Card Edge Connectors(468861)
| Image | Product Number | Pricing(USD) | Quantity | ECAD | Quantity Available | Weight(Kg) | Mfr | Series | Package | Product Status | Operating Temperature | Mounting Type | Features | Base Product Number | Color | Termination | DataSheet | RoHS Status | Moisture Sensitivity Level (MSL) | REACH Status | Other Names | ECCN | HTSUS | Standard Package | Pitch | Number of Rows | Contact Finish | Contact Finish Thickness | Contact Material | Contact Type | Number of Positions | Gender | Card Type | Number of Positions/Bay/Row | Card Thickness | Read Out | Flange Feature | Material - Insulation | Termination Rows |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
845-046-559-108 | 115.9988 |  |
2522 | 0.00000000 | EDAC Inc. | 845 | Box | Active | -40°C ~ 125°C | Through Hole, Right Angle | - | 845-046 | Green | Solder | download | ROHS3 Compliant | REACH Unaffected | 151-845-046-559-108 | EAR99 | 8536.69.4040 | 25 | 0.100" (2.54mm) | 1 | Gold | 10.0µin (0.25µm) | Copper Alloy | Cantilever | 46 | Female | Non Specified - Single Edge | 46 | 0.054" ~ 0.070" (1.37mm ~ 1.78mm) | Single | Flush Mount, Top Opening, Threaded Insert, 4-40 | Diallyl Phthalate (DAP) | 1 | ||
 |
846-048-521-258 | - | |
3125 | 0.00000000 | EDAC Inc. | 846 | Box | Obsolete | -40°C ~ 125°C | Through Hole | Card Guides | 846-048 | Green | Solder | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | 151-846-048-521-258 | EAR99 | 8536.69.4040 | 25 | 0.125" (3.18mm) | 2 | Gold | - | Copper Alloy | - | 48 | Female | Non Specified - Dual Edge | 24 | 0.062" (1.57mm) | Dual | Flush Mount, Top Opening, Threaded Insert, 4-40 | Diallyl Phthalate (DAP) | ||
 |
846-028-559-203 | 73.4736 | |
6716 | 0.00000000 | EDAC Inc. | 846 | Box | Active | -40°C ~ 125°C | Through Hole, Right Angle | - | 846-028 | Green | Solder | download | ROHS3 Compliant | REACH Unaffected | 151-846-028-559-203 | EAR99 | 8536.69.4040 | 25 | 0.125" (3.18mm) | 2 | Gold | 10.0µin (0.25µm) | Copper Alloy | Cantilever | 28 | Female | Non Specified - Dual Edge | 14 | 0.054" ~ 0.070" (1.37mm ~ 1.78mm) | Dual | Flush Mount, Floating Bobbin, 0.116" (2.95mm) Dia | Diallyl Phthalate (DAP) | 2 | ||
 |
837-030-500-103 | 143.3028 | |
6240 | 0.00000000 | EDAC Inc. | 837 | Box | Active | -40°C ~ 125°C | Through Hole | - | 837-030 | Green | Solder Eyelet(s) | download | ROHS3 Compliant | REACH Unaffected | 151-837-030-500-103 | EAR99 | 8536.69.4040 | 25 | 0.156" (3.96mm) | 1 | Gold | 10.0µin (0.25µm) | Copper Alloy | Cantilever | 30 | Female | Non Specified - Single Edge | 30 | 0.054" ~ 0.070" (1.37mm ~ 1.78mm) | Single | Flush Mount, Floating Bobbin, 0.116" (2.95mm) Dia | Diallyl Phthalate (DAP) | 1 | ||
 |
307-042-559-103 | 25.8608 | |
5234 | 0.00000000 | EDAC Inc. | 307 | Box | Active | -40°C ~ 105°C | Through Hole, Right Angle | - | 307-042 | Green | Solder | download | ROHS3 Compliant | Not Applicable | REACH Unaffected | 151-307-042-559-103 | EAR99 | 8536.69.4040 | 25 | 0.156" (3.96mm) | 1 | Gold | 10.0µin (0.25µm) | Copper Alloy | Semi Bellows | 42 | Female | Non Specified - Single Edge | 42 | 0.054" ~ 0.070" (1.37mm ~ 1.78mm) | Single | Flush Mount, Floating Bobbin, 0.116" (2.95mm) Dia | Polyester Thermoplastic | 1 | |
 |
746-064-527-201 | 10.0408 | |
4270 | 0.00000000 | EDAC Inc. | 746 | Box | Active | -40°C ~ 105°C | Through Hole | - | 746-064 | Black | Press-Fit | download | ROHS3 Compliant | REACH Unaffected | 151-746-064-527-201 | EAR99 | 8536.69.4040 | 25 | 0.125" (3.18mm) | 2 | Gold | 30.0µin (0.76µm) | Copper Alloy | Cantilever | 64 | Female | Non Specified - Dual Edge | 32 | 0.054" ~ 0.070" (1.37mm ~ 1.78mm) | Dual | - | Polyester Thermoplastic | 2 | ||
 |
807-008-553-112 | 111.7464 | |
7713 | 0.00000000 | EDAC Inc. | 807 | Box | Active | -40°C ~ 125°C | Through Hole, Right Angle | - | 807-008 | Green | Solder | download | ROHS3 Compliant | REACH Unaffected | 151-807-008-553-112 | EAR99 | 8536.69.4040 | 25 | 0.156" (3.96mm) | 2 | Gold | 10.0µin (0.25µm) | Copper Alloy | Semi Bellows | 16 | Female | Non Specified - Dual Edge | 8 | 0.054" ~ 0.070" (1.37mm ~ 1.78mm) | Dual | Side Mount Opening, Unthreaded, 0.128" (3.25mm) Dia | Diallyl Phthalate (DAP) | 1 | ||
 |
833-078-556-204 | 75.9624 | |
9122 | 0.00000000 | EDAC Inc. | 833 | Box | Active | -40°C ~ 125°C | Board Edge, Straddle Mount | Card Extender | 833-078 | Green | Solder | download | ROHS3 Compliant | REACH Unaffected | 151-833-078-556-204 | EAR99 | 8536.69.4040 | 25 | 0.156" (3.96mm) | 2 | Gold | 10.0µin (0.25µm) | Copper Alloy | Cantilever | 78 | Female | Non Specified - Dual Edge | 39 | 0.054" ~ 0.070" (1.37mm ~ 1.78mm) | Dual | Flush Mount, Top Opening, Unthreaded, 0.156" (3.96mm) Dia | Diallyl Phthalate (DAP) | 2 | ||
 |
345-057-524-608 | 19.6112 | |
6920 | 0.00000000 | EDAC Inc. | 345 | Box | Active | -40°C ~ 105°C | Through Hole | - | 345-057 | Green | Solder | download | ROHS3 Compliant | REACH Unaffected | 151-345-057-524-608 | EAR99 | 8536.69.4040 | 25 | 0.100" (2.54mm) | 1 | Gold | 10.0µin (0.25µm) | Copper Alloy | Cantilever | 57 | Female | Non Specified - Single Edge | 57 | 0.054" ~ 0.070" (1.37mm ~ 1.78mm) | Single | Top Mount Opening, Threaded Insert, 4-40 | Polyester Thermoplastic | 1 | ||
|
845-090-559-878 | - | |
8944 | 0.00000000 | EDAC Inc. | 845 | Box | Obsolete | 845-090 | - | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | 151-845-090-559-878 | EAR99 | 8536.69.4040 | 25 | |||||||||||||||||||||
 |
837-020-500-612 | 120.4876 | |
6956 | 0.00000000 | EDAC Inc. | 837 | Box | Active | -40°C ~ 125°C | Through Hole | - | 837-020 | Green | Solder Eyelet(s) | download | ROHS3 Compliant | REACH Unaffected | 151-837-020-500-612 | EAR99 | 8536.69.4040 | 25 | 0.156" (3.96mm) | 1 | Gold | 10.0µin (0.25µm) | Copper Alloy | Cantilever | 20 | Female | Non Specified - Single Edge | 20 | 0.054" ~ 0.070" (1.37mm ~ 1.78mm) | Single | Side Mount Opening, Unthreaded, 0.128" (3.25mm) Dia | Diallyl Phthalate (DAP) | 1 | ||
 |
345-140-521-578 | 20.2788 | |
1742 | 0.00000000 | EDAC Inc. | 345 | Box | Active | -40°C ~ 105°C | Through Hole | Card Guides | 345-140 | Green | Solder | download | ROHS3 Compliant | REACH Unaffected | 151-345-140-521-578 | EAR99 | 8536.69.4040 | 25 | 0.100" (2.54mm) | 2 | Gold | 10.0µin (0.25µm) | Copper Alloy | Cantilever | 140 | Female | Non Specified - Dual Edge | 70 | 0.054" ~ 0.070" (1.37mm ~ 1.78mm) | Dual | Top Mount Opening, Threaded Insert, 4-40 | Polyester Thermoplastic | 2 | ||
|
807-007-531-158 | - | |
4978 | 0.00000000 | EDAC Inc. | 807 | Box | Obsolete | 807-007 | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | 151-807-007-531-158 | EAR99 | 8536.69.4040 | 25 | |||||||||||||||||||||
 |
846-015-526-607 | 53.7548 | |
1434 | 0.00000000 | EDAC Inc. | 846 | Box | Active | -40°C ~ 125°C | Through Hole | - | 846-015 | Green | Solder | download | ROHS3 Compliant | REACH Unaffected | 151-846-015-526-607 | EAR99 | 8536.69.4040 | 25 | 0.125" (3.18mm) | 1 | Gold | 10.0µin (0.25µm) | Copper Alloy | Cantilever | 15 | Female | Non Specified - Single Edge | 15 | 0.054" ~ 0.070" (1.37mm ~ 1.78mm) | Single | Top Mount Opening, Threaded Insert, M3 | Diallyl Phthalate (DAP) | 1 | ||
|
395-056-523-403 | 16.9520 | |
4780 | 0.00000000 | EDAC Inc. | 395 | Box | Active | -40°C ~ 105°C | Through Hole | - | 395-056 | Black | Solder | download | ROHS3 Compliant | REACH Unaffected | 151-395-056-523-403 | EAR99 | 8536.69.4040 | 25 | 0.100" (2.54mm) | 1 | Gold | 10.0µin (0.25µm) | Copper Alloy | Cantilever | 56 | Female | Non Specified - Single Edge | 56 | 0.054" ~ 0.070" (1.37mm ~ 1.78mm) | Single | Top Mount Opening, Floating Bobbin, 0.116" (2.95mm) Dia | Polyester Thermoplastic | 1 | ||
|
846-017-559-678 | - | |
7113 | 0.00000000 | EDAC Inc. | 846 | Box | Obsolete | -40°C ~ 125°C | Through Hole, Right Angle | Card Guides | 846-017 | Green | Wire Wrap | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | 151-846-017-559-678 | EAR99 | 8536.69.4040 | 25 | 0.125" (3.18mm) | 1 | Gold | - | Copper Alloy | - | 17 | Female | Non Specified - Single Edge | 17 | 0.062" (1.57mm) | Single | Top Mount Opening, Threaded Insert, 4-40 | Diallyl Phthalate (DAP) | ||
 |
345-052-559-658 | 19.7740 | |
2793 | 0.00000000 | EDAC Inc. | 345 | Box | Active | -40°C ~ 105°C | Through Hole, Right Angle | Card Guides | 345-052 | Green | Wire Wrap | download | ROHS3 Compliant | REACH Unaffected | 151-345-052-559-658 | EAR99 | 8536.69.4040 | 25 | 0.100" (2.54mm) | 1 | Gold | 10.0µin (0.25µm) | Copper Alloy | Cantilever | 52 | Female | Non Specified - Single Edge | 52 | 0.054" ~ 0.070" (1.37mm ~ 1.78mm) | Single | Top Mount Opening, Threaded Insert, 4-40 | Polyester Thermoplastic | 1 | ||
|
846-024-541-258 | - | |
6917 | 0.00000000 | EDAC Inc. | 846 | Box | Obsolete | -40°C ~ 125°C | Through Hole | Card Guides | 846-024 | Green | Wire Wrap | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | 151-846-024-541-258 | EAR99 | 8536.69.4040 | 25 | 0.125" (3.18mm) | 2 | Gold | - | Copper Alloy | - | 24 | Female | Non Specified - Dual Edge | 12 | 0.062" (1.57mm) | Dual | Flush Mount, Top Opening, Threaded Insert, 4-40 | Diallyl Phthalate (DAP) | ||
|
845-118-558-258 | - | |
5843 | 0.00000000 | EDAC Inc. | 845 | Box | Obsolete | 845-118 | - | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | 151-845-118-558-258 | EAR99 | 8536.69.4040 | 25 | |||||||||||||||||||||
 |
833-066-540-802 | 54.6996 | |
1379 | 0.00000000 | EDAC Inc. | 833 | Box | Active | -40°C ~ 125°C | Through Hole | - | 833-066 | Green | Wire Wrap | download | ROHS3 Compliant | REACH Unaffected | 151-833-066-540-802 | EAR99 | 8536.69.4040 | 25 | 0.156" (3.96mm) | 2 | Gold | 10.0µin (0.25µm) | Copper Alloy | Cantilever | 66 | Female | Non Specified - Dual Edge | 33 | 0.054" ~ 0.070" (1.37mm ~ 1.78mm) | Dual | Top Mount Opening, Unthreaded, 0.128" (3.25mm) Dia | Diallyl Phthalate (DAP) | 2 | ||
|
807-016-505-178 | - | |
2604 | 0.00000000 | EDAC Inc. | 807 | Box | Obsolete | 807-016 | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | 151-807-016-505-178 | EAR99 | 8536.69.4040 | 25 | |||||||||||||||||||||
 |
837-042-521-608 | 77.4900 | |
9263 | 0.00000000 | EDAC Inc. | 837 | Box | Active | -40°C ~ 125°C | Through Hole | - | 837-042 | Green | Solder | download | ROHS3 Compliant | REACH Unaffected | 151-837-042-521-608 | EAR99 | 8536.69.4040 | 25 | 0.156" (3.96mm) | 1 | Gold | 10.0µin (0.25µm) | Copper Alloy | Cantilever | 42 | Female | Non Specified - Single Edge | 42 | 0.054" ~ 0.070" (1.37mm ~ 1.78mm) | Single | Top Mount Opening, Threaded Insert, 4-40 | Diallyl Phthalate (DAP) | 1 | ||
 |
346-024-526-101 | 7.4644 | |
2770 | 0.00000000 | EDAC Inc. | 346 | Box | Active | -40°C ~ 105°C | Through Hole | - | 346-024 | Green | Solder | download | ROHS3 Compliant | REACH Unaffected | 151-346-024-526-101 | EAR99 | 8536.69.4040 | 25 | 0.125" (3.18mm) | 1 | Gold | 10.0µin (0.25µm) | Copper Alloy | Cantilever | 24 | Female | Non Specified - Single Edge | 24 | 0.054" ~ 0.070" (1.37mm ~ 1.78mm) | Single | - | Polyester Thermoplastic | 1 | ||
 |
345-061-542-603 | 21.9060 | |
3805 | 0.00000000 | EDAC Inc. | 345 | Box | Active | -40°C ~ 105°C | Through Hole | - | 345-061 | Green | Wire Wrap | download | ROHS3 Compliant | REACH Unaffected | 151-345-061-542-603 | EAR99 | 8536.69.4040 | 25 | 0.100" (2.54mm) | 1 | Gold | 10.0µin (0.25µm) | Copper Alloy | Cantilever | 61 | Female | Non Specified - Single Edge | 61 | 0.054" ~ 0.070" (1.37mm ~ 1.78mm) | Single | Top Mount Opening, Floating Bobbin, 0.116" (2.95mm) Dia | Polyester Thermoplastic | 1 | ||
 |
346-024-521-804 | 7.1688 | |
3367 | 0.00000000 | EDAC Inc. | 346 | Box | Active | -40°C ~ 105°C | Through Hole | - | 346-024 | Green | Solder | download | ROHS3 Compliant | REACH Unaffected | 151-346-024-521-804 | EAR99 | 8536.69.4040 | 25 | 0.125" (3.18mm) | 2 | Gold | 10.0µin (0.25µm) | Copper Alloy | Cantilever | 24 | Female | Non Specified - Dual Edge | 12 | 0.054" ~ 0.070" (1.37mm ~ 1.78mm) | Dual | Top Mount Opening, Unthreaded, 0.156" (3.96mm) Dia | Polyester Thermoplastic | 2 | ||
 |
395-094-540-878 | 16.3772 | |
9075 | 0.00000000 | EDAC Inc. | 395 | Box | Active | -40°C ~ 105°C | Through Hole | Card Guides | 395-094 | Black | Wire Wrap | download | ROHS3 Compliant | REACH Unaffected | 151-395-094-540-878 | EAR99 | 8536.69.4040 | 25 | 0.100" (2.54mm) | 2 | Gold | 10.0µin (0.25µm) | Copper Alloy | Cantilever | 94 | Female | Non Specified - Dual Edge | 47 | 0.054" ~ 0.070" (1.37mm ~ 1.78mm) | Dual | Top Mount Opening, Threaded Insert, 4-40 | Polyester Thermoplastic | 2 | ||
 |
395-058-560-204 | 12.8396 | |
6117 | 0.00000000 | EDAC Inc. | 395 | Box | Active | -40°C ~ 105°C | Board Edge, Straddle Mount | Card Extender | 395-058 | Black | Solder | download | ROHS3 Compliant | REACH Unaffected | 151-395-058-560-204 | EAR99 | 8536.69.4040 | 25 | 0.100" (2.54mm) | 2 | Gold | 10.0µin (0.25µm) | Copper Alloy | Cantilever | 58 | Female | Non Specified - Dual Edge | 29 | 0.054" ~ 0.070" (1.37mm ~ 1.78mm) | Dual | Flush Mount, Top Opening, Unthreaded, 0.156" (3.96mm) Dia | Polyester Thermoplastic | 2 | ||
 |
746-038-540-606 | 7.9648 | |
5612 | 0.00000000 | EDAC Inc. | 746 | Box | Active | -40°C ~ 105°C | Through Hole | - | 746-038 | Black | Press-Fit, Wire Wrap | download | ROHS3 Compliant | REACH Unaffected | 151-746-038-540-606 | EAR99 | 8536.69.4040 | 25 | 0.125" (3.18mm) | 2 | Gold | 30.0µin (0.76µm) | Copper Alloy | Cantilever | 38 | Female | Non Specified - Dual Edge | 19 | 0.054" ~ 0.070" (1.37mm ~ 1.78mm) | Dual | - | Polyester Thermoplastic | 2 | ||
 |
395-048-555-807 | 13.5200 | |
9364 | 0.00000000 | EDAC Inc. | 395 | Box | Active | -40°C ~ 105°C | Board Edge, Straddle Mount | Card Extender | 395-048 | Black | Solder Eyelet(s) | download | ROHS3 Compliant | REACH Unaffected | 151-395-048-555-807 | EAR99 | 8536.69.4040 | 25 | 0.100" (2.54mm) | 2 | Gold | 10.0µin (0.25µm) | Copper Alloy | Cantilever | 48 | Female | Non Specified - Dual Edge | 24 | 0.054" ~ 0.070" (1.37mm ~ 1.78mm) | Dual | Top Mount Opening, Threaded Insert, M3 | Polyester Thermoplastic | 2 | ||
 |
322-022-554-158 | 28.5136 | |
2064 | 0.00000000 | EDAC Inc. | 322 | Box | Active | -40°C ~ 105°C | Through Hole, Right Angle | Card Guides | 322-022 | Gray | Solder Eyelet(s) | download | ROHS3 Compliant | Not Applicable | REACH Unaffected | 151-322-022-554-158 | EAR99 | 8536.69.4040 | 25 | 0.156" (3.96mm) | 2 | Gold | 10.0µin (0.25µm) | Copper Alloy | Semi Bellows | 44 | Female | Non Specified - Dual Edge | 22 | 0.054" ~ 0.070" (1.37mm ~ 1.78mm) | Dual | Flush Mount, Top Opening, Threaded Insert, 4-40 | Polycarbonate (PC), Glass Filled | 1 |
