Rectangular Connectors(2759)
| Image | Product Number | Pricing(USD) | Quantity | ECAD | Quantity Available | Weight(Kg) | Mfr | Series | Package | Product Status | Operating Temperature | Applications | Mounting Type | Type | Features | Base Product Number | Color | Termination | Ingress Protection | Note | Style | DataSheet | RoHS Status | Moisture Sensitivity Level (MSL) | REACH Status | Other Names | ECCN | HTSUS | Standard Package | Connector Type | Pitch | Number of Rows | Row Spacing | Contact Finish | Contact Finish Thickness | Current Rating (Amps) | Contact Material | Material Flammability Rating | Contact Type | Pitch - Mating | Number of Positions | Row Spacing - Mating | Number of Positions Loaded | Shrouding | Fastening Type | Contact Length - Mating | Contact Length - Post | Overall Contact Length | Insulation Height | Contact Shape | Contact Finish - Mating | Contact Finish Thickness - Mating | Contact Finish - Post | Insulation Material | Insulation Color | Voltage Rating | Mated Stacking Heights | Contact Finish Thickness - Post | Wire Gauge | Contact Termination | Pin or Socket | Cable Termination | Wire Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
BM12B-ZPDSS-TF(LF)(SN) | 1.3500 |  |
9 | 0.00000000 | JST Sales America Inc. | ZPD | Tape & Reel (TR) | Active | -25°C ~ 85°C | - | Surface Mount | Solder Retention | BM12B-ZP | Solder | - | Board to Cable/Wire | download | RoHS Compliant | 1 (Unlimited) | EAR99 | 8536.69.4040 | 1,000 | Header | 2 | 2A | Copper Alloy | UL94 V-0 | Outer Shroud Contact | 0.059" (1.50mm) | 12 | - | All | Shrouded - 4 Wall | Locking Ramp | - | - | - | 0.219" (5.56mm) | Rectangular | Tin | - | Tin | Polyamide (PA), Nylon | Natural | 100V | 9.5mm | - | |||||||||||||||
 |
B13B-EH-A(LF)(SN) | 0.5600 | |
1160 | 0.00000000 | JST Sales America Inc. | EH | Bulk | Active | -25°C ~ 85°C | - | Through Hole | - | B13B-EH | Press-Fit, Solder | - | Board to Cable/Wire | download | RoHS Compliant | 1 (Unlimited) | EAR99 | 8536.69.4040 | 250 | Header | 1 | 3A | Brass | UL94 V-0 | Male Pin | 0.098" (2.50mm) | 13 | - | All | Shrouded - 3 Wall | Friction Lock | 0.130" (3.30mm) | 0.126" (3.20mm) | - | 0.236" (6.00mm) | Square | Tin | - | Tin | Polyamide (PA66), Nylon 6/6 | Natural | 250V | 8.1mm | - | |||||||||||||||
 |
SXAM-001T-P0.6 | 0.0284 | |
1602 | 0.00000000 | JST Sales America Inc. | XA | Tape & Reel (TR) | Active | Stamped | SXAM-001 | download | RoHS Compliant | 1 (Unlimited) | EAR99 | 8536.90.4000 | 7,000 | Tin | - | 22-28 AWG | Crimp | Pin | |||||||||||||||||||||||||||||||||||||||||
 |
EHR-6 | 0.1100 | |
394 | 0.00000000 | JST Sales America Inc. | EH | Bulk | Active | -25°C ~ 85°C | Free Hanging (In-Line) | - | EHR | Natural | Contacts Not Included | download | RoHS Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8538.90.6000 | 1,000 | Receptacle | 0.098" (2.50mm) | 1 | - | Female Socket | 6 | - | Crimp | |||||||||||||||||||||||||||||||||
 |
HLP-08V | 0.4500 | |
1 | 0.00000000 | JST Sales America Inc. | HL | Bulk | Active | -25°C ~ 90°C | Free Hanging (In-Line) | - | HLP | White | Contacts Not Included | download | RoHS Compliant | 1 (Unlimited) | EAR99 | 8538.90.6000 | 500 | Plug | 0.156" (3.96mm) | 2 | 0.156" (3.96mm) | Female Socket | 8 | Latch Lock | Polyamide (PA66), Nylon 6/6 | Crimp | |||||||||||||||||||||||||||||||||
 |
SM02B-PASS-TBT(LF)(SN) | 0.6600 | |
6491 | 0.00000000 | JST Sales America Inc. | PA | Tape & Reel (TR) | Active | -25°C ~ 85°C | - | Surface Mount, Right Angle | Pick and Place, Solder Retention | SM02B-PA | Solder | - | Board to Cable/Wire | download | RoHS Compliant | 1 (Unlimited) | EAR99 | 8536.69.4040 | 1,000 | Header | 1 | 3A | Copper Alloy | UL94 V-0 | Male Pin | 0.079" (2.00mm) | 2 | - | All | Shrouded - 4 Wall | Locking Ramp | - | - | - | 0.224" (5.69mm) | Square | Tin | - | Tin | Polyamide (PA), Nylon | Natural | 250V | - | - | |||||||||||||||
 |
B10B-PH-SM4-TB | 1.2500 | |
16 | 0.00000000 | JST Sales America Inc. | PH | Tape & Reel (TR) | Active | -25°C ~ 85°C | - | Surface Mount | Solder Retention | B10B-PH | Solder | - | Board to Cable/Wire | download | RoHS Compliant | 1 (Unlimited) | EAR99 | 8536.69.4040 | 1,000 | Header | 1 | 2A | Copper Alloy | UL94 V-0 | Male Pin | 0.079" (2.00mm) | 10 | - | All | Shrouded - 4 Wall | Detent Lock | 0.130" (3.30mm) | - | - | 0.260" (6.60mm) | Square | Tin | - | Tin | Polyamide (PA6T), Nylon 6T | Natural | 100V | 8.6mm | - | |||||||||||||||
 |
PUDP-32V-S | 0.5600 | |
3 | 0.00000000 | JST Sales America Inc. | PUD | Bulk | Active | -25°C ~ 85°C | Free Hanging (In-Line) | - | PUDP-32V | Natural | Contacts Not Included | download | RoHS Compliant | 1 (Unlimited) | EAR99 | 8538.90.6000 | 500 | Receptacle | 0.079" (2.00mm) | 2 | 0.079" (2.00mm) | Female Socket | 32 | Latch Lock | Crimp | ||||||||||||||||||||||||||||||||||
 |
BM05B-SRSS-TB | - | |
5428 | 0.00000000 | JST Sales America Inc. | SH/SR | Tape & Reel (TR) | Obsolete | -25°C ~ 85°C | - | Surface Mount | Solder Retention | Solder | - | Board to Cable/Wire | download | RoHS non-compliant | 1 (Unlimited) | EAR99 | 8536.69.4040 | 1,500 | Header | 1 | 1A | Copper Alloy | UL94 V-0 | Male Pin | 0.039" (1.00mm) | 5 | - | All | Shrouded - 4 Wall | Push-Pull | - | - | - | 0.167" (4.25mm) | Square | Tin-Lead | - | Tin-Lead | Polyamide (PA), Nylon | Natural | 50V | 4.9mm | - | ||||||||||||||||
 |
SPNI-002T-P0.5 | 0.1000 | |
31 | 0.00000000 | JST Sales America Inc. | PNI | Tape & Reel (TR) | Active | - | SPNI-002 | download | RoHS Compliant | 1 (Unlimited) | EAR99 | 8536.90.4000 | 9,000 | Tin | - | 24-28 AWG | Crimp | Pin | |||||||||||||||||||||||||||||||||||||||||
|
SPA-001T-P0.5 | 0.0184 | |
9727 | 0.00000000 | JST Sales America Inc. | PA | Tape & Reel (TR) | Active | - | SPA-001 | download | RoHS Compliant | 1 (Unlimited) | Q4655252 | EAR99 | 8536.90.4000 | 10,000 | Tin | - | 22-26 AWG | Crimp | Socket | ||||||||||||||||||||||||||||||||||||||||
 |
B11B-PH-SM4-TB(LF)(SN) | 1.3300 | |
8 | 0.00000000 | JST Sales America Inc. | PH | Tape & Reel (TR) | Active | -25°C ~ 85°C | - | Surface Mount | Solder Retention | B11B-PH | Solder | - | Board to Cable/Wire | download | RoHS Compliant | 1 (Unlimited) | EAR99 | 8536.69.4040 | 1,000 | Header | 1 | 2A | Copper Alloy | UL94 V-0 | Male Pin | 0.079" (2.00mm) | 11 | - | All | Shrouded - 4 Wall | Detent Lock | 0.130" (3.30mm) | - | - | 0.260" (6.60mm) | Square | Tin | - | Tin | Polyamide (PA6T), Nylon 6T | Natural | 100V | 8.6mm | - | |||||||||||||||
 |
S15B-XH-A(LF)(SN) | 0.9100 | |
139 | 0.00000000 | JST Sales America Inc. | XH | Bulk | Active | -25°C ~ 85°C | - | Through Hole, Right Angle | - | S15B-XH | Press-Fit, Solder | - | Board to Cable/Wire | download | RoHS Compliant | 1 (Unlimited) | EAR99 | 8536.69.4040 | 100 | Header | 1 | 3A | Brass | UL94 V-0 | Male Pin | 0.098" (2.50mm) | 15 | - | All | Shrouded - 4 Wall | Detent Lock | - | 0.134" (3.40mm) | - | 0.240" (6.10mm) | Square | Tin | - | Tin | Polyamide (PA66), Nylon 6/6 | Natural | 250V | - | - | |||||||||||||||
 |
B11B-PASK(LF)(SN) | 0.5120 | |
3335 | 0.00000000 | JST Sales America Inc. | PA | Bulk | Active | -25°C ~ 85°C | - | Through Hole | - | B11B-PAS | Kinked Pin, Solder | - | Board to Cable/Wire | download | RoHS Compliant | 1 (Unlimited) | 455-1826 | EAR99 | 8536.69.4040 | 250 | Header | 1 | 3A | Copper Alloy | UL94 V-0 | Male Pin | 0.079" (2.00mm) | 11 | - | All | Shrouded - 4 Wall | Locking Ramp | 0.126" (3.20mm) | 0.118" (3.00mm) | 0.319" (8.10mm) | 0.303" (7.70mm) | Square | Tin | - | Tin | Polybutylene Terephthalate (PBT), Glass Filled | Natural | 250V | 9.9mm, 14.7mm, 14.9mm | - | ||||||||||||||
 |
S9B-PH-K-S(LF)(SN) | 0.4700 | |
277 | 0.00000000 | JST Sales America Inc. | PH | Bulk | Active | -25°C ~ 85°C | - | Through Hole, Right Angle | - | S9B-PH-K | Press-Fit, Solder | - | Board to Cable/Wire | download | RoHS Compliant | 1 (Unlimited) | EAR99 | 8536.69.4040 | 250 | Header | 1 | 2A | Brass | UL94 V-0 | Male Pin | 0.079" (2.00mm) | 9 | - | All | Shrouded - 4 Wall | Detent Lock | 0.130" (3.30mm) | 0.134" (3.40mm) | - | 0.189" (4.80mm) | Square | Tin | - | Tin | Polyamide (PA66), Nylon 6/6 | Natural | 100V | - | - | |||||||||||||||
|
B20B-PADSS-1F(LF)(SN) | - | |
1822 | 0.00000000 | JST Sales America Inc. | PAD | Bulk | Active | -25°C ~ 85°C | - | Through Hole | Board Guide | B20B-PAD | Solder | - | Board to Cable/Wire | download | RoHS Compliant | 1 (Unlimited) | Q6916880 | EAR99 | 8536.69.4040 | 150 | Header | 2 | 3A | Copper Alloy | UL94 V-0 | Male Pin | 0.079" (2.00mm) | 20 | 0.079" (2.00mm) | All | Shrouded - 4 Wall | Locking Ramp | - | 0.134" (3.40mm) | - | 0.402" (10.20mm) | Square | Tin | - | Tin | Polyamide (PA66), Nylon 6/6, Glass Filled | Natural | 250V | 12.4mm | - | ||||||||||||||
|
XMP-04V | 0.1148 | |
5974 | 0.00000000 | JST Sales America Inc. | XM | Bulk | Active | -25°C ~ 85°C | Free Hanging (In-Line) | - | XMP | - | Contacts Not Included | download | RoHS Compliant | 1 (Unlimited) | EAR99 | 8538.90.6000 | 1,000 | - | 0.098" (2.50mm) | 1 | - | Female Socket | 4 | Latch Holder | Polyamide (PA66), Nylon 6/6 | Crimp | |||||||||||||||||||||||||||||||||
 |
B4B-ZR | - | |
6643 | 0.00000000 | JST Sales America Inc. | ZH | Bulk | Obsolete | -25°C ~ 85°C | - | Through Hole | - | Solder | - | Board to Cable/Wire | download | RoHS non-compliant | 1 (Unlimited) | EAR99 | 8536.69.4040 | 2,000 | Header | 1 | 1A | Brass | UL94 V-0 | Male Pin | 0.059" (1.50mm) | 4 | - | All | Shrouded - 4 Wall | Detent Lock | 0.094" (2.40mm) | 0.106" (2.69mm) | 0.256" (6.50mm) | 0.177" (4.50mm) | Circular | Tin-Lead | - | Tin-Lead | Polyamide (PA66), Nylon 6/6, Glass Filled | Natural | 50V | 5.6mm | - | ||||||||||||||||
 |
11KR-6H-P | 0.6100 | |
1 | 0.00000000 | JST Sales America Inc. | KR | Bulk | Active | Free Hanging (In-Line) | - | 11KR | Gray | download | RoHS Compliant | 1 (Unlimited) | EAR99 | 8536.69.8000 | 500 | Socket | 0.079" (2.00mm) | 1 | - | Tin | - | Female Socket | 11 | - | 26 AWG | IDC | Discrete | ||||||||||||||||||||||||||||||||
|
ZHR-4-K | - | |
1877 | 0.00000000 | JST Sales America Inc. | ZH | Bulk | Active | -25°C ~ 85°C | Free Hanging (In-Line) | - | ZHR | Black | Contacts Not Included | download | RoHS Compliant | 1 (Unlimited) | EAR99 | 8538.90.6000 | 1,000 | Receptacle | 0.059" (1.50mm) | 1 | - | Female Socket | 4 | - | Crimp | ||||||||||||||||||||||||||||||||||
 |
PNDP-20V-Z | 0.2800 | |
1 | 0.00000000 | JST Sales America Inc. | PND | Bulk | Active | -25°C ~ 85°C | Free Hanging (In-Line) | - | PNDP-20V | Ivory | Contacts Not Included | download | RoHS Compliant | 1 (Unlimited) | EAR99 | 8538.90.6000 | 300 | Receptacle | 0.079" (2.00mm) | 2 | 0.197" (5.00mm) | Female Socket | 20 | Latch Lock | Polyamide (PA66), Nylon 6/6 | Crimp | |||||||||||||||||||||||||||||||||
 |
ADHR-03V-H | 0.1700 | |
71 | 0.00000000 | JST Sales America Inc. | ADH | Bulk | Active | -25°C ~ 85°C | Free Hanging (In-Line) | - | ADHR-03V | Gray | Contacts Not Included | download | RoHS Compliant | 1 (Unlimited) | EAR99 | 8538.90.6000 | 1,000 | Receptacle | 0.051" (1.30mm) | 1 | - | Female Blade Socket | 3 | Friction Lock | Polybutylene Terephthalate (PBT) | Crimp | |||||||||||||||||||||||||||||||||
 |
13KR-D6S-P | 1.0300 | |
472 | 0.00000000 | JST Sales America Inc. | KRD | Bulk | Active | Free Hanging (In-Line), Right Angle | - | 13KR | Natural | download | RoHS Compliant | 1 (Unlimited) | EAR99 | 8536.69.8000 | 500 | Socket | 0.079" (2.00mm) | 1 | - | Tin | - | Female Socket | 13 | - | 26 AWG | IDC | Discrete | ||||||||||||||||||||||||||||||||
 |
B03P-VL | 1.0500 | |
3 | 0.00000000 | JST Sales America Inc. | VL | Bulk | Active | -25°C ~ 90°C | - | Through Hole | - | B03P | Solder | - | Board to Cable/Wire | download | ROHS3 Compliant | 1 (Unlimited) | EAR99 | 8536.69.4040 | 100 | Header | 1 | 20A | Copper Alloy | UL94 V-0 | Male Pin | 0.244" (6.20mm) | 3 | - | All | Shrouded - 4 Wall | Latch Holder | - | 0.142" (3.60mm) | - | 0.646" (16.40mm) | Square | Tin | - | Tin | Polyamide (PA66), Nylon 6/6 | Natural | 600V | 29.2mm | - | |||||||||||||||
 |
PHR-12 | 0.2700 | |
4 | 0.00000000 | JST Sales America Inc. | PH | Bulk | Active | -25°C ~ 85°C | Free Hanging (In-Line) | - | PHR | Natural | Contacts Not Included | download | RoHS Compliant | 1 (Unlimited) | EAR99 | 8538.90.6000 | 1,000 | Receptacle | 0.079" (2.00mm) | 1 | - | Female Socket | 12 | Detent Lock | Crimp | ||||||||||||||||||||||||||||||||||
|
S10B-XASS-1N-BN(LF)(SN) | 0.4792 | |
3425 | 0.00000000 | JST Sales America Inc. | XA | Bulk | Active | -25°C ~ 85°C | - | Through Hole, Right Angle | - | S10B-XAS | Solder | - | Board to Cable/Wire | - | RoHS Compliant | 1 (Unlimited) | EAR99 | 8536.69.4040 | 100 | Header | 1 | 3A | Copper Alloy | UL94 V-0 | Male Pin | 0.098" (2.50mm) | 10 | - | All | Shrouded - 4 Wall | Locking Ramp | - | 0.126" (3.20mm) | - | 0.299" (7.60mm) | Circular | Tin | - | Tin | Polyamide (PA66), Nylon 6/6, Glass Filled | Natural | 250V | - | - | |||||||||||||||
|
B14B-XASK-1N-A(LF)(SN) | - | |
5484 | 0.00000000 | JST Sales America Inc. | XA | Bulk | Active | -25°C ~ 85°C | - | Through Hole | Board Guide | B14B-XAS | Press-Fit, Solder | - | Board to Cable/Wire | download | RoHS Compliant | 1 (Unlimited) | EAR99 | 8536.69.4040 | 100 | Header | 1 | 3A | Copper Alloy | UL94 V-0 | Male Pin | 0.098" (2.50mm) | 14 | - | All | Shrouded - 4 Wall | Locking Ramp | - | 0.134" (3.40mm) | - | 0.346" (8.80mm) | Circular | Tin | - | Tin | Polyamide (PA66), Nylon 6/6, Glass Filled | Natural | 250V | - | - | |||||||||||||||
 |
B06B-PNISK-1A(LF)(SN)(F) | 0.5400 | |
2420 | 0.00000000 | JST Sales America Inc. | PNI | Bulk | Active | -25°C ~ 85°C | - | Through Hole | Board Guide | B06B-PNI | Press-Fit, Solder | - | Board to Cable/Wire | download | RoHS Compliant | 1 (Unlimited) | EAR99 | 8536.69.4040 | 350 | Header | 1 | 3A | Copper Alloy | UL94 V-0 | Male Pin | 0.079" (2.00mm) | 6 | - | All | Shrouded - 4 Wall | Latch Lock | - | 0.134" (3.40mm) | - | 0.402" (10.20mm) | Square | Tin | - | Tin | Polyamide (PA66), Nylon 6/6, Glass Filled | Natural | 100V | 12.25mm | - | |||||||||||||||
|
HRP-03-S | 0.0404 | |
2183 | 0.00000000 | JST Sales America Inc. | HR | Bulk | Active | -25°C ~ 85°C | Free Hanging (In-Line) | - | HRP | Natural | Contacts Not Included | download | RoHS Compliant | 1 (Unlimited) | EAR99 | 8538.90.6000 | 2,000 | Receptacle | 0.098" (2.50mm) | 1 | - | Female Socket | 3 | - | Polyamide (PA66), Nylon 6/6 | Crimp | |||||||||||||||||||||||||||||||||
|
B22B-PADSS | - | |
2405 | 0.00000000 | JST Sales America Inc. | PAD | Bulk | Obsolete | -25°C ~ 85°C | - | Through Hole | - | Solder | - | Board to Cable/Wire | download | RoHS non-compliant | 1 (Unlimited) | EAR99 | 8536.69.4040 | 150 | Header | 2 | 3A | Copper Alloy | UL94 V-0 | Male Pin | 0.079" (2.00mm) | 22 | 0.079" (2.00mm) | All | Shrouded - 4 Wall | Locking Ramp | - | 0.134" (3.40mm) | - | 0.402" (10.20mm) | Square | Tin-Lead | - | Tin-Lead | Polyamide (PA66), Nylon 6/6, Glass Filled | Natural | 250V | 12.4mm | - |
