 | 7.8980 | |
5907 | 0.00000000 | Weidmüller | Omnimate SL | Bulk | Active | -50°C ~ 100°C | Through Hole | Header, Male Pins, Shrouded (4 Side) | - | Orange | - | Solder | - | RoHS Compliant | 1 (Unlimited) | REACH Unaffected | SLD 5.08/18/180G 3.2SN OR BX | EAR99 | 8536.69.4040 | 20 | 0.200" (5.08mm) | Copper Alloy | Polybutylene Terephthalate (PBT) | UL94 V-0 | 18 | 0.866" (22.00mm) | - | - | - | 9 | 2 | Vertical | - | 11A | 10 A | 300 V | Tin | - | - | 0.126" (3.20mm) | 400 V | ||
|
0395137511 | 3.5486 | |
8591 | 0.00000000 | Molex | Eurostyle ESE 39513 | Bulk | Active | -40°C ~ 115°C | Free Hanging (In-Line) | Plug, Female Sockets | - | 039513 | Green | - | Screw - Rising Cage Clamp | download | ROHS3 Compliant | 1 (Unlimited) | EAR99 | 8536.69.8000 | 320 | 0.150" (3.81mm) | Phosphor Bronze | Polyamide (PA66), Nylon 6/6 | UL94 V-0 | 11 | 0.750" (19.05mm) | 16-30 AWG | - | - | 11 | 1 | - | 270° | - | 8 A | 300 V | Gold | 0.23 Nm (2.0 Lb-In) | 6.5mm | - | ||||
|
3045868 | 12.9500 | |
1083 | 0.00000000 | Phoenix Contact | CLIPLINE COMBI UPBV | Bulk | Active | - | Free Hanging (In-Line) | Plug, Female Sockets | - | Gray | Screw | download | RoHS Compliant | 1 (Unlimited) | UPBV 4/ 7 | EAR99 | 8536.69.8000 | 25 | - | 7 | 10-26 AWG | 0.14-6mm² | 7 | 1 | - | 90° | 32A | 30 A | 600 V | - | 800 V | ||||||||||||
 |
2645450000 | 2.8400 | |
180 | 0.00000000 | Weidmüller | Omnimate CH | Bulk | Active | -40°C ~ 105°C | Through Hole | Header, Male Pins, Shrouded (4 Side) | Mating Flange | Green | - | Solder | download | Not Applicable | EAR99 | 8536.69.4040 | 180 | 0.197" (5.00mm) | Copper Alloy | Polyamide (PA), Nylon, Glass Filled | UL94 V-0 | 6 | 0.472" (12.00mm) | - | - | - | 6 | 1 | Vertical | - | 15A | 15 A | 300 V | Tin | - | - | 0.154" (3.90mm) | 630 V | |||||
 |
WJA508-5.08-2*15p-14-RNA | 6.9300 | |
50 | 0.00000000 | Reliance North America | - | Tape & Box (TB) | Active | download | 4915-WJA508-5.08-2*15p-14-RNATB | 50 | |||||||||||||||||||||||||||||||||||
 |
1727710000 | 14.1600 | |
32 | 0.00000000 | Weidmüller | Omnimate B2L | Bulk | Active | -50°C ~ 100°C | Free Hanging (In-Line) | Plug, Female Sockets | - | Black | IP20 | Screwless - Spring Cage, Tension Clamp | download | RoHS Compliant | Not Applicable | REACH Unaffected | EAR99 | 8536.90.4000 | 48 | 0.138" (3.50mm) | Copper Alloy | Polybutylene Terephthalate (PBT) | UL94 V-0 | 20 | 0.618" (15.70mm) | 16-28 AWG | 0.2-1mm² | - | 10 | 2 | - | 180° | 10.3A | 10 A | 300 V | Tin | - | 7mm | - | 200 V | |||
 |
1155010000 | 5.8965 | |
2563 | 0.00000000 | Weidmüller | Omnimate SL | Bulk | Active | -50°C ~ 100°C | Through Hole | Header, Male Pins, Shrouded (4 Side) | Interlocking (Side) | Orange | - | Solder | - | RoHS Compliant | 1 (Unlimited) | REACH Unaffected | SL 5.08HC/23/90B 3.2SN OG BX | EAR99 | 8536.69.4040 | 20 | 0.200" (5.08mm) | Copper Alloy | Polyamide (PA), Nylon, Glass Filled | UL94 V-0 | 23 | 0.472" (12.00mm) | - | - | - | 23 | 1 | 90°, Right Angle | - | 24A | 18.5 A | 300 V | Tin | - | - | 0.126" (3.20mm) | 400 V | ||
|
OSTV713A250 | - | |
8991 | 0.00000000 | On Shore Technology Inc. | OSTV7 | Bulk | Obsolete | -30°C ~ 105°C | Through Hole | Header, Female Sockets | Mating Flange, Retention Latches | Green | - | Solder | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8536.69.4040 | 1 | 0.295" (7.50mm) | Phosphor Bronze | Thermoplastic | UL94 V-0 | 13 | 0.748" (19.00mm) | - | - | - | 13 | 1 | Vertical | - | - | 10 A | 300 V | - | - | - | 0.138" (3.50mm) | ||||
|
1748070000 | 11.3538 | |
1823 | 0.00000000 | Weidmüller | Omnimate B2L | Bulk | Active | -50°C ~ 100°C | Free Hanging (In-Line) | Plug, Female Sockets | Mating Flange | Orange | IP20 | Screwless - Spring Cage, Tension Clamp | download | RoHS Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8536.69.8000 | 42 | 0.138" (3.50mm) | Copper Alloy | Polybutylene Terephthalate (PBT) | UL94 V-0 | 18 | 0.618" (15.70mm) | 16-28 AWG | 0.2-1mm² | - | 9 | 2 | - | 180° | 10.3A | 10 A | 150 V | Tin | - | 7mm | - | 250 V | |||
|
TBP04R3-500-07-BE | 0.4709 | |
6038 | 0.00000000 | CUI Devices | TBP04R3-500 | Box | Active | -40°C ~ 105°C | Through Hole | Header, Male Pins, Shrouded (2 Side) | - | Blue | - | Solder | - | 2223-TBP04R3-500-07-BE | 200 | 0.197" (5.00mm) | Copper Alloy | Polyamide (PA66), Nylon 6/6 | UL94 V-0 | 7 | 0.472" (12.00mm) | - | - | - | 7 | 1 | Vertical | - | 10A | 15 A | 300 V | Tin | - | - | 0.157" (4.00mm) | 400 V | |||||||
|
OQ12A1500000G | 0.5902 | |
8864 | 0.00000000 | Amphenol Anytek | OQ | Bulk | Active | -40°C ~ 115°C | Through Hole | Header, Male Pins, Shrouded (4 Side) | - | OQ12 | Green | - | Solder | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8536.69.4040 | 2,000 | 0.295" (7.50mm) | Copper | Thermoplastic | UL94 V-0 | 12 | 0.472" (12.00mm) | - | - | - | 12 | 1 | Vertical | - | - | 20 A | 300 V | Tin | - | - | 0.157" (4.00mm) | |||
|
1825750 | 8.1328 | |
7052 | 0.00000000 | Phoenix Contact | COMBICON ICV | Bulk | Active | - | Through Hole | Header, Female Sockets | Mating and Mounting Flange, Retention Latches | Green | - | Solder | download | RoHS Compliant | 1 (Unlimited) | EAR99 | 8536.69.4040 | 50 | 0.200" (5.08mm) | - | Polyamide (PA), Nylon | UL94 V-0 | 8 | 0.748" (19.00mm) | - | - | - | 8 | 1 | Vertical | - | 12A | 10 A | 300 V | Tin | - | - | 0.142" (3.60mm) | 630 V | ||||
|
V72252510000G | 3.0842 | |
5102 | 0.00000000 | Amphenol Anytek | V7 | Bulk | Active | -40°C ~ 115°C | Through Hole | Header, Female Sockets | Mating Flange, Retention Latches | V722 | Green | - | Solder | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8536.69.4040 | 1,980 | 0.200" (5.08mm) | Copper | Thermoplastic | UL94 V-0 | 22 | - | - | - | - | 22 | 1 | 90°, Right Angle | - | - | 20 A | 300 V | Tin | - | - | 0.138" (3.50mm) | |||
 |
HW0230520000G | 0.3808 | |
1962 | 0.00000000 | Amphenol Anytek | 35-381 | Bulk | Active | -40°C ~ 115°C | Free Hanging (In-Line) | Plug, Female Sockets | Mating Flange | HW02 | Green | - | Screwless - Leg Spring, Push-In Spring | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8536.69.4040 | 2,000 | 0.150" (3.81mm) | Copper Alloy | Thermoplastic Resin | UL94 V-0 | 2 | 0.488" (12.40mm) | 16-28 AWG | 1.5mm² | - | 2 | 1 | - | 180° | - | 8 A | 300 V | Tin | - | 8-9mm | - | |||
|
0395333910 | 6.4027 | |
6591 | 0.00000000 | Molex | Eurostyle ESE 39533 | Bulk | Active | -40°C ~ 105°C | Free Hanging (In-Line) | Plug, Female Sockets | Positions Stamped, Retention Latches (Wire Side) | 039533 | Black | - | Screw - Rising Cage Clamp | download | ROHS3 Compliant | 1 (Unlimited) | EAR99 | 8536.69.8000 | 200 | 0.200" (5.08mm) | Phosphor Bronze | Polyamide (PA66), Nylon 6/6 | UL94 V-0 | 10 | 1.020" (25.91mm) | 12-26 AWG | - | - | 10 | 1 | - | 90° | - | 15 A | 300 V | Gold | 0.56 Nm (5.0 Lb-In) | 5mm | - | ||||
|
1830525 | 16.5910 | |
8958 | 0.00000000 | Phoenix Contact | COMBICON MCDV | Bulk | Active | - | Through Hole | Header, Male Pins, Shrouded (4 Side) | - | Green | - | Solder | download | RoHS Compliant | 1 (Unlimited) | MCDV 1 5/14-G-3 81 | EAR99 | 8536.69.4040 | 50 | 0.150" (3.81mm) | - | Polyamide (PA), Nylon | UL94 V-0 | 28 | 0.862" (21.89mm) | - | - | - | 14 | 2 | Vertical | - | 8A | 8 A | 300 V | Tin | - | - | 0.134" (3.40mm) | 320 V | |||
 |
721-603/018-000 | 6.3400 | |
2038 | 0.00000000 | WAGO Corporation | MCSMIDI | Box | Active | -60°C ~ 100°C | Free Hanging (In-Line) | Plug, Male Pins | Board Lock | Gray | - | Screwless - Push-In Spring | download | ROHS3 Compliant | Not Applicable | EAR99 | 8536.90.4000 | 1 | 0.197" (5.00mm) | Electrolytic Copper | Polyamide (PA66), Nylon 6/6 | UL94 V-0 | 3 | 0.563" (14.30mm) | 12-28 AWG | 0.08-2.5mm² | - | 3 | 1 | - | 180° | 12A | 15 A | 600 V | Tin | - | 8-9mm | - | 630 V | ||||
 |
1944930000 | 9.0663 | |
8942 | 0.00000000 | Weidmüller | Omnimate BL | Bulk | Active | -50°C ~ 100°C | Free Hanging (In-Line) | Plug, Female Sockets | Ejector Latches, Retention Latches (Non-Wire Side) | Orange | - | Screw - Clamping Yoke (Tension Sleeve) | - | RoHS Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8536.69.8000 | 24 | 0.200" (5.08mm) | Copper Alloy | Polybutylene Terephthalate (PBT) | UL94 V-0 | 12 | 0.632" (16.05mm) | 12-30 AWG | 0.2-4mm² | M2.5 | 12 | 1 | - | 180° | 23A | 20 A | 300 V | Tin | 0.4-0.5 Nm (3.5-4.4 Lb-In) | 7mm | - | 400 V |
