Card Edge Connectors(468861)

Image Product Number Pricing(USD) Quantity ECAD Quantity Available Weight(Kg) Mfr Series Package Product Status Operating Temperature Mounting Type Features Base Product Number Color Termination DataSheet RoHS Status Moisture Sensitivity Level (MSL) REACH Status Other Names ECCN HTSUS Standard Package Pitch Number of Rows Contact Finish Contact Finish Thickness Contact Material Contact Type Number of Positions Gender Card Type Number of Positions/Bay/Row Card Thickness Read Out Flange Feature Material - Insulation Termination Rows
837-016-560-203 EDAC Inc. 837-016-560-203 79.8524
RFQ
 ECAD 4829 0.00000000 EDAC Inc. 837 Box Active -40°C ~ 125°C Board Edge, Straddle Mount Card Extender 837-016 Green Solder download ROHS3 Compliant REACH Unaffected 151-837-016-560-203 EAR99 8536.69.4040 25 0.156" (3.96mm) 2 Gold 10.0µin (0.25µm) Copper Alloy Cantilever 16 Female Non Specified - Dual Edge 8 0.054" ~ 0.070" (1.37mm ~ 1.78mm) Dual Flush Mount, Floating Bobbin, 0.116" (2.95mm) Dia Diallyl Phthalate (DAP) 2
395-060-541-407 EDAC Inc. 395-060-541-407 15.7644
RFQ
 ECAD 8861 0.00000000 EDAC Inc. 395 Box Active -40°C ~ 105°C Through Hole - 395-060 Black Wire Wrap download ROHS3 Compliant REACH Unaffected 151-395-060-541-407 EAR99 8536.69.4040 25 0.100" (2.54mm) 1 Gold 10.0µin (0.25µm) Copper Alloy Cantilever 60 Female Non Specified - Single Edge 60 0.054" ~ 0.070" (1.37mm ~ 1.78mm) Single Top Mount Opening, Threaded Insert, M3 Polyester Thermoplastic 1
837-016-521-612 EDAC Inc. 837-016-521-612 42.1784
RFQ
 ECAD 4878 0.00000000 EDAC Inc. 837 Box Active -40°C ~ 125°C Through Hole - 837-016 Green Solder download ROHS3 Compliant REACH Unaffected 151-837-016-521-612 EAR99 8536.69.4040 25 0.156" (3.96mm) 1 Gold 10.0µin (0.25µm) Copper Alloy Cantilever 16 Female Non Specified - Single Edge 16 0.054" ~ 0.070" (1.37mm ~ 1.78mm) Single Side Mount Opening, Unthreaded, 0.128" (3.25mm) Dia Diallyl Phthalate (DAP) 1
833-052-542-807 EDAC Inc. 833-052-542-807 62.8424
RFQ
 ECAD 1603 0.00000000 EDAC Inc. 833 Box Active -40°C ~ 125°C Through Hole - 833-052 Green Wire Wrap download ROHS3 Compliant REACH Unaffected 151-833-052-542-807 EAR99 8536.69.4040 25 0.156" (3.96mm) 2 Gold 10.0µin (0.25µm) Copper Alloy Cantilever 52 Female Non Specified - Dual Edge 26 0.054" ~ 0.070" (1.37mm ~ 1.78mm) Dual Top Mount Opening, Threaded Insert, M3 Diallyl Phthalate (DAP) 2
845-027-559-104 EDAC Inc. 845-027-559-104 72.0564
RFQ
 ECAD 3751 0.00000000 EDAC Inc. 845 Box Active -40°C ~ 125°C Through Hole, Right Angle - 845-027 Green Solder download ROHS3 Compliant REACH Unaffected 151-845-027-559-104 EAR99 8536.69.4040 25 0.100" (2.54mm) 1 Gold 10.0µin (0.25µm) Copper Alloy Cantilever 27 Female Non Specified - Single Edge 27 0.054" ~ 0.070" (1.37mm ~ 1.78mm) Single Flush Mount, Top Opening, Unthreaded, 0.156" (3.96mm) Dia Diallyl Phthalate (DAP) 1
845-032-523-678 EDAC Inc. 845-032-523-678 -
RFQ
 ECAD 7797 0.00000000 EDAC Inc. 845 Box Obsolete 845-032 - ROHS3 Compliant 1 (Unlimited) REACH Unaffected 151-845-032-523-678 EAR99 8536.69.4040 25
845-035-523-101 EDAC Inc. 845-035-523-101 58.3536
RFQ
 ECAD 1816 0.00000000 EDAC Inc. 845 Box Active -40°C ~ 125°C Through Hole - 845-035 Green Solder download ROHS3 Compliant REACH Unaffected 151-845-035-523-101 EAR99 8536.69.4040 25 0.100" (2.54mm) 1 Gold 10.0µin (0.25µm) Copper Alloy Cantilever 35 Female Non Specified - Single Edge 35 0.054" ~ 0.070" (1.37mm ~ 1.78mm) Single - Diallyl Phthalate (DAP) 1
807-074-522-258 EDAC Inc. 807-074-522-258 -
RFQ
 ECAD 3951 0.00000000 EDAC Inc. 807 Box Obsolete 807-074 download ROHS3 Compliant 1 (Unlimited) REACH Unaffected 151-807-074-522-258 EAR99 8536.69.4040 25
837-012-558-104 EDAC Inc. 837-012-558-104 42.9976
RFQ
 ECAD 9360 0.00000000 EDAC Inc. 837 Box Active -40°C ~ 125°C Through Hole, Right Angle - 837-012 Green Solder download ROHS3 Compliant REACH Unaffected 151-837-012-558-104 EAR99 8536.69.4040 25 0.156" (3.96mm) 1 Gold 10.0µin (0.25µm) Copper Alloy Cantilever 12 Female Non Specified - Single Edge 12 0.054" ~ 0.070" (1.37mm ~ 1.78mm) Single Flush Mount, Top Opening, Unthreaded, 0.156" (3.96mm) Dia Diallyl Phthalate (DAP) 1
807-040-557-108 EDAC Inc. 807-040-557-108 273.0988
RFQ
 ECAD 3217 0.00000000 EDAC Inc. 807 Box Active -40°C ~ 125°C Through Hole, Right Angle - 807-040 Green Solder download ROHS3 Compliant REACH Unaffected 151-807-040-557-108 EAR99 8536.69.4040 25 0.156" (3.96mm) 2 Gold 10.0µin (0.25µm) Copper Alloy Semi Bellows 80 Female Non Specified - Dual Edge 40 0.054" ~ 0.070" (1.37mm ~ 1.78mm) Dual Flush Mount, Top Opening, Threaded Insert, 4-40 Diallyl Phthalate (DAP) 1
845-050-558-208 EDAC Inc. 845-050-558-208 86.9400
RFQ
 ECAD 4145 0.00000000 EDAC Inc. 845 Box Active -40°C ~ 125°C Through Hole, Right Angle - 845-050 Green Solder download ROHS3 Compliant REACH Unaffected 151-845-050-558-208 EAR99 8536.69.4040 25 0.100" (2.54mm) 2 Gold 10.0µin (0.25µm) Copper Alloy Cantilever 50 Female Non Specified - Dual Edge 25 0.054" ~ 0.070" (1.37mm ~ 1.78mm) Dual Flush Mount, Top Opening, Threaded Insert, 4-40 Diallyl Phthalate (DAP) 2
395-036-524-402 EDAC Inc. 395-036-524-402 12.6312
RFQ
 ECAD 3405 0.00000000 EDAC Inc. 395 Box Active -40°C ~ 105°C Through Hole - 395-036 Black Solder download ROHS3 Compliant REACH Unaffected 151-395-036-524-402 EAR99 8536.69.4040 25 0.100" (2.54mm) 1 Gold 10.0µin (0.25µm) Copper Alloy Cantilever 36 Female Non Specified - Single Edge 36 0.054" ~ 0.070" (1.37mm ~ 1.78mm) Single Top Mount Opening, Unthreaded, 0.128" (3.25mm) Dia Polyester Thermoplastic 1
845-044-521-104 EDAC Inc. 845-044-521-104 83.8688
RFQ
 ECAD 7558 0.00000000 EDAC Inc. 845 Box Active -40°C ~ 125°C Through Hole - 845-044 Green Solder download ROHS3 Compliant REACH Unaffected 151-845-044-521-104 EAR99 8536.69.4040 25 0.100" (2.54mm) 1 Gold 10.0µin (0.25µm) Copper Alloy Cantilever 44 Female Non Specified - Single Edge 44 0.054" ~ 0.070" (1.37mm ~ 1.78mm) Single Flush Mount, Top Opening, Unthreaded, 0.156" (3.96mm) Dia Diallyl Phthalate (DAP) 1
837-013-520-604 EDAC Inc. 837-013-520-604 29.9136
RFQ
 ECAD 8732 0.00000000 EDAC Inc. 837 Box Active -40°C ~ 125°C Through Hole - 837-013 Green Solder download ROHS3 Compliant REACH Unaffected 151-837-013-520-604 EAR99 8536.69.4040 25 0.156" (3.96mm) 1 Gold 10.0µin (0.25µm) Copper Alloy Cantilever 13 Female Non Specified - Single Edge 13 0.054" ~ 0.070" (1.37mm ~ 1.78mm) Single Top Mount Opening, Unthreaded, 0.156" (3.96mm) Dia Diallyl Phthalate (DAP) 1
845-068-541-402 EDAC Inc. 845-068-541-402 144.4708
RFQ
 ECAD 7812 0.00000000 EDAC Inc. 845 Box Active -40°C ~ 125°C Through Hole - 845-068 Green Wire Wrap download ROHS3 Compliant REACH Unaffected 151-845-068-541-402 EAR99 8536.69.4040 25 0.100" (2.54mm) 1 Gold 10.0µin (0.25µm) Copper Alloy Cantilever 68 Female Non Specified - Single Edge 68 0.054" ~ 0.070" (1.37mm ~ 1.78mm) Single Top Mount Opening, Unthreaded, 0.128" (3.25mm) Dia Diallyl Phthalate (DAP) 1
395-018-521-158 EDAC Inc. 395-018-521-158 13.4076
RFQ
 ECAD 4648 0.00000000 EDAC Inc. 395 Box Active -40°C ~ 105°C Through Hole Card Guides 395-018 Black Solder download ROHS3 Compliant REACH Unaffected 151-395-018-521-158 EAR99 8536.69.4040 25 0.100" (2.54mm) 1 Gold 10.0µin (0.25µm) Copper Alloy Cantilever 18 Female Non Specified - Single Edge 18 0.054" ~ 0.070" (1.37mm ~ 1.78mm) Single Flush Mount, Top Opening, Threaded Insert, 4-40 Polyester Thermoplastic 1
845-112-542-508 EDAC Inc. 845-112-542-508 104.8952
RFQ
 ECAD 6109 0.00000000 EDAC Inc. 845 Box Active -40°C ~ 125°C Through Hole - 845-112 Green Wire Wrap download ROHS3 Compliant REACH Unaffected 151-845-112-542-508 EAR99 8536.69.4040 25 0.100" (2.54mm) 2 Gold 10.0µin (0.25µm) Copper Alloy Cantilever 112 Female Non Specified - Dual Edge 56 0.054" ~ 0.070" (1.37mm ~ 1.78mm) Dual Top Mount Opening, Threaded Insert, 4-40 Diallyl Phthalate (DAP) 2
395-070-555-503 EDAC Inc. 395-070-555-503 15.4888
RFQ
 ECAD 7442 0.00000000 EDAC Inc. 395 Box Active -40°C ~ 105°C Board Edge, Straddle Mount Card Extender 395-070 Black Solder Eyelet(s) download ROHS3 Compliant REACH Unaffected 151-395-070-555-503 EAR99 8536.69.4040 25 0.100" (2.54mm) 2 Gold 10.0µin (0.25µm) Copper Alloy Cantilever 70 Female Non Specified - Dual Edge 35 0.054" ~ 0.070" (1.37mm ~ 1.78mm) Dual Top Mount Opening, Floating Bobbin, 0.116" (2.95mm) Dia Polyester Thermoplastic 2
305-040-556-558 EDAC Inc. 305-040-556-558 14.2728
RFQ
 ECAD 3742 0.00000000 EDAC Inc. 305 Box Active -40°C ~ 105°C Board Edge, Straddle Mount Card Extender, Card Guides 305-040 Green Solder download ROHS3 Compliant Not Applicable REACH Unaffected 151-305-040-556-558 EAR99 8536.69.4040 25 0.156" (3.96mm) 2 Gold 10.0µin (0.25µm) Copper Alloy Semi Bellows 40 Female Non Specified - Dual Edge 20 0.054" ~ 0.070" (1.37mm ~ 1.78mm) Dual Flush Mount, Top Opening, Threaded Insert, 4-40 Polyester Thermoplastic 2
395-066-524-578 EDAC Inc. 395-066-524-578 13.7464
RFQ
 ECAD 9754 0.00000000 EDAC Inc. 395 Box Active -40°C ~ 105°C Through Hole Card Guides 395-066 Black Solder download ROHS3 Compliant REACH Unaffected 151-395-066-524-578 EAR99 8536.69.4040 25 0.100" (2.54mm) 2 Gold 10.0µin (0.25µm) Copper Alloy Cantilever 66 Female Non Specified - Dual Edge 33 0.054" ~ 0.070" (1.37mm ~ 1.78mm) Dual Top Mount Opening, Threaded Insert, 4-40 Polyester Thermoplastic 2
845-028-542-407 EDAC Inc. 845-028-542-407 72.8912
RFQ
 ECAD 4960 0.00000000 EDAC Inc. 845 Box Active -40°C ~ 125°C Through Hole - 845-028 Green Wire Wrap download ROHS3 Compliant REACH Unaffected 151-845-028-542-407 EAR99 8536.69.4040 25 0.100" (2.54mm) 1 Gold 10.0µin (0.25µm) Copper Alloy Cantilever 28 Female Non Specified - Single Edge 28 0.054" ~ 0.070" (1.37mm ~ 1.78mm) Single Top Mount Opening, Threaded Insert, M3 Diallyl Phthalate (DAP) 1
837-017-523-168 EDAC Inc. 837-017-523-168 -
RFQ
 ECAD 1176 0.00000000 EDAC Inc. 837 Box Obsolete 837-017 - ROHS3 Compliant 1 (Unlimited) REACH Unaffected 151-837-017-523-168 EAR99 8536.69.4040 25
395-016-524-507 EDAC Inc. 395-016-524-507 9.4688
RFQ
 ECAD 3218 0.00000000 EDAC Inc. 395 Box Active -40°C ~ 105°C Through Hole - 395-016 Black Solder download ROHS3 Compliant REACH Unaffected 151-395-016-524-507 EAR99 8536.69.4040 25 0.100" (2.54mm) 2 Gold 10.0µin (0.25µm) Copper Alloy Cantilever 16 Female Non Specified - Dual Edge 8 0.054" ~ 0.070" (1.37mm ~ 1.78mm) Dual Top Mount Opening, Threaded Insert, M3 Polyester Thermoplastic 2
833-009-540-102 EDAC Inc. 833-009-540-102 25.2752
RFQ
 ECAD 2355 0.00000000 EDAC Inc. 833 Box Active -40°C ~ 125°C Through Hole - 833-009 Green Wire Wrap download ROHS3 Compliant REACH Unaffected 151-833-009-540-102 EAR99 8536.69.4040 25 0.156" (3.96mm) 1 Gold 10.0µin (0.25µm) Copper Alloy Cantilever 9 Female Non Specified - Single Edge 9 0.054" ~ 0.070" (1.37mm ~ 1.78mm) Single Flush Mount, Top Opening, Unthreaded, 0.128" (3.25mm) Dia Diallyl Phthalate (DAP) 1
807-082-524-202 EDAC Inc. 807-082-524-202 117.1800
RFQ
 ECAD 1973 0.00000000 EDAC Inc. 807 Box Active -40°C ~ 125°C Through Hole - 807-082 Green Solder download ROHS3 Compliant REACH Unaffected 151-807-082-524-202 EAR99 8536.69.4040 25 0.156" (3.96mm) 2 Gold 10.0µin (0.25µm) Copper Alloy Semi Bellows 82 Female Non Specified - Dual Edge 41 0.054" ~ 0.070" (1.37mm ~ 1.78mm) Dual Flush Mount, Top Opening, Unthreaded, 0.128" (3.25mm) Dia Diallyl Phthalate (DAP) 2
845-138-558-812 EDAC Inc. 845-138-558-812 138.0960
RFQ
 ECAD 3572 0.00000000 EDAC Inc. 845 Box Active -40°C ~ 125°C Through Hole, Right Angle - 845-138 Green Solder download ROHS3 Compliant REACH Unaffected 151-845-138-558-812 EAR99 8536.69.4040 25 0.100" (2.54mm) 2 Gold 10.0µin (0.25µm) Copper Alloy Cantilever 138 Female Non Specified - Dual Edge 69 0.054" ~ 0.070" (1.37mm ~ 1.78mm) Dual Side Mount Opening, Unthreaded, 0.128" (3.25mm) Dia Diallyl Phthalate (DAP) 2
845-060-558-502 EDAC Inc. 845-060-558-502 76.5448
RFQ
 ECAD 6212 0.00000000 EDAC Inc. 845 Box Active -40°C ~ 125°C Through Hole, Right Angle - 845-060 Green Solder download ROHS3 Compliant REACH Unaffected 151-845-060-558-502 EAR99 8536.69.4040 25 0.100" (2.54mm) 2 Gold 10.0µin (0.25µm) Copper Alloy Cantilever 60 Female Non Specified - Dual Edge 30 0.054" ~ 0.070" (1.37mm ~ 1.78mm) Dual Top Mount Opening, Unthreaded, 0.128" (3.25mm) Dia Diallyl Phthalate (DAP) 2
395-028-520-802 EDAC Inc. 395-028-520-802 7.9568
RFQ
 ECAD 3610 0.00000000 EDAC Inc. 395 Box Active -40°C ~ 105°C Through Hole - 395-028 Black Solder download ROHS3 Compliant REACH Unaffected 151-395-028-520-802 EAR99 8536.69.4040 25 0.100" (2.54mm) 2 Gold 10.0µin (0.25µm) Copper Alloy Cantilever 28 Female Non Specified - Dual Edge 14 0.054" ~ 0.070" (1.37mm ~ 1.78mm) Dual Top Mount Opening, Unthreaded, 0.128" (3.25mm) Dia Polyester Thermoplastic 2
395-063-520-603 EDAC Inc. 395-063-520-603 16.1404
RFQ
 ECAD 9732 0.00000000 EDAC Inc. 395 Box Active -40°C ~ 105°C Through Hole - 395-063 Black Solder download ROHS3 Compliant REACH Unaffected 151-395-063-520-603 EAR99 8536.69.4040 25 0.100" (2.54mm) 1 Gold 10.0µin (0.25µm) Copper Alloy Cantilever 63 Female Non Specified - Single Edge 63 0.054" ~ 0.070" (1.37mm ~ 1.78mm) Single Top Mount Opening, Floating Bobbin, 0.116" (2.95mm) Dia Polyester Thermoplastic 1
746-084-545-601 EDAC Inc. 746-084-545-601 14.0008
RFQ
 ECAD 9908 0.00000000 EDAC Inc. 746 Box Active -40°C ~ 105°C Through Hole - 746-084 Black Press-Fit, Wire Wrap download ROHS3 Compliant REACH Unaffected 151-746-084-545-601 EAR99 8536.69.4040 25 0.125" (3.18mm) 2 Gold 30.0µin (0.76µm) Copper Alloy Cantilever 84 Female Non Specified - Dual Edge 42 0.054" ~ 0.070" (1.37mm ~ 1.78mm) Dual - Polyester Thermoplastic 2
