Card Edge Connectors(468861)
| Image | Product Number | Pricing(USD) | Quantity | ECAD | Quantity Available | Weight(Kg) | Mfr | Series | Package | Product Status | Operating Temperature | Mounting Type | Features | Base Product Number | Color | Termination | DataSheet | RoHS Status | Moisture Sensitivity Level (MSL) | REACH Status | Other Names | ECCN | HTSUS | Standard Package | Pitch | Number of Rows | Contact Finish | Contact Finish Thickness | Contact Material | Contact Type | Number of Positions | Gender | Card Type | Number of Positions/Bay/Row | Card Thickness | Read Out | Flange Feature | Material - Insulation | Termination Rows |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
345-126-524-512 | 17.1212 |  |
6075 | 0.00000000 | EDAC Inc. | 345 | Box | Active | -40°C ~ 105°C | Through Hole | - | 345-126 | Green | Solder | download | ROHS3 Compliant | REACH Unaffected | 151-345-126-524-512 | EAR99 | 8536.69.4040 | 25 | 0.100" (2.54mm) | 2 | Gold | 10.0µin (0.25µm) | Copper Alloy | Cantilever | 126 | Female | Non Specified - Dual Edge | 63 | 0.054" ~ 0.070" (1.37mm ~ 1.78mm) | Dual | Side Mount Opening, Unthreaded, 0.128" (3.25mm) Dia | Polyester Thermoplastic | 2 | ||
 |
833-068-556-808 | 86.7036 | |
4367 | 0.00000000 | EDAC Inc. | 833 | Box | Active | -40°C ~ 125°C | Board Edge, Straddle Mount | Card Extender | 833-068 | Green | Solder | download | ROHS3 Compliant | REACH Unaffected | 151-833-068-556-808 | EAR99 | 8536.69.4040 | 25 | 0.156" (3.96mm) | 2 | Gold | 10.0µin (0.25µm) | Copper Alloy | Cantilever | 68 | Female | Non Specified - Dual Edge | 34 | 0.054" ~ 0.070" (1.37mm ~ 1.78mm) | Dual | Top Mount Opening, Threaded Insert, 4-40 | Diallyl Phthalate (DAP) | 2 | ||
 |
845-082-556-202 | 89.9008 | |
8501 | 0.00000000 | EDAC Inc. | 845 | Box | Active | -40°C ~ 125°C | Board Edge, Straddle Mount | Card Extender | 845-082 | Green | Solder | download | ROHS3 Compliant | REACH Unaffected | 151-845-082-556-202 | EAR99 | 8536.69.4040 | 25 | 0.100" (2.54mm) | 2 | Gold | 10.0µin (0.25µm) | Copper Alloy | Cantilever | 82 | Female | Non Specified - Dual Edge | 41 | 0.054" ~ 0.070" (1.37mm ~ 1.78mm) | Dual | Flush Mount, Top Opening, Unthreaded, 0.128" (3.25mm) Dia | Diallyl Phthalate (DAP) | 2 | ||
 |
396-036-540-612 | 13.4268 | |
7712 | 0.00000000 | EDAC Inc. | 396 | Box | Active | -40°C ~ 105°C | Through Hole | - | 396-036 | Black | Wire Wrap | download | ROHS3 Compliant | REACH Unaffected | 151-396-036-540-612 | EAR99 | 8536.69.4040 | 25 | 0.125" (3.18mm) | 1 | Gold | 10.0µin (0.25µm) | Copper Alloy | Cantilever | 36 | Female | Non Specified - Single Edge | 36 | 0.054" ~ 0.070" (1.37mm ~ 1.78mm) | Single | Side Mount Opening, Unthreaded, 0.128" (3.25mm) Dia | Polyester Thermoplastic | 1 | ||
 |
807-038-542-203 | 86.3572 | |
7429 | 0.00000000 | EDAC Inc. | 807 | Box | Active | -40°C ~ 125°C | Through Hole | - | 807-038 | Green | Wire Wrap | download | ROHS3 Compliant | REACH Unaffected | 151-807-038-542-203 | EAR99 | 8536.69.4040 | 25 | 0.156" (3.96mm) | 2 | Gold | 10.0µin (0.25µm) | Copper Alloy | Semi Bellows | 38 | Female | Non Specified - Dual Edge | 19 | 0.054" ~ 0.070" (1.37mm ~ 1.78mm) | Dual | Flush Mount, Floating Bobbin, 0.116" (2.95mm) Dia | Diallyl Phthalate (DAP) | 2 | ||
 |
395-051-542-688 | 17.1088 | |
2980 | 0.00000000 | EDAC Inc. | 395 | Box | Active | -40°C ~ 105°C | Through Hole | Card Guides | 395-051 | Black | Wire Wrap | download | ROHS3 Compliant | REACH Unaffected | 151-395-051-542-688 | EAR99 | 8536.69.4040 | 25 | 0.100" (2.54mm) | 1 | Gold | 10.0µin (0.25µm) | Copper Alloy | Cantilever | 51 | Female | Non Specified - Single Edge | 51 | 0.054" ~ 0.070" (1.37mm ~ 1.78mm) | Single | Top Mount Opening, Threaded Insert, 4-40 | Polyester Thermoplastic | 1 | ||
 |
346-058-521-808 | 12.5744 | |
5723 | 0.00000000 | EDAC Inc. | 346 | Box | Active | -40°C ~ 105°C | Through Hole | - | 346-058 | Green | Solder | download | ROHS3 Compliant | REACH Unaffected | 151-346-058-521-808 | EAR99 | 8536.69.4040 | 25 | 0.125" (3.18mm) | 2 | Gold | 10.0µin (0.25µm) | Copper Alloy | Cantilever | 58 | Female | Non Specified - Dual Edge | 29 | 0.054" ~ 0.070" (1.37mm ~ 1.78mm) | Dual | Top Mount Opening, Threaded Insert, 4-40 | Polyester Thermoplastic | 2 | ||
 |
346-092-559-207 | 16.6412 | |
4357 | 0.00000000 | EDAC Inc. | 346 | Box | Active | -40°C ~ 105°C | Through Hole, Right Angle | - | 346-092 | Green | Solder, Wire Wrap | download | ROHS3 Compliant | REACH Unaffected | 151-346-092-559-207 | EAR99 | 8536.69.4040 | 25 | 0.125" (3.18mm) | 2 | Gold | 10.0µin (0.25µm) | Copper Alloy | Cantilever | 92 | Female | Non Specified - Dual Edge | 46 | 0.054" ~ 0.070" (1.37mm ~ 1.78mm) | Dual | Flush Mount, Top Opening, Threaded Insert, M3 | Polyester Thermoplastic | 2 | ||
 |
395-023-541-178 | 14.1840 | |
9663 | 0.00000000 | EDAC Inc. | 395 | Box | Active | -40°C ~ 105°C | Through Hole | Card Guides | 395-023 | Black | Wire Wrap | download | ROHS3 Compliant | REACH Unaffected | 151-395-023-541-178 | EAR99 | 8536.69.4040 | 25 | 0.100" (2.54mm) | 1 | Gold | 10.0µin (0.25µm) | Copper Alloy | Cantilever | 23 | Female | Non Specified - Single Edge | 23 | 0.054" ~ 0.070" (1.37mm ~ 1.78mm) | Single | Flush Mount, Top Opening, Threaded Insert, 4-40 | Polyester Thermoplastic | 1 | ||
 |
346-052-558-201 | 12.1956 | |
6028 | 0.00000000 | EDAC Inc. | 346 | Box | Active | -40°C ~ 105°C | Through Hole, Right Angle | - | 346-052 | Green | Solder, Wire Wrap | download | ROHS3 Compliant | REACH Unaffected | 151-346-052-558-201 | EAR99 | 8536.69.4040 | 25 | 0.125" (3.18mm) | 2 | Gold | 10.0µin (0.25µm) | Copper Alloy | Cantilever | 52 | Female | Non Specified - Dual Edge | 26 | 0.054" ~ 0.070" (1.37mm ~ 1.78mm) | Dual | - | Polyester Thermoplastic | 2 | ||
 |
345-120-520-588 | 17.0888 | |
7499 | 0.00000000 | EDAC Inc. | 345 | Box | Active | -40°C ~ 105°C | Through Hole | Card Guides | 345-120 | Green | Solder | download | ROHS3 Compliant | REACH Unaffected | 151-345-120-520-588 | EAR99 | 8536.69.4040 | 25 | 0.100" (2.54mm) | 2 | Gold | 10.0µin (0.25µm) | Copper Alloy | Cantilever | 120 | Female | Non Specified - Dual Edge | 60 | 0.054" ~ 0.070" (1.37mm ~ 1.78mm) | Dual | Top Mount Opening, Threaded Insert, 4-40 | Polyester Thermoplastic | 2 | ||
 |
395-022-560-201 | 9.5636 | |
2777 | 0.00000000 | EDAC Inc. | 395 | Box | Active | -40°C ~ 105°C | Board Edge, Straddle Mount | Card Extender | 395-022 | Black | Solder | download | ROHS3 Compliant | REACH Unaffected | 151-395-022-560-201 | EAR99 | 8536.69.4040 | 25 | 0.100" (2.54mm) | 2 | Gold | 10.0µin (0.25µm) | Copper Alloy | Cantilever | 22 | Female | Non Specified - Dual Edge | 11 | 0.054" ~ 0.070" (1.37mm ~ 1.78mm) | Dual | - | Polyester Thermoplastic | 2 | ||
 |
837-086-500-208 | 177.7040 | |
8805 | 0.00000000 | EDAC Inc. | 837 | Box | Active | -40°C ~ 125°C | Through Hole | - | 837-086 | Green | Solder Eyelet(s) | download | ROHS3 Compliant | REACH Unaffected | 151-837-086-500-208 | EAR99 | 8536.69.4040 | 25 | 0.156" (3.96mm) | 2 | Gold | 10.0µin (0.25µm) | Copper Alloy | Cantilever | 86 | Female | Non Specified - Dual Edge | 43 | 0.054" ~ 0.070" (1.37mm ~ 1.78mm) | Dual | Flush Mount, Top Opening, Threaded Insert, 4-40 | Diallyl Phthalate (DAP) | 2 | ||
 |
807-034-557-102 | 227.3008 | |
8402 | 0.00000000 | EDAC Inc. | 807 | Box | Active | -40°C ~ 125°C | Through Hole, Right Angle | - | 807-034 | Green | Solder | download | ROHS3 Compliant | REACH Unaffected | 151-807-034-557-102 | EAR99 | 8536.69.4040 | 25 | 0.156" (3.96mm) | 2 | Gold | 10.0µin (0.25µm) | Copper Alloy | Semi Bellows | 68 | Female | Non Specified - Dual Edge | 34 | 0.054" ~ 0.070" (1.37mm ~ 1.78mm) | Dual | Flush Mount, Top Opening, Unthreaded, 0.128" (3.25mm) Dia | Diallyl Phthalate (DAP) | 1 | ||
 |
845-132-559-508 | 139.6236 | |
8012 | 0.00000000 | EDAC Inc. | 845 | Box | Active | -40°C ~ 125°C | Through Hole, Right Angle | - | 845-132 | Green | Solder | download | ROHS3 Compliant | REACH Unaffected | 151-845-132-559-508 | EAR99 | 8536.69.4040 | 25 | 0.100" (2.54mm) | 2 | Gold | 10.0µin (0.25µm) | Copper Alloy | Cantilever | 132 | Female | Non Specified - Dual Edge | 66 | 0.054" ~ 0.070" (1.37mm ~ 1.78mm) | Dual | Top Mount Opening, Threaded Insert, 4-40 | Diallyl Phthalate (DAP) | 2 | ||
 |
845-108-542-212 | 98.0436 | |
5162 | 0.00000000 | EDAC Inc. | 845 | Box | Active | -40°C ~ 125°C | Through Hole | - | 845-108 | Green | Wire Wrap | download | ROHS3 Compliant | REACH Unaffected | 151-845-108-542-212 | EAR99 | 8536.69.4040 | 25 | 0.100" (2.54mm) | 2 | Gold | 10.0µin (0.25µm) | Copper Alloy | Cantilever | 108 | Female | Non Specified - Dual Edge | 54 | 0.054" ~ 0.070" (1.37mm ~ 1.78mm) | Dual | Flush Mount, Side Opening, Unthreaded, 0.128" (3.25mm) Dia | Diallyl Phthalate (DAP) | 2 | ||
 |
846-062-521-807 | 75.4896 | |
9933 | 0.00000000 | EDAC Inc. | 846 | Box | Active | -40°C ~ 125°C | Through Hole | - | 846-062 | Green | Solder | download | ROHS3 Compliant | REACH Unaffected | 151-846-062-521-807 | EAR99 | 8536.69.4040 | 25 | 0.125" (3.18mm) | 2 | Gold | 10.0µin (0.25µm) | Copper Alloy | Cantilever | 62 | Female | Non Specified - Dual Edge | 31 | 0.054" ~ 0.070" (1.37mm ~ 1.78mm) | Dual | Top Mount Opening, Threaded Insert, M3 | Diallyl Phthalate (DAP) | 2 | ||
 |
842-012-559-103 | 94.2636 | |
9726 | 0.00000000 | EDAC Inc. | 842 | Box | Active | -40°C ~ 125°C | Through Hole, Right Angle | - | 842-012 | Green | Solder | download | ROHS3 Compliant | REACH Unaffected | 151-842-012-559-103 | EAR99 | 8536.69.4040 | 25 | 0.100" (2.54mm) | 1 | Gold | 10.0µin (0.25µm) | Copper Alloy | Cantilever | 12 | Female | Non Specified - Single Edge | 12 | 0.054" ~ 0.070" (1.37mm ~ 1.78mm) | Single | Flush Mount, Floating Bobbin, 0.116" (2.95mm) Dia | Diallyl Phthalate (DAP) | 1 | ||
 |
833-060-520-808 | 67.2208 | |
4525 | 0.00000000 | EDAC Inc. | 833 | Box | Active | -40°C ~ 125°C | Through Hole | - | 833-060 | Green | Solder | download | ROHS3 Compliant | REACH Unaffected | 151-833-060-520-808 | EAR99 | 8536.69.4040 | 25 | 0.156" (3.96mm) | 2 | Gold | 10.0µin (0.25µm) | Copper Alloy | Cantilever | 60 | Female | Non Specified - Dual Edge | 30 | 0.054" ~ 0.070" (1.37mm ~ 1.78mm) | Dual | Top Mount Opening, Threaded Insert, 4-40 | Diallyl Phthalate (DAP) | 2 | ||
 |
392-051-541-112 | 22.2772 | |
8875 | 0.00000000 | EDAC Inc. | 392 | Box | Active | -40°C ~ 105°C | Through Hole | - | 392-051 | Black | Wire Wrap | download | ROHS3 Compliant | REACH Unaffected | 151-392-051-541-112 | EAR99 | 8536.69.4040 | 25 | 0.100" (2.54mm) | 1 | Gold | 10.0µin (0.25µm) | Copper Alloy | Cantilever | 51 | Female | Non Specified - Single Edge | 51 | 0.054" ~ 0.070" (1.37mm ~ 1.78mm) | Single | Flush Mount, Side Opening, Unthreaded, 0.128" (3.25mm) Dia | Polyester Thermoplastic | 1 | ||
 |
408-041-503-212 | - | |
6952 | 0.00000000 | EDAC Inc. | 408 | Tray | Obsolete | -65°C ~ 125°C | - | Card Guides | 408-041 | Green | - | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | 151-408-041-503-212 | EAR99 | 8536.69.4040 | 25 | 0.100" (2.54mm) | 1 | Gold | - | Copper Alloy | - | 41 | Female | Non Specified - Single Edge | 41 | 0.062" (1.57mm) | Single | Top Mount Opening, Unthreaded, 0.128" (3.25mm) Dia | Diallyl Phthalate (DAP) | ||
 |
346-034-558-201 | 10.3588 | |
2067 | 0.00000000 | EDAC Inc. | 346 | Box | Active | -40°C ~ 105°C | Through Hole, Right Angle | - | 346-034 | Green | Solder, Wire Wrap | download | ROHS3 Compliant | REACH Unaffected | 151-346-034-558-201 | EAR99 | 8536.69.4040 | 25 | 0.125" (3.18mm) | 2 | Gold | 10.0µin (0.25µm) | Copper Alloy | Cantilever | 34 | Female | Non Specified - Dual Edge | 17 | 0.054" ~ 0.070" (1.37mm ~ 1.78mm) | Dual | - | Polyester Thermoplastic | 2 | ||
 |
345-108-555-503 | 17.3816 | |
2048 | 0.00000000 | EDAC Inc. | 345 | Box | Active | -40°C ~ 105°C | Board Edge, Straddle Mount | Card Extender | 345-108 | Green | Solder Eyelet(s) | download | ROHS3 Compliant | REACH Unaffected | 151-345-108-555-503 | EAR99 | 8536.69.4040 | 25 | 0.100" (2.54mm) | 2 | Gold | 10.0µin (0.25µm) | Copper Alloy | Cantilever | 108 | Female | Non Specified - Dual Edge | 54 | 0.054" ~ 0.070" (1.37mm ~ 1.78mm) | Dual | Top Mount Opening, Floating Bobbin, 0.116" (2.95mm) Dia | Polyester Thermoplastic | 2 | ||
 |
395-069-541-403 | 16.9232 | |
5535 | 0.00000000 | EDAC Inc. | 395 | Box | Active | -40°C ~ 105°C | Through Hole | - | 395-069 | Black | Wire Wrap | download | ROHS3 Compliant | REACH Unaffected | 151-395-069-541-403 | EAR99 | 8536.69.4040 | 25 | 0.100" (2.54mm) | 1 | Gold | 10.0µin (0.25µm) | Copper Alloy | Cantilever | 69 | Female | Non Specified - Single Edge | 69 | 0.054" ~ 0.070" (1.37mm ~ 1.78mm) | Single | Top Mount Opening, Floating Bobbin, 0.116" (2.95mm) Dia | Polyester Thermoplastic | 1 | ||
 |
837-021-558-603 | 68.8748 | |
1628 | 0.00000000 | EDAC Inc. | 837 | Box | Active | -40°C ~ 125°C | Through Hole, Right Angle | - | 837-021 | Green | Solder | download | ROHS3 Compliant | REACH Unaffected | 151-837-021-558-603 | EAR99 | 8536.69.4040 | 25 | 0.156" (3.96mm) | 1 | Gold | 10.0µin (0.25µm) | Copper Alloy | Cantilever | 21 | Female | Non Specified - Single Edge | 21 | 0.054" ~ 0.070" (1.37mm ~ 1.78mm) | Single | Top Mount Opening, Floating Bobbin, 0.116" (2.95mm) Dia | Diallyl Phthalate (DAP) | 1 | ||
 |
346-076-560-812 | 14.6524 | |
5524 | 0.00000000 | EDAC Inc. | 346 | Box | Active | -40°C ~ 105°C | Board Edge, Straddle Mount | Card Extender | 346-076 | Green | Solder | download | ROHS3 Compliant | REACH Unaffected | 151-346-076-560-812 | EAR99 | 8536.69.4040 | 25 | 0.125" (3.18mm) | 2 | Gold | 10.0µin (0.25µm) | Copper Alloy | Cantilever | 76 | Female | Non Specified - Dual Edge | 38 | 0.054" ~ 0.070" (1.37mm ~ 1.78mm) | Dual | Side Mount Opening, Unthreaded, 0.128" (3.25mm) Dia | Polyester Thermoplastic | 2 | ||
 |
846-050-526-807 | 71.2372 | |
5535 | 0.00000000 | EDAC Inc. | 846 | Box | Active | -40°C ~ 125°C | Through Hole | - | 846-050 | Green | Solder | download | ROHS3 Compliant | REACH Unaffected | 151-846-050-526-807 | EAR99 | 8536.69.4040 | 25 | 0.125" (3.18mm) | 2 | Gold | 10.0µin (0.25µm) | Copper Alloy | Cantilever | 50 | Female | Non Specified - Dual Edge | 25 | 0.054" ~ 0.070" (1.37mm ~ 1.78mm) | Dual | Top Mount Opening, Threaded Insert, M3 | Diallyl Phthalate (DAP) | 2 | ||
 |
846-049-520-602 | 54.1012 | |
7712 | 0.00000000 | EDAC Inc. | 846 | Box | Active | -40°C ~ 125°C | Through Hole | - | 846-049 | Green | Solder | download | ROHS3 Compliant | REACH Unaffected | 151-846-049-520-602 | EAR99 | 8536.69.4040 | 25 | 0.125" (3.18mm) | 1 | Gold | 10.0µin (0.25µm) | Copper Alloy | Cantilever | 49 | Female | Non Specified - Single Edge | 49 | 0.054" ~ 0.070" (1.37mm ~ 1.78mm) | Single | Top Mount Opening, Unthreaded, 0.128" (3.25mm) Dia | Diallyl Phthalate (DAP) | 1 | ||
 |
395-019-521-101 | 9.9612 | |
2824 | 0.00000000 | EDAC Inc. | 395 | Box | Active | -40°C ~ 105°C | Through Hole | - | 395-019 | Black | Solder | download | ROHS3 Compliant | REACH Unaffected | 151-395-019-521-101 | EAR99 | 8536.69.4040 | 25 | 0.100" (2.54mm) | 1 | Gold | 10.0µin (0.25µm) | Copper Alloy | Cantilever | 19 | Female | Non Specified - Single Edge | 19 | 0.054" ~ 0.070" (1.37mm ~ 1.78mm) | Single | - | Polyester Thermoplastic | 1 | ||
 |
346-080-520-212 | 14.0896 | |
9032 | 0.00000000 | EDAC Inc. | 346 | Box | Active | -40°C ~ 105°C | Through Hole | - | 346-080 | Green | Solder | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | 151-346-080-520-212 | EAR99 | 8536.69.4040 | 25 | 0.125" (3.18mm) | 2 | Gold | 10.0µin (0.25µm) | Copper Alloy | Cantilever | 80 | Female | Non Specified - Dual Edge | 40 | 0.054" ~ 0.070" (1.37mm ~ 1.78mm) | Dual | Flush Mount, Side Opening, Unthreaded, 0.128" (3.25mm) Dia | Polyester Thermoplastic | 2 |
