D-Sub, D-Shaped Connectors(166763)
| Image | Product Number | Pricing(USD) | Quantity | ECAD | Quantity Available | Weight(Kg) | Mfr | Series | Package | Product Status | Operating Temperature | Mounting Type | Features | Base Product Number | Color | Termination | Ingress Protection | DataSheet | RoHS Status | Moisture Sensitivity Level (MSL) | REACH Status | ECCN | HTSUS | Standard Package | Connector Type | Number of Rows | Contact Finish | Contact Finish Thickness | Current Rating (Amps) | Contact Material | Material Flammability Rating | Contact Type | Number of Positions | Voltage Rating | Flange Feature | Dielectric Material | Shell Material, Finish | Connector Style | Wire Gauge | Contact Form | Shell Size, Connector Layout | Backset Spacing |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
L17TF2510101 | 3.2221 |  |
8169 | 0.00000000 | Amphenol ICC (Commercial Products) | TF | Tray | Active | -55°C ~ 125°C | Through Hole | Grounding Indents | L17TF25 | - | Press-Fit | - | download | RoHS Compliant | 1 (Unlimited) | EAR99 | 8536.69.4040 | 50 | Plug, Male Pins | 2 | Gold | Flash | 3A | Brass | UL94 V-0 | Signal | 25 | 300V | Housing/Shell (4-40) | Thermoplastic, Glass Filled | Steel, Tin Plated | D-Sub | - | Stamped | 3 (DB, B) | - | ||
|
L17TF2510102 | 3.4677 | |
2933 | 0.00000000 | Amphenol ICC (Commercial Products) | TF | Tray | Active | -55°C ~ 125°C | Through Hole | Grounding Indents | L17TF25 | - | Press-Fit | - | download | RoHS Compliant | 1 (Unlimited) | EAR99 | 8536.69.4040 | 50 | Plug, Male Pins | 2 | Gold | Flash | 3A | Brass | UL94 V-0 | Signal | 25 | 300V | Mating Side, Female Screwlock (4-40) | Thermoplastic, Glass Filled | Steel, Tin Plated | D-Sub | - | Stamped | 3 (DB, B) | - | ||
|
L17TF2511105 | 3.3090 | |
3861 | 0.00000000 | Amphenol ICC (Commercial Products) | TF | Tray | Active | -55°C ~ 125°C | Through Hole | Grounding Indents | L17TF25 | - | Press-Fit | - | download | RoHS Compliant | 1 (Unlimited) | EAR99 | 8536.69.4040 | 50 | Plug, Male Pins | 2 | Gold | 16.0µin (0.41µm) | 3A | Brass | UL94 V-0 | Signal | 25 | 300V | Mating Side, Female Screwlock (M3) | Thermoplastic, Glass Filled | Steel, Tin Plated | D-Sub | - | Stamped | 3 (DB, B) | - | ||
|
L17TF2512104 | 3.6399 | |
3468 | 0.00000000 | Amphenol ICC (Commercial Products) | TF | Tray | Active | -55°C ~ 125°C | Through Hole | Grounding Indents | L17TF25 | - | Press-Fit | - | download | RoHS Compliant | 1 (Unlimited) | EAR99 | 8536.69.4040 | 50 | Plug, Male Pins | 2 | Gold | 30.0µin (0.76µm) | 3A | Brass | UL94 V-0 | Signal | 25 | 300V | Housing/Shell (M3) | Thermoplastic, Glass Filled | Steel, Tin Plated | D-Sub | - | Stamped | 3 (DB, B) | - | ||
|
L17TF2512114 | 3.6399 | |
2457 | 0.00000000 | Amphenol ICC (Commercial Products) | TF | Tray | Active | -55°C ~ 125°C | Through Hole | Board Lock, Grounding Indents | L17TF25 | - | Press-Fit | - | download | RoHS Compliant | 1 (Unlimited) | EAR99 | 8536.69.4040 | 50 | Plug, Male Pins | 2 | Gold | 30.0µin (0.76µm) | 3A | Brass | UL94 V-0 | Signal | 25 | 300V | Housing/Shell (M3) | Thermoplastic, Glass Filled | Steel, Tin Plated | D-Sub | - | Stamped | 3 (DB, B) | - | ||
|
L17TF3700100 | 5.3577 | |
5979 | 0.00000000 | Amphenol ICC (Commercial Products) | TF | Tray | Active | -55°C ~ 125°C | Through Hole | - | L17TF37 | - | Press-Fit | - | download | RoHS Compliant | 1 (Unlimited) | EAR99 | 8536.69.4040 | 40 | Receptacle, Female Sockets | 2 | Gold | Flash | 3A | Phosphor Bronze | UL94 V-0 | Signal | 37 | 300V | Housing/Shell (Unthreaded) | Thermoplastic, Glass Filled | Steel, Tin Plated | D-Sub | - | Stamped | 4 (DC, C) | - | ||
|
L17TF3701100 | 4.9896 | |
1392 | 0.00000000 | Amphenol ICC (Commercial Products) | TF | Tray | Active | -55°C ~ 125°C | Through Hole | - | L17TF37 | - | Press-Fit | - | download | RoHS Compliant | 1 (Unlimited) | EAR99 | 8536.69.4040 | 36 | Receptacle, Female Sockets | 2 | Gold | 16.0µin (0.41µm) | 3A | Phosphor Bronze | UL94 V-0 | Signal | 37 | 300V | Housing/Shell (Unthreaded) | Thermoplastic, Glass Filled | Steel, Tin Plated | D-Sub | - | Stamped | 4 (DC, C) | - | ||
|
L17TF3702100 | 5.5579 | |
7448 | 0.00000000 | Amphenol ICC (Commercial Products) | TF | Tray | Active | -55°C ~ 125°C | Through Hole | - | L17TF37 | - | Press-Fit | - | download | RoHS Compliant | 1 (Unlimited) | EAR99 | 8536.69.4040 | 40 | Receptacle, Female Sockets | 2 | Gold | 30.0µin (0.76µm) | 3A | Phosphor Bronze | UL94 V-0 | Signal | 37 | 300V | Housing/Shell (Unthreaded) | Thermoplastic, Glass Filled | Steel, Tin Plated | D-Sub | - | Stamped | 4 (DC, C) | - | ||
|
L17TF3702102 | 5.7391 | |
2835 | 0.00000000 | Amphenol ICC (Commercial Products) | TF | Tray | Active | -55°C ~ 125°C | Through Hole | - | L17TF37 | - | Press-Fit | - | download | RoHS Compliant | 1 (Unlimited) | EAR99 | 8536.69.4040 | 40 | Receptacle, Female Sockets | 2 | Gold | 30.0µin (0.76µm) | 3A | Phosphor Bronze | UL94 V-0 | Signal | 37 | 300V | Mating Side, Female Screwlock (4-40) | Thermoplastic, Glass Filled | Steel, Tin Plated | D-Sub | - | Stamped | 4 (DC, C) | - | ||
|
L17TF3702112 | 5.5087 | |
1812 | 0.00000000 | Amphenol ICC (Commercial Products) | TF | Tray | Active | -55°C ~ 125°C | Through Hole | Board Lock | L17TF37 | - | Press-Fit | - | download | RoHS Compliant | 1 (Unlimited) | EAR99 | 8536.69.4040 | 40 | Receptacle, Female Sockets | 2 | Gold | 30.0µin (0.76µm) | 3A | Phosphor Bronze | UL94 V-0 | Signal | 37 | 300V | Mating Side, Female Screwlock (4-40) | Thermoplastic, Glass Filled | Steel, Tin Plated | D-Sub | - | Stamped | 4 (DC, C) | - | ||
|
L17TF3702114 | 5.5579 | |
7966 | 0.00000000 | Amphenol ICC (Commercial Products) | TF | Tray | Active | -55°C ~ 125°C | Through Hole | Board Lock | L17TF37 | - | Press-Fit | - | download | RoHS Compliant | 1 (Unlimited) | EAR99 | 8536.69.4040 | 40 | Receptacle, Female Sockets | 2 | Gold | 30.0µin (0.76µm) | 3A | Phosphor Bronze | UL94 V-0 | Signal | 37 | 300V | Housing/Shell (M3) | Thermoplastic, Glass Filled | Steel, Tin Plated | D-Sub | - | Stamped | 4 (DC, C) | - | ||
|
L17TF3710112 | 5.1108 | |
9195 | 0.00000000 | Amphenol ICC (Commercial Products) | TF | Tray | Active | -55°C ~ 125°C | Through Hole | Board Lock, Grounding Indents | L17TF37 | - | Press-Fit | - | download | RoHS Compliant | 1 (Unlimited) | EAR99 | 8536.69.4040 | 40 | Plug, Male Pins | 2 | Gold | Flash | 3A | Brass | UL94 V-0 | Signal | 37 | 300V | Mating Side, Female Screwlock (4-40) | Thermoplastic, Glass Filled | Steel, Tin Plated | D-Sub | - | Stamped | 4 (DC, C) | - | ||
|
L17TF3710115 | 5.1108 | |
9878 | 0.00000000 | Amphenol ICC (Commercial Products) | TF | Tray | Active | -55°C ~ 125°C | Through Hole | Board Lock, Grounding Indents | L17TF37 | - | Press-Fit | - | download | RoHS Compliant | 1 (Unlimited) | EAR99 | 8536.69.4040 | 40 | Plug, Male Pins | 2 | Gold | Flash | 3A | Brass | UL94 V-0 | Signal | 37 | 300V | Mating Side, Female Screwlock (M3) | Thermoplastic, Glass Filled | Steel, Tin Plated | D-Sub | - | Stamped | 4 (DC, C) | - | ||
|
L17TF3712100 | 5.3527 | |
7244 | 0.00000000 | Amphenol ICC (Commercial Products) | TF | Tray | Active | -55°C ~ 125°C | Through Hole | Grounding Indents | L17TF37 | - | Press-Fit | - | download | RoHS Compliant | 1 (Unlimited) | EAR99 | 8536.69.4040 | 36 | Plug, Male Pins | 2 | Gold | 30.0µin (0.76µm) | 3A | Brass | UL94 V-0 | Signal | 37 | 300V | Housing/Shell (Unthreaded) | Thermoplastic, Glass Filled | Steel, Tin Plated | D-Sub | - | Stamped | 4 (DC, C) | - | ||
|
L17TF3712104 | 5.3527 | |
8488 | 0.00000000 | Amphenol ICC (Commercial Products) | TF | Tray | Active | -55°C ~ 125°C | Through Hole | Grounding Indents | L17TF37 | - | Press-Fit | - | download | RoHS Compliant | 1 (Unlimited) | EAR99 | 8536.69.4040 | 40 | Plug, Male Pins | 2 | Gold | 30.0µin (0.76µm) | 3A | Brass | UL94 V-0 | Signal | 37 | 300V | Housing/Shell (M3) | Thermoplastic, Glass Filled | Steel, Tin Plated | D-Sub | - | Stamped | 4 (DC, C) | - | ||
|
L717DA15P1ATN | 6.6609 | |
7930 | 0.00000000 | Amphenol ICC (Commercial Products) | D | Tray | Active | -55°C ~ 125°C | Through Hole, Right Angle | Grounding Indents, Mounting Brackets | L717DA15 | Black | Solder | - | - | RoHS Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8536.69.4040 | 50 | Plug, Male Pins | 2 | Gold | 8.00µin (0.203µm) | 7.5A | Brass | UL94 V-0 | Signal | 15 | 300V | Housing/Shell (Unthreaded) | Thermoplastic, Glass Filled | Steel, Tin Plated | D-Sub | - | Machined | 2 (DA, A) | 0.406" (10.30mm) | |
|
L717DA15PAM4 | 6.1805 | |
6112 | 0.00000000 | Amphenol ICC (Commercial Products) | D | Tray | Active | -55°C ~ 125°C | Through Hole, Right Angle | Grounding Indents, Mounting Brackets | L717DA15 | Black | Solder | - | - | RoHS Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8536.69.4040 | 50 | Plug, Male Pins | 2 | Gold | 8.00µin (0.203µm) | 7.5A | Brass | UL94 V-0 | Signal | 15 | 300V | Housing/Shell (Unthreaded) | Thermoplastic, Glass Filled | Steel, Tin Plated | D-Sub | - | Machined | 2 (DA, A) | 0.319" (8.10mm) | |
|
L717DA15PAZ4 | 6.2669 | |
3306 | 0.00000000 | Amphenol ICC (Commercial Products) | D | Tray | Active | -55°C ~ 125°C | Through Hole, Right Angle | Grounding Indents, Mounting Brackets | L717DA15 | Black | Solder | - | - | RoHS Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8536.69.4040 | 50 | Plug, Male Pins | 2 | Gold | 8.00µin (0.203µm) | 7.5A | Brass | UL94 V-0 | Signal | 15 | 300V | Housing/Shell (Unthreaded) | Thermoplastic, Glass Filled | Steel, Tin Plated | D-Sub | - | Machined | 2 (DA, A) | 0.319" (8.10mm) | |
|
L717DA15PAZ4B206 | - | |
6260 | 0.00000000 | Amphenol ICC (Commercial Products) | D | Tray | Active | -55°C ~ 125°C | Through Hole, Right Angle | Grounding Indents, Mounting Brackets | L717DA15 | Black | Solder | - | - | RoHS Compliant | 1 (Unlimited) | EAR99 | 8536.69.4040 | 200 | Plug, Male Pins | 2 | Gold | 8.00µin (0.203µm) | 7.5A | Brass | UL94 V-0 | Signal | 15 | 300V | Housing/Shell (Unthreaded) | Thermoplastic, Glass Filled | Steel, Tin Plated | D-Sub | - | Machined | 2 (DA, A) | 0.319" (8.10mm) | ||
|
L717DA15PST2 | 13.6205 | |
5077 | 0.00000000 | Amphenol ICC (Commercial Products) | D-ST | Bag | Active | -55°C ~ 125°C | Free Hanging (In-Line) | Grounding Indents | L717DA15 | Black | Screw | - | - | RoHS Compliant | 1 (Unlimited) | EAR99 | 8536.69.8000 | 1 | Plug, Male Pins | 2 | Gold | 8.00µin (0.203µm) | 7.5A | Brass | UL94 V-0 | Signal | 15 | 300V | Housing/Shell (Unthreaded) | Thermoplastic, Glass Filled | Steel, Tin Plated | D-Sub | 18 AWG | Machined | 2 (DA, A) | - | ||
|
L717DA15PSTC309 | - | |
9682 | 0.00000000 | Amphenol ICC (Commercial Products) | D-ST | Tray | Active | -55°C ~ 85°C | Free Hanging (In-Line) | Grounding Indents | L717DA15 | Black | Screw | - | - | RoHS Compliant | 1 (Unlimited) | EAR99 | 8536.69.8000 | 200 | Plug, Male Pins | 2 | Gold | 8.00µin (0.203µm) | 7.5A | Brass | UL94 V-0 | Signal | 15 | 300V | Housing/Shell (Unthreaded) | Thermoplastic, Glass Filled | Steel, Tin Plated | D-Sub | 18 AWG | Machined | 2 (DA, A) | - | ||
|
L717DA15PTR063 | 4.8517 | |
8885 | 0.00000000 | Amphenol ICC (Commercial Products) | D | Tray | Active | -55°C ~ 125°C | Through Hole | Grounding Indents | L717DA15 | Black | Solder | - | - | RoHS Compliant | 1 (Unlimited) | EAR99 | 8536.69.4040 | 50 | Plug, Male Pins | 2 | Gold | 8.00µin (0.203µm) | 7.5A | Brass | UL94 V-0 | Signal | 15 | 300V | Housing/Shell (Unthreaded) | Thermoplastic, Glass Filled | Steel, Tin Plated | D-Sub | - | Machined | 2 (DA, A) | - | ||
|
L717DA15PVF | 4.9196 | |
6349 | 0.00000000 | Amphenol ICC (Commercial Products) | D | Bag | Active | -55°C ~ 125°C | Free Hanging (In-Line) | Grounding Indents | L717DA15 | Black | Solder Cup | - | - | RoHS Compliant | 1 (Unlimited) | EAR99 | 8536.69.8000 | 50 | Plug, Male Pins | 2 | Gold | 8.00µin (0.203µm) | 7.5A | Brass | UL94 V-0 | Signal | 15 | 300V | Mating Side, Female Screwlock (4-40) | Thermoplastic, Glass Filled | Steel, Tin Plated | D-Sub | - | Machined | 2 (DA, A) | - | ||
|
L717DAG15PT | 4.5941 | |
5341 | 0.00000000 | Amphenol ICC (Commercial Products) | D | Tray | Active | -55°C ~ 125°C | Through Hole | Grounding Indents | L717DAG15 | Black | Solder | - | - | RoHS Compliant | 1 (Unlimited) | EAR99 | 8536.69.4040 | 50 | Plug, Male Pins | 2 | Gold | 8.00µin (0.203µm) | 7.5A | Brass | UL94 V-0 | Signal | 15 | 300V | Board Side (M3) | Thermoplastic, Glass Filled | Steel, Tin Plated | D-Sub | - | Machined | 2 (DA, A) | - | ||
|
L717DAH15POL2RM5 | 4.9609 | |
9389 | 0.00000000 | Amphenol ICC (Commercial Products) | D | Tray | Active | -55°C ~ 125°C | Through Hole | Board Lock, Grounding Indents | L717DAH15 | Black | Solder | - | - | RoHS Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8536.69.4040 | 50 | Plug, Male Pins | 2 | Gold | 8.00µin (0.203µm) | 7.5A | Brass | UL94 V-0 | Signal | 15 | 300V | Board Side (4-40) | Thermoplastic, Glass Filled | Steel, Tin Plated | D-Sub | - | Machined | 2 (DA, A) | - | |
|
L717DAH15PTRM8 | - | |
4954 | 0.00000000 | Amphenol ICC (Commercial Products) | D | Tray | Active | -55°C ~ 125°C | Through Hole | Board Lock, Grounding Indents | L717DAH15 | Black | Solder | - | - | RoHS Compliant | 1 (Unlimited) | EAR99 | 8536.69.4040 | 200 | Plug, Male Pins | 2 | Gold | 8.00µin (0.203µm) | 7.5A | Brass | UL94 V-0 | Signal | 15 | 300V | Board Side (4-40) | Thermoplastic, Glass Filled | Steel, Tin Plated | D-Sub | - | Machined | 2 (DA, A) | - | ||
|
L717DAH15PURM8 | - | |
1307 | 0.00000000 | Amphenol ICC (Commercial Products) | D | Tray | Active | -55°C ~ 125°C | Through Hole | Grounding Indents | L717DAH15 | Black | Solder | - | - | RoHS Compliant | 1 (Unlimited) | EAR99 | 8536.69.4040 | 200 | Plug, Male Pins | 2 | Gold | 8.00µin (0.203µm) | 7.5A | Brass | UL94 V-0 | Signal | 15 | 300V | Board Side (4-40) | Thermoplastic, Glass Filled | Steel, Tin Plated | D-Sub | - | Machined | 2 (DA, A) | - | ||
|
L717DB25P1AON | 9.1951 | |
8565 | 0.00000000 | Amphenol ICC (Commercial Products) | D | Tray | Active | -55°C ~ 125°C | Through Hole, Right Angle | Grounding Indents | L717DB25 | Black | Solder | - | - | RoHS Compliant | 1 (Unlimited) | REACH Unaffected | EAR99 | 8536.69.4040 | 50 | Plug, Male Pins | 2 | Gold | 8.00µin (0.203µm) | 7.5A | Brass | UL94 V-0 | Signal | 25 | 300V | Housing/Shell (Unthreaded) | Thermoplastic, Glass Filled | Steel, Tin Plated | D-Sub | - | Machined | 3 (DB, B) | 0.406" (10.30mm) | |
|
L717DB25PAJ3 | 8.7971 | |
3078 | 0.00000000 | Amphenol ICC (Commercial Products) | D | Tray | Active | -55°C ~ 125°C | Through Hole, Right Angle | Grounding Indents, Mounting Brackets | L717DB25 | Black | Solder | - | - | RoHS Compliant | 1 (Unlimited) | EAR99 | 8536.69.4040 | 50 | Plug, Male Pins | 2 | Gold | 8.00µin (0.203µm) | 7.5A | Brass | UL94 V-0 | Signal | 25 | 300V | Housing/Shell (Unthreaded) | Thermoplastic, Glass Filled | Steel, Tin Plated | D-Sub | - | Machined | 3 (DB, B) | 0.319" (8.10mm) | ||
|
L717DB25PAM4 | 9.0337 | |
1975 | 0.00000000 | Amphenol ICC (Commercial Products) | D | Tray | Active | -55°C ~ 125°C | Through Hole, Right Angle | Grounding Indents, Mounting Brackets | L717DB25 | Black | Solder | - | - | RoHS Compliant | 1 (Unlimited) | EAR99 | 8536.69.4040 | 50 | Plug, Male Pins | 2 | Gold | 8.00µin (0.203µm) | 7.5A | Brass | UL94 V-0 | Signal | 25 | 300V | Housing/Shell (Unthreaded) | Thermoplastic, Glass Filled | Steel, Tin Plated | D-Sub | - | Machined | 3 (DB, B) | 0.319" (8.10mm) |
