Rectangular Connectors(819835)

Image Product Number Pricing(USD) Quantity ECAD Quantity Available Weight(Kg) Mfr Series Package Product Status Mounting Type Base Product Number Color Termination DataSheet RoHS Status Moisture Sensitivity Level (MSL) REACH Status ECCN HTSUS Standard Package Pitch Number of Rows Row Spacing Number of Positions Length - Overall Pin Length - Post (Mating) Length - Stack Height Length - Tail Contact Finish - Post (Mating) Contact Finish Thickness - Post (Mating)
DWM-18-54-S-S-250 Samtec Inc. DWM-18-54-S-S-250 -
RFQ
 ECAD 5398 0.00000000 Samtec Inc. Flex Stack, DWM Bulk Active Through Hole DWM-18 Black Solder download ROHS3 Compliant Not Applicable REACH Unaffected EAR99 8536.69.4040 1 0.050" (1.27mm) 1 - 18 0.555" (14.097mm) 0.185" (4.699mm) 0.250" (6.350mm) 0.120" (3.048mm) Gold 30.0µin (0.76µm)
DWM-20-60-G-S-705 Samtec Inc. DWM-20-60-G-S-705 -
RFQ
 ECAD 9468 0.00000000 Samtec Inc. Flex Stack, DWM Bulk Active Through Hole DWM-20 Black Solder download ROHS3 Compliant Not Applicable REACH Unaffected EAR99 8536.69.4040 1 0.050" (1.27mm) 1 - 20 0.825" (20.955mm) - 0.705" (17.907mm) 0.120" (3.048mm) Gold 10.0µin (0.25µm)
DWM-20-61-G-D-827 Samtec Inc. DWM-20-61-G-D-827 -
RFQ
 ECAD 8612 0.00000000 Samtec Inc. Flex Stack, DWM Bulk Active Through Hole DWM-20 Black Solder download ROHS3 Compliant Not Applicable REACH Unaffected EAR99 8536.69.4040 1 0.050" (1.27mm) 2 0.100" (2.54mm) 40 1.050" (26.670mm) 0.103" (2.616mm) 0.827" (21.006mm) 0.120" (3.048mm) Gold 10.0µin (0.25µm)
DWM-21-53-G-D-250 Samtec Inc. DWM-21-53-G-D-250 -
RFQ
 ECAD 5343 0.00000000 Samtec Inc. Flex Stack, DWM Bulk Active Through Hole DWM-21 Black Solder download ROHS3 Compliant Not Applicable REACH Unaffected EAR99 8536.69.4040 1 0.050" (1.27mm) 2 0.100" (2.54mm) 42 0.505" (12.827mm) 0.135" (3.429mm) 0.250" (6.350mm) 0.120" (3.048mm) Gold 10.0µin (0.25µm)
DWM-22-01-T-D-200 Samtec Inc. DWM-22-01-T-D-200 -
RFQ
 ECAD 1641 0.00000000 Samtec Inc. Flex Stack, DWM Bulk Active Through Hole DWM-22 Black Solder download ROHS3 Compliant Not Applicable REACH Unaffected EAR99 8536.69.4040 1 0.050" (1.27mm) 2 0.100" (2.54mm) 44 0.450" (11.430mm) 0.130" (3.302mm) 0.200" (5.080mm) 0.120" (3.048mm) Tin -
DWM-16-53-L-S-265 Samtec Inc. DWM-16-53-L-S-265 -
RFQ
 ECAD 6103 0.00000000 Samtec Inc. Flex Stack, DWM Bulk Active Through Hole DWM-16 Black Solder download ROHS3 Compliant Not Applicable REACH Unaffected EAR99 8536.69.4040 1 0.050" (1.27mm) 1 - 16 0.505" (12.827mm) 0.120" (3.048mm) 0.265" (6.731mm) 0.120" (3.048mm) Gold 10.0µin (0.25µm)
DWM-16-57-L-S-250 Samtec Inc. DWM-16-57-L-S-250 -
RFQ
 ECAD 6276 0.00000000 Samtec Inc. Flex Stack, DWM Bulk Active Through Hole DWM-16 Black Solder download ROHS3 Compliant Not Applicable REACH Unaffected EAR99 8536.69.4040 1 0.050" (1.27mm) 1 - 16 0.650" (16.510mm) 0.280" (7.112mm) 0.250" (6.350mm) 0.120" (3.048mm) Gold 10.0µin (0.25µm)
DWM-16-59-L-S-250 Samtec Inc. DWM-16-59-L-S-250 -
RFQ
 ECAD 7457 0.00000000 Samtec Inc. Flex Stack, DWM Bulk Active Through Hole DWM-16 Black Solder download ROHS3 Compliant Not Applicable REACH Unaffected EAR99 8536.69.4040 1 0.050" (1.27mm) 1 - 16 0.755" (19.177mm) 0.385" (9.779mm) 0.250" (6.350mm) 0.120" (3.048mm) Gold 10.0µin (0.25µm)
DWM-16-60-G-D-200 Samtec Inc. DWM-16-60-G-D-200 -
RFQ
 ECAD 5094 0.00000000 Samtec Inc. Flex Stack, DWM Bulk Active Through Hole DWM-16 Black Solder download ROHS3 Compliant Not Applicable REACH Unaffected EAR99 8536.69.4040 1 0.050" (1.27mm) 2 0.100" (2.54mm) 32 0.825" (20.955mm) 0.505" (12.827mm) 0.200" (5.080mm) 0.120" (3.048mm) Gold 10.0µin (0.25µm)
HDWM-04-54-S-D-355-SM Samtec Inc. HDWM-04-54-S-D-355-SM -
RFQ
 ECAD 5944 0.00000000 Samtec Inc. Flex Stack, HDWM Bulk Active Surface Mount HDWM-04 Black Solder - ROHS3 Compliant 1 (Unlimited) REACH Unaffected EAR99 8536.69.4040 1 0.050" (1.27mm) 2 0.100" (2.54mm) 8 0.640" (16.256mm) 0.285" (7.239mm) 0.355" (9.017mm) - Gold 30.0µin (0.76µm)
HDWM-04-55-L-D-250 Samtec Inc. HDWM-04-55-L-D-250 -
RFQ
 ECAD 5291 0.00000000 Samtec Inc. Flex Stack, HDWM Bulk Active Through Hole HDWM-04 Black Solder - ROHS3 Compliant Not Applicable REACH Unaffected EAR99 8536.69.4040 1 0.050" (1.27mm) 2 0.100" (2.54mm) 8 0.610" (15.494mm) 0.240" (6.096mm) 0.250" (6.350mm) 0.120" (3.048mm) Gold 10.0µin (0.25µm)
HDWM-04-56-S-S-250-SM Samtec Inc. HDWM-04-56-S-S-250-SM -
RFQ
 ECAD 7732 0.00000000 Samtec Inc. Flex Stack, HDWM Bulk Active Surface Mount HDWM-04 Black Solder - ROHS3 Compliant 1 (Unlimited) REACH Unaffected EAR99 8536.69.4040 1 0.050" (1.27mm) 1 - 4 0.605" (15.367mm) 0.355" (9.017mm) 0.250" (6.350mm) - Gold 30.0µin (0.76µm)
HDWM-09-01-G-S-280-SM Samtec Inc. HDWM-09-01-G-S-280-SM -
RFQ
 ECAD 5946 0.00000000 Samtec Inc. Flex Stack, HDWM Bulk Active Surface Mount HDWM-09 Black Solder - ROHS3 Compliant 1 (Unlimited) REACH Unaffected EAR99 8536.69.4040 1 0.050" (1.27mm) 1 - 9 0.460" (11.684mm) 0.180" (4.572mm) 0.280" (7.112mm) - Gold 10.0µin (0.25µm)
HDWM-09-59-G-D-250-SM Samtec Inc. HDWM-09-59-G-D-250-SM -
RFQ
 ECAD 1505 0.00000000 Samtec Inc. Flex Stack, HDWM Bulk Active Surface Mount HDWM-09 Black Solder - ROHS3 Compliant 1 (Unlimited) REACH Unaffected EAR99 8536.69.4040 1 0.050" (1.27mm) 2 0.100" (2.54mm) 18 0.715" (18.161mm) 0.465" (11.811mm) 0.250" (6.350mm) - Gold 10.0µin (0.25µm)
HDWM-06-54-G-D-250-SM Samtec Inc. HDWM-06-54-G-D-250-SM -
RFQ
 ECAD 6111 0.00000000 Samtec Inc. Flex Stack, HDWM Bulk Active Surface Mount HDWM-06 Black Solder - ROHS3 Compliant 1 (Unlimited) REACH Unaffected EAR99 8536.69.4040 1 0.050" (1.27mm) 2 0.100" (2.54mm) 12 0.535" (13.589mm) 0.285" (7.239mm) 0.250" (6.350mm) - Gold 10.0µin (0.25µm)
HDWM-06-55-G-D-368-SM Samtec Inc. HDWM-06-55-G-D-368-SM -
RFQ
 ECAD 8865 0.00000000 Samtec Inc. Flex Stack, HDWM Bulk Active Surface Mount HDWM-06 Black Solder - ROHS3 Compliant 1 (Unlimited) REACH Unaffected EAR99 8536.69.4040 1 0.050" (1.27mm) 2 0.100" (2.54mm) 12 0.708" (17.983mm) 0.340" (8.636mm) 0.368" (9.347mm) - Gold 10.0µin (0.25µm)
HDWM-03-53-L-S-250-SM Samtec Inc. HDWM-03-53-L-S-250-SM 1.1700
RFQ
 ECAD 6834 0.00000000 Samtec Inc. Flex Stack, HDWM Bulk Active Surface Mount HDWM-03 Black Solder - ROHS3 Compliant 1 (Unlimited) REACH Unaffected EAR99 8536.69.4040 1 0.050" (1.27mm) 1 - 3 0.485" (12.319mm) 0.235" (5.969mm) 0.250" (6.350mm) - Gold 10.0µin (0.25µm)
HDWM-03-54-L-S-250-SM Samtec Inc. HDWM-03-54-L-S-250-SM -
RFQ
 ECAD 1478 0.00000000 Samtec Inc. Flex Stack, HDWM Bulk Active Surface Mount HDWM-03 Black Solder - ROHS3 Compliant 1 (Unlimited) REACH Unaffected EAR99 8536.69.4040 1 0.050" (1.27mm) 1 - 3 0.535" (13.589mm) 0.285" (7.239mm) 0.250" (6.350mm) - Gold 10.0µin (0.25µm)
HDWM-03-55-G-S-251-SM Samtec Inc. HDWM-03-55-G-S-251-SM -
RFQ
 ECAD 2238 0.00000000 Samtec Inc. Flex Stack, HDWM Bulk Active Surface Mount HDWM-03 Black Solder - ROHS3 Compliant 1 (Unlimited) REACH Unaffected EAR99 8536.69.4040 1 0.050" (1.27mm) 1 - 3 0.591" (15.011mm) 0.340" (8.636mm) 0.251" (6.375mm) - Gold 10.0µin (0.25µm)
HDWM-03-55-S-S-355-SM Samtec Inc. HDWM-03-55-S-S-355-SM -
RFQ
 ECAD 1452 0.00000000 Samtec Inc. Flex Stack, HDWM Bulk Active Surface Mount HDWM-03 Black Solder - ROHS3 Compliant 1 (Unlimited) REACH Unaffected EAR99 8536.69.4040 1 0.050" (1.27mm) 1 - 3 0.695" (17.653mm) 0.340" (8.636mm) 0.355" (9.017mm) - Gold 30.0µin (0.76µm)
HDWM-03-59-L-D-250 Samtec Inc. HDWM-03-59-L-D-250 -
RFQ
 ECAD 5142 0.00000000 Samtec Inc. Flex Stack, HDWM Bulk Active Through Hole HDWM-03 Black Solder - ROHS3 Compliant Not Applicable REACH Unaffected EAR99 8536.69.4040 1 0.050" (1.27mm) 2 0.100" (2.54mm) 6 0.755" (19.177mm) 0.385" (9.779mm) 0.250" (6.350mm) 0.120" (3.048mm) Gold 10.0µin (0.25µm)
HDWM-03-60-S-D-783 Samtec Inc. HDWM-03-60-S-D-783 -
RFQ
 ECAD 1852 0.00000000 Samtec Inc. Flex Stack, HDWM Bulk Active Through Hole HDWM-03 Black Solder - ROHS3 Compliant Not Applicable REACH Unaffected EAR99 8536.69.4040 1 0.050" (1.27mm) 2 0.100" (2.54mm) 6 0.825" (20.955mm) - 0.783" (19.888mm) 0.120" (3.048mm) Gold 30.0µin (0.76µm)
HDWM-04-01-S-D-280-SM Samtec Inc. HDWM-04-01-S-D-280-SM -
RFQ
 ECAD 2622 0.00000000 Samtec Inc. Flex Stack, HDWM Bulk Active Surface Mount HDWM-04 Black Solder - ROHS3 Compliant 1 (Unlimited) REACH Unaffected EAR99 8536.69.4040 1 0.050" (1.27mm) 2 0.100" (2.54mm) 8 0.460" (11.684mm) 0.180" (4.572mm) 0.280" (7.112mm) - Gold 30.0µin (0.76µm)
HDWM-04-52-L-S-250 Samtec Inc. HDWM-04-52-L-S-250 -
RFQ
 ECAD 6109 0.00000000 Samtec Inc. Flex Stack, HDWM Bulk Active Through Hole HDWM-04 Black Solder - ROHS3 Compliant Not Applicable REACH Unaffected EAR99 8536.69.4040 1 0.050" (1.27mm) 1 - 4 0.425" (10.800mm) 0.055" (1.397mm) 0.250" (6.350mm) 0.120" (3.048mm) Gold 10.0µin (0.25µm)
HDWM-10-54-G-S-358 Samtec Inc. HDWM-10-54-G-S-358 -
RFQ
 ECAD 7451 0.00000000 Samtec Inc. Flex Stack, HDWM Bulk Active Through Hole HDWM-10 Black Solder - ROHS3 Compliant Not Applicable REACH Unaffected EAR99 8536.69.4040 1 0.050" (1.27mm) 1 - 10 0.555" (14.097mm) 0.077" (1.956mm) 0.358" (9.093mm) 0.120" (3.048mm) Gold 10.0µin (0.25µm)
HDWM-06-01-L-D-250 Samtec Inc. HDWM-06-01-L-D-250 -
RFQ
 ECAD 9515 0.00000000 Samtec Inc. Flex Stack, HDWM Bulk Active Through Hole HDWM-06 Black Solder - ROHS3 Compliant Not Applicable REACH Unaffected EAR99 8536.69.4040 1 0.050" (1.27mm) 2 0.100" (2.54mm) 12 0.450" (11.430mm) 0.080" (2.032mm) 0.250" (6.350mm) 0.120" (3.048mm) Gold 10.0µin (0.25µm)
HDWM-25-01-S-D-250-SM-A-P Samtec Inc. HDWM-25-01-S-D-250-SM-A-P -
RFQ
 ECAD 7458 0.00000000 Samtec Inc. Flex Stack, HDWM Bulk Active Surface Mount HDWM-25 Black Solder - ROHS3 Compliant 1 (Unlimited) REACH Unaffected EAR99 8536.69.4040 1 0.050" (1.27mm) 2 0.100" (2.54mm) 50 0.430" (10.922mm) 0.180" (4.572mm) 0.250" (6.350mm) - Gold 30.0µin (0.76µm)
HDWM-25-53-G-S-355-SM Samtec Inc. HDWM-25-53-G-S-355-SM -
RFQ
 ECAD 7257 0.00000000 Samtec Inc. Flex Stack, HDWM Bulk Active Surface Mount HDWM-25 Black Solder - ROHS3 Compliant 1 (Unlimited) REACH Unaffected EAR99 8536.69.4040 1 0.050" (1.27mm) 1 - 25 0.590" (14.986mm) 0.235" (5.969mm) 0.355" (9.017mm) - Gold 10.0µin (0.25µm)
HDWM-25-54-S-D-200 Samtec Inc. HDWM-25-54-S-D-200 -
RFQ
 ECAD 8246 0.00000000 Samtec Inc. Flex Stack, HDWM Bulk Active Through Hole HDWM-25 Black Solder - ROHS3 Compliant Not Applicable REACH Unaffected EAR99 8536.69.4040 1 0.050" (1.27mm) 2 0.100" (2.54mm) 50 0.555" (14.097mm) 0.235" (5.969mm) 0.200" (5.080mm) 0.120" (3.048mm) Gold 30.0µin (0.76µm)
HDWM-25-55-L-D-250-SM Samtec Inc. HDWM-25-55-L-D-250-SM -
RFQ
 ECAD 4430 0.00000000 Samtec Inc. Flex Stack, HDWM Bulk Active Surface Mount HDWM-25 Black Solder - ROHS3 Compliant 1 (Unlimited) REACH Unaffected EAR99 8536.69.4040 1 0.050" (1.27mm) 2 0.100" (2.54mm) 50 0.590" (14.986mm) 0.340" (8.636mm) 0.250" (6.350mm) - Gold 10.0µin (0.25µm)
