Card Edge Connectors(668078)

Image Product Number Pricing(USD) Quantity ECAD Quantity Available Weight(Kg) Mfr Series Package Product Status Operating Temperature Mounting Type Features Base Product Number Color Termination DataSheet RoHS Status Moisture Sensitivity Level (MSL) REACH Status Other Names ECCN HTSUS Standard Package Pitch Number of Rows Contact Finish Contact Finish Thickness Contact Material Contact Type Number of Positions Gender Card Type Number of Positions/Bay/Row Card Thickness Read Out Flange Feature Material - Insulation Termination Rows
395-086-525-804 EDAC Inc. 395-086-525-804 13.9244
RFQ
 ECAD 9123 0.00000000 EDAC Inc. 395 Bulk Active -40°C ~ 105°C Through Hole - 395-086 Black Solder download ROHS3 Compliant 1 (Unlimited) REACH Unaffected 151-395-086-525-804 EAR99 8536.69.4040 25 0.100" (2.54mm) 2 Gold 10.0µin (0.25µm) Copper Alloy Cantilever 86 Female Non Specified - Dual Edge 43 0.054" ~ 0.070" (1.37mm ~ 1.78mm) Dual Top Mount Opening, Unthreaded, 0.156" (3.96mm) Dia Polyester Thermoplastic 2
RBC17DREH-S13 Sullins Connector Solutions RBC17DREH-S13 7.7880
RFQ
 ECAD 3712 0.00000000 Sullins Connector Solutions - Tube Active -65°C ~ 125°C Board Edge, Straddle Mount Card Extender RBC17 Green Solder Eyelet(s) download ROHS3 Compliant 1 (Unlimited) REACH Unaffected EAR99 8536.69.4040 1 0.100" (2.54mm) 2 Gold 10.0µin (0.25µm) Phosphor Bronze Full Bellows 34 Female Non Specified - Dual Edge 17 0.062" (1.57mm) Dual Top Mount Opening, Unthreaded, 0.125" (3.18mm) Dia Polyphenylene Sulfide (PPS)
HBM08DRTH Sullins Connector Solutions HBM08DRTH 4.8020
RFQ
 ECAD 3406 0.00000000 Sullins Connector Solutions - Tray Active -65°C ~ 125°C Through Hole - HBM08 Blue Solder download ROHS3 Compliant Not Applicable REACH Unaffected EAR99 8536.69.4040 1 0.156" (3.96mm) 2 Gold 10.0µin (0.25µm) Beryllium Copper Full Bellows 16 Female Non Specified - Dual Edge 8 0.062" (1.57mm) Dual Top Mount Opening, Unthreaded, 0.125" (3.18mm) Dia Polybutylene Terephthalate (PBT)
ECM12MMJN Sullins Connector Solutions ECM12MMJN 6.9040
RFQ
 ECAD 6546 0.00000000 Sullins Connector Solutions - Tray Active -65°C ~ 125°C Through Hole, Right Angle - ECM12 - Solder download ROHS3 Compliant 1 (Unlimited) REACH Unaffected EAR99 8536.69.4040 1 0.156" (3.96mm) 2 Gold 30.0µin (0.76µm) Phosphor Bronze - 24 Male Fits Female Edgecards 12 0.062" (1.57mm) Dual - Polybutylene Terephthalate (PBT)
345-039-524-478 EDAC Inc. 345-039-524-478 15.4860
RFQ
 ECAD 7907 0.00000000 EDAC Inc. 345 Box Active -40°C ~ 105°C Through Hole Card Guides 345-039 Green Solder download ROHS3 Compliant REACH Unaffected 151-345-039-524-478 EAR99 8536.69.4040 25 0.100" (2.54mm) 1 Gold 10.0µin (0.25µm) Copper Alloy Cantilever 39 Female Non Specified - Single Edge 39 0.054" ~ 0.070" (1.37mm ~ 1.78mm) Single Top Mount Opening, Threaded Insert, 4-40 Polyester Thermoplastic 1
845-074-555-503 EDAC Inc. 845-074-555-503 101.4772
RFQ
 ECAD 6631 0.00000000 EDAC Inc. 845 Box Active -40°C ~ 125°C Board Edge, Straddle Mount Card Extender 845-074 Green Solder download ROHS3 Compliant REACH Unaffected 151-845-074-555-503 EAR99 8536.69.4040 25 0.100" (2.54mm) 2 Gold 10.0µin (0.25µm) Copper Alloy Cantilever 74 Female Non Specified - Dual Edge 37 0.054" ~ 0.070" (1.37mm ~ 1.78mm) Dual Top Mount Opening, Floating Bobbin, 0.116" (2.95mm) Dia Diallyl Phthalate (DAP) 2
745-016-525-206 EDAC Inc. 745-016-525-206 4.7120
RFQ
 ECAD 4892 0.00000000 EDAC Inc. 745 Bulk Active -40°C ~ 105°C Through Hole - 745-016 Black Press-Fit download ROHS3 Compliant 1 (Unlimited) REACH Unaffected 151-745-016-525-206 EAR99 8536.69.4040 25 0.100" (2.54mm) 2 Gold 30.0µin (0.76µm) Copper Alloy Cantilever 16 Female Non Specified - Dual Edge 8 0.054" ~ 0.070" (1.37mm ~ 1.78mm) Dual - Polyester Thermoplastic 2
395-014-520-502 EDAC Inc. 395-014-520-502 6.9916
RFQ
 ECAD 8202 0.00000000 EDAC Inc. 395 Box Active -40°C ~ 105°C Through Hole - 395-014 Black Solder download ROHS3 Compliant REACH Unaffected 151-395-014-520-502 EAR99 8536.69.4040 25 0.100" (2.54mm) 2 Gold 10.0µin (0.25µm) Copper Alloy Cantilever 14 Female Non Specified - Dual Edge 7 0.054" ~ 0.070" (1.37mm ~ 1.78mm) Dual Top Mount Opening, Unthreaded, 0.128" (3.25mm) Dia Polyester Thermoplastic 2
RCC40DREN-S13 Sullins Connector Solutions RCC40DREN-S13 12.1800
RFQ
 ECAD 1461 0.00000000 Sullins Connector Solutions - Tube Active -65°C ~ 125°C Board Edge, Straddle Mount Card Extender RCC40 Green Solder Eyelet(s) download ROHS3 Compliant 1 (Unlimited) REACH Unaffected EAR99 8536.69.4040 1 0.100" (2.54mm) 2 Gold 30.0µin (0.76µm) Phosphor Bronze Full Bellows 80 Female Non Specified - Dual Edge 40 0.062" (1.57mm) Dual - Polyphenylene Sulfide (PPS)
892-052-541-104 EDAC Inc. 892-052-541-104 150.9636
RFQ
 ECAD 4695 0.00000000 EDAC Inc. 892 Bulk Active -40°C ~ 125°C Through Hole - 892-052 Black Wire Wrap download ROHS3 Compliant 1 (Unlimited) REACH Unaffected 151-892-052-541-104 EAR99 8536.69.4040 25 0.100" (2.54mm) 1 Gold 10.0µin (0.25µm) Copper Alloy Cantilever 52 Female Non Specified - Single Edge 52 0.054" ~ 0.070" (1.37mm ~ 1.78mm) Single Flush Mount, Top Opening, Unthreaded, 0.156" (3.96mm) Dia Polyphenylene Sulfide (PPS) 1
895-010-540-604 EDAC Inc. 895-010-540-604 48.1768
RFQ
 ECAD 4411 0.00000000 EDAC Inc. 895 Bulk Active -40°C ~ 125°C Through Hole - 895-010 Black Wire Wrap download ROHS3 Compliant 1 (Unlimited) REACH Unaffected 151-895-010-540-604 EAR99 8536.69.4040 25 0.100" (2.54mm) 1 Gold 10.0µin (0.25µm) Copper Alloy Cantilever 10 Female Non Specified - Single Edge 10 0.054" ~ 0.070" (1.37mm ~ 1.78mm) Single Top Mount Opening, Unthreaded, 0.156" (3.96mm) Dia Polyphenylene Sulfide (PPS) 1
745-072-525-206 EDAC Inc. 745-072-525-206 10.4344
RFQ
 ECAD 6361 0.00000000 EDAC Inc. 745 Bulk Active -40°C ~ 105°C Through Hole - 745-072 Black Press-Fit download ROHS3 Compliant 1 (Unlimited) REACH Unaffected 151-745-072-525-206 EAR99 8536.69.4040 25 0.100" (2.54mm) 2 Gold 30.0µin (0.76µm) Copper Alloy Cantilever 72 Female Non Specified - Dual Edge 36 0.054" ~ 0.070" (1.37mm ~ 1.78mm) Dual - Polyester Thermoplastic 2
GBB86DHRR Sullins Connector Solutions GBB86DHRR -
RFQ
 ECAD 8953 0.00000000 Sullins Connector Solutions - Tube Active -65°C ~ 125°C Board Edge, Straddle Mount Board Lock, Card Extender GBB86 Black Solder download ROHS3 Compliant 1 (Unlimited) REACH Unaffected EAR99 8536.69.4040 10 0.050" (1.27mm) 2 Gold 10.0µin (0.25µm) Phosphor Bronze Hairpin Bellows 172 Female Non Specified - Dual Edge 86 0.062" (1.57mm) Dual - Polyamide (PA9T), Nylon 9T
ACB97DHBN Sullins Connector Solutions ACB97DHBN -
RFQ
 ECAD 4484 0.00000000 Sullins Connector Solutions - Tube Active -65°C ~ 150°C Through Hole, Right Angle - ACB97 Black Solder, Staggered download ROHS3 Compliant 1 (Unlimited) REACH Unaffected EAR99 8536.69.4040 1 0.050" (1.27mm) 2 Gold 30.0µin (0.76µm) Beryllium Copper Hairpin Bellows 194 Female Non Specified - Dual Edge 97 0.062" (1.57mm) Dual - Polyphenylene Sulfide (PPS)
346-036-560-878 EDAC Inc. 346-036-560-878 14.7120
RFQ
 ECAD 4297 0.00000000 EDAC Inc. 346 Box Active -40°C ~ 105°C Board Edge, Straddle Mount Card Extender, Card Guides 346-036 Green Solder download ROHS3 Compliant REACH Unaffected 151-346-036-560-878 EAR99 8536.69.4040 25 0.125" (3.18mm) 2 Gold 10.0µin (0.25µm) Copper Alloy Cantilever 36 Female Non Specified - Dual Edge 18 0.054" ~ 0.070" (1.37mm ~ 1.78mm) Dual Top Mount Opening, Threaded Insert, 4-40 Polyester Thermoplastic 2
395-082-560-207 EDAC Inc. 395-082-560-207 16.5340
RFQ
 ECAD 4802 0.00000000 EDAC Inc. 395 Box Active -40°C ~ 105°C Board Edge, Straddle Mount Card Extender 395-082 Black Solder download ROHS3 Compliant REACH Unaffected 151-395-082-560-207 EAR99 8536.69.4040 25 0.100" (2.54mm) 2 Gold 10.0µin (0.25µm) Copper Alloy Cantilever 82 Female Non Specified - Dual Edge 41 0.054" ~ 0.070" (1.37mm ~ 1.78mm) Dual Flush Mount, Top Opening, Threaded Insert, M3 Polyester Thermoplastic 2
ASC26DREF-S13 Sullins Connector Solutions ASC26DREF-S13 18.3370
RFQ
 ECAD 1220 0.00000000 Sullins Connector Solutions - Tube Active -65°C ~ 150°C Board Edge, Straddle Mount Card Extender ASC26 Green Solder Eyelet(s) download ROHS3 Compliant Not Applicable REACH Unaffected EAR99 8536.69.4040 1 0.100" (2.54mm) 2 Gold 10.0µin (0.25µm) Beryllium Copper Full Bellows 52 Female Non Specified - Dual Edge 26 0.062" (1.57mm) Dual Top Mount Opening, Floating Bobbin, 0.116" (2.95mm) Dia Polyphenylene Sulfide (PPS)
ECA15DTMN Sullins Connector Solutions ECA15DTMN 5.9620
RFQ
 ECAD 8298 0.00000000 Sullins Connector Solutions - Tray Active -65°C ~ 125°C Through Hole, Right Angle - ECA15 Blue Solder download ROHS3 Compliant Not Applicable REACH Unaffected EAR99 8536.69.4040 1 0.125" (3.18mm) 2 Gold 30.0µin (0.76µm) Phosphor Bronze Loop Bellows 30 Female Non Specified - Dual Edge 15 0.062" (1.57mm) Dual - Polybutylene Terephthalate (PBT)
EBA28DTBN Sullins Connector Solutions EBA28DTBN 6.8640
RFQ
 ECAD 1585 0.00000000 Sullins Connector Solutions - Tray Active -65°C ~ 125°C Through Hole, Right Angle - EBA28 Blue Solder download ROHS3 Compliant Not Applicable REACH Unaffected EAR99 8536.69.4040 1 0.125" (3.18mm) 2 Gold 10.0µin (0.25µm) Phosphor Bronze Loop Bellows 56 Female Non Specified - Dual Edge 28 0.062" (1.57mm) Dual - Polybutylene Terephthalate (PBT)
745-053-540-101 EDAC Inc. 745-053-540-101 13.9032
RFQ
 ECAD 2009 0.00000000 EDAC Inc. 745 Bulk Active -40°C ~ 105°C Through Hole - 745-053 Black Press-Fit, Wire Wrap download ROHS3 Compliant 1 (Unlimited) REACH Unaffected 151-745-053-540-101 EAR99 8536.69.4040 25 0.100" (2.54mm) 1 Gold 30.0µin (0.76µm) Copper Alloy Cantilever 53 Female Non Specified - Single Edge 53 0.054" ~ 0.070" (1.37mm ~ 1.78mm) Single - Polyester Thermoplastic 1
396-040-522-603 EDAC Inc. 396-040-522-603 13.8336
RFQ
 ECAD 4832 0.00000000 EDAC Inc. 396 Box Active -40°C ~ 105°C Through Hole - 396-040 Black Solder download ROHS3 Compliant REACH Unaffected 151-396-040-522-603 EAR99 8536.69.4040 25 0.125" (3.18mm) 1 Gold 10.0µin (0.25µm) Copper Alloy Cantilever 40 Female Non Specified - Single Edge 40 0.054" ~ 0.070" (1.37mm ~ 1.78mm) Single Top Mount Opening, Floating Bobbin, 0.116" (2.95mm) Dia Polyester Thermoplastic 1
395-007-521-658 EDAC Inc. 395-007-521-658 11.6844
RFQ
 ECAD 4258 0.00000000 EDAC Inc. 395 Box Active -40°C ~ 105°C Through Hole Card Guides 395-007 Black Solder download ROHS3 Compliant REACH Unaffected 151-395-007-521-658 EAR99 8536.69.4040 25 0.100" (2.54mm) 1 Gold 10.0µin (0.25µm) Copper Alloy Cantilever 7 Female Non Specified - Single Edge 7 0.054" ~ 0.070" (1.37mm ~ 1.78mm) Single Top Mount Opening, Threaded Insert, 4-40 Polyester Thermoplastic 1
345-136-521-858 EDAC Inc. 345-136-521-858 19.4324
RFQ
 ECAD 9107 0.00000000 EDAC Inc. 345 Box Active -40°C ~ 105°C Through Hole Card Guides 345-136 Green Solder download ROHS3 Compliant REACH Unaffected 151-345-136-521-858 EAR99 8536.69.4040 25 0.100" (2.54mm) 2 Gold 10.0µin (0.25µm) Copper Alloy Cantilever 136 Female Non Specified - Dual Edge 68 0.054" ~ 0.070" (1.37mm ~ 1.78mm) Dual Top Mount Opening, Threaded Insert, 4-40 Polyester Thermoplastic 2
845-063-540-112 EDAC Inc. 845-063-540-112 151.9088
RFQ
 ECAD 8462 0.00000000 EDAC Inc. 845 Box Active -40°C ~ 125°C Through Hole - 845-063 Green Wire Wrap download ROHS3 Compliant REACH Unaffected 151-845-063-540-112 EAR99 8536.69.4040 25 0.100" (2.54mm) 1 Gold 10.0µin (0.25µm) Copper Alloy Cantilever 63 Female Non Specified - Single Edge 63 0.054" ~ 0.070" (1.37mm ~ 1.78mm) Single Flush Mount, Side Opening, Unthreaded, 0.128" (3.25mm) Dia Diallyl Phthalate (DAP) 1
MEC1-105-02-F-D-RA1-A-SL Samtec Inc. MEC1-105-02-F-D-RA1-A-SL -
RFQ
 ECAD 6053 0.00000000 Samtec Inc. MEC1 Tube Active -55°C ~ 125°C Surface Mount, Right Angle Board Lock MEC1-105 Black Solder - ROHS3 Compliant 1 (Unlimited) EAR99 8536.69.4040 1 0.039" (1.00mm) 2 Gold 3.00µin (0.076µm) Phosphor Bronze Loop Bellows 10 Female Non Specified - Dual Edge - 0.062" (1.57mm) Dual - Liquid Crystal Polymer (LCP)
717-068-541-201 EDAC Inc. 717-068-541-201 12.7828
RFQ
 ECAD 2533 0.00000000 EDAC Inc. 717 Bulk Active -40°C ~ 105°C Through Hole - 717-068 Black Press-Fit, Wire Wrap download ROHS3 Compliant 1 (Unlimited) REACH Unaffected 151-717-068-541-201 EAR99 8536.69.4040 25 0.156" (3.96mm) 2 Gold 30.0µin (0.76µm) Copper Alloy Cantilever 68 Female Non Specified - Dual Edge 34 0.054" ~ 0.070" (1.37mm ~ 1.78mm) Dual - Polyester Thermoplastic 2
345-067-500-158 EDAC Inc. 345-067-500-158 40.3832
RFQ
 ECAD 2446 0.00000000 EDAC Inc. 345 Box Active -40°C ~ 105°C Through Hole Card Guides 345-067 Green Solder Eyelet(s) download ROHS3 Compliant REACH Unaffected 151-345-067-500-158 EAR99 8536.69.4040 25 0.100" (2.54mm) 1 Gold 10.0µin (0.25µm) Copper Alloy Cantilever 67 Female Non Specified - Single Edge 67 0.054" ~ 0.070" (1.37mm ~ 1.78mm) Single Flush Mount, Top Opening, Threaded Insert, 4-40 Polyester Thermoplastic 1
895-070-523-103 EDAC Inc. 895-070-523-103 165.4632
RFQ
 ECAD 9991 0.00000000 EDAC Inc. 895 Bulk Active -40°C ~ 125°C Through Hole - 895-070 Black Solder download ROHS3 Compliant 1 (Unlimited) REACH Unaffected 151-895-070-523-103 EAR99 8536.69.4040 25 0.100" (2.54mm) 1 Gold 10.0µin (0.25µm) Copper Alloy Cantilever 70 Female Non Specified - Single Edge 70 0.054" ~ 0.070" (1.37mm ~ 1.78mm) Single Flush Mount, Floating Bobbin, 0.116" (2.95mm) Dia Polyphenylene Sulfide (PPS) 1
333-034-555-812 EDAC Inc. 333-034-555-812 11.0448
RFQ
 ECAD 2512 0.00000000 EDAC Inc. 333 Box Active -40°C ~ 105°C Board Edge, Straddle Mount Card Extender 333-034 Green Solder download ROHS3 Compliant Not Applicable REACH Unaffected 151-333-034-555-812 EAR99 8536.69.4040 25 0.156" (3.96mm) 2 Gold 10.0µin (0.25µm) Copper Alloy Cantilever 34 Female Non Specified - Dual Edge 17 0.054" ~ 0.070" (1.37mm ~ 1.78mm) Dual Side Mount Opening, Unthreaded, 0.128" (3.25mm) Dia Polyester Thermoplastic 2
ECC65DKAN-S189 Sullins Connector Solutions ECC65DKAN-S189 14.2990
RFQ
 ECAD 3364 0.00000000 Sullins Connector Solutions - Tray Active -65°C ~ 125°C Through Hole, Right Angle - ECC65 - Solder download ROHS3 Compliant 1 (Unlimited) REACH Unaffected EAR99 8536.69.4040 1 0.100" (2.54mm) 2 Gold 30.0µin (0.76µm) Phosphor Bronze Cantilever 130 Female Non Specified - Dual Edge 65 0.062" (1.57mm) Dual - Polybutylene Terephthalate (PBT)
