Card Edge Connectors(468861)
| Image | Product Number | Pricing(USD) | Quantity | ECAD | Quantity Available | Weight(Kg) | Mfr | Series | Package | Product Status | Operating Temperature | Mounting Type | Features | Base Product Number | Color | Termination | DataSheet | RoHS Status | Moisture Sensitivity Level (MSL) | REACH Status | Other Names | ECCN | HTSUS | Standard Package | Pitch | Number of Rows | Contact Finish | Contact Finish Thickness | Contact Material | Contact Type | Number of Positions | Gender | Card Type | Number of Positions/Bay/Row | Card Thickness | Read Out | Flange Feature | Material - Insulation | Termination Rows |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
807-011-458-107 | 78.2952 |  |
1392 | 0.00000000 | EDAC Inc. | 807 | Bulk | Active | -40°C ~ 125°C | Through Hole, Right Angle | - | 807-011 | Green | Solder | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | 151-807-011-458-107 | EAR99 | 8536.69.4040 | 25 | 0.156" (3.96mm) | 1 | Tin | - | Copper Alloy | Semi Bellows | 11 | Female | Non Specified - Single Edge | 11 | 0.054" ~ 0.070" (1.37mm ~ 1.78mm) | Single | Flush Mount, Top Opening, Threaded Insert, M3 | Diallyl Phthalate (DAP) | 1 | |
 |
857-020-424-208 | 58.2972 | |
7392 | 0.00000000 | EDAC Inc. | 857 | Bulk | Active | -40°C ~ 125°C | Through Hole | - | 857-020 | Black | Solder | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | 151-857-020-424-208 | EAR99 | 8536.69.4040 | 25 | 0.156" (3.96mm) | 2 | Tin | - | Copper Alloy | Semi Bellows | 20 | Female | Non Specified - Dual Edge | 10 | 0.054" ~ 0.070" (1.37mm ~ 1.78mm) | Dual | Flush Mount, Top Opening, Threaded Insert, 4-40 | Polyphenylene Sulfide (PPS) | 2 | |
 |
857-022-405-112 | 87.9456 | |
8339 | 0.00000000 | EDAC Inc. | 857 | Bulk | Active | -40°C ~ 125°C | Through Hole | - | 857-022 | Black | Solder Eyelet(s) | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | 151-857-022-405-112 | EAR99 | 8536.69.4040 | 25 | 0.156" (3.96mm) | 1 | Tin | - | Copper Alloy | Semi Bellows | 22 | Female | Non Specified - Single Edge | 22 | 0.054" ~ 0.070" (1.37mm ~ 1.78mm) | Single | Side Mount Opening, Unthreaded, 0.128" (3.25mm) Dia | Polyphenylene Sulfide (PPS) | 1 | |
 |
857-012-557-108 | 140.5616 | |
3773 | 0.00000000 | EDAC Inc. | 857 | Bulk | Active | -40°C ~ 125°C | Through Hole, Right Angle | - | 857-012 | Black | Solder | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | 151-857-012-557-108 | EAR99 | 8536.69.4040 | 25 | 0.156" (3.96mm) | 2 | Gold | 10.0µin (0.25µm) | Copper Alloy | Semi Bellows | 24 | Female | Non Specified - Dual Edge | 12 | 0.054" ~ 0.070" (1.37mm ~ 1.78mm) | Dual | Flush Mount, Top Opening, Threaded Insert, 4-40 | Polyphenylene Sulfide (PPS) | 1 | |
 |
807-026-424-212 | 65.3420 | |
6390 | 0.00000000 | EDAC Inc. | 807 | Bulk | Active | -40°C ~ 125°C | Through Hole | - | 807-026 | Green | Solder | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | 151-807-026-424-212 | EAR99 | 8536.69.4040 | 25 | 0.156" (3.96mm) | 2 | Tin | - | Copper Alloy | Semi Bellows | 26 | Female | Non Specified - Dual Edge | 13 | 0.054" ~ 0.070" (1.37mm ~ 1.78mm) | Dual | Side Mount Opening, Unthreaded, 0.128" (3.25mm) Dia | Diallyl Phthalate (DAP) | 2 | |
 |
857-034-501-101 | 207.6792 | |
4431 | 0.00000000 | EDAC Inc. | 857 | Bulk | Active | -40°C ~ 125°C | Through Hole | - | 857-034 | Black | Solder Eyelet(s) | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | 151-857-034-501-101 | EAR99 | 8536.69.4040 | 25 | 0.156" (3.96mm) | 2 | Gold | 10.0µin (0.25µm) | Copper Alloy | Semi Bellows | 68 | Female | Non Specified - Dual Edge | 34 | 0.054" ~ 0.070" (1.37mm ~ 1.78mm) | Dual | - | Polyphenylene Sulfide (PPS) | 1 | |
 |
857-018-457-102 | 145.3552 | |
7979 | 0.00000000 | EDAC Inc. | 857 | Bulk | Active | -40°C ~ 125°C | Through Hole, Right Angle | - | 857-018 | Black | Solder | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | 151-857-018-457-102 | EAR99 | 8536.69.4040 | 25 | 0.156" (3.96mm) | 2 | Tin | - | Copper Alloy | Semi Bellows | 36 | Female | Non Specified - Dual Edge | 18 | 0.054" ~ 0.070" (1.37mm ~ 1.78mm) | Dual | Flush Mount, Top Opening, Unthreaded, 0.128" (3.25mm) Dia | Polyphenylene Sulfide (PPS) | 1 | |
 |
307-070-440-203 | 16.5788 | |
2828 | 0.00000000 | EDAC Inc. | 307 | Bulk | Active | -40°C ~ 105°C | Through Hole | - | 307-070 | Green | Wire Wrap | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | 151-307-070-440-203 | EAR99 | 8536.69.4040 | 25 | 0.156" (3.96mm) | 2 | Tin | - | Copper Alloy | Semi Bellows | 70 | Female | Non Specified - Dual Edge | 35 | 0.054" ~ 0.070" (1.37mm ~ 1.78mm) | Dual | Flush Mount, Floating Bobbin, 0.116" (2.95mm) Dia | Polyester Thermoplastic | 2 | |
 |
307-052-424-268 | 16.0112 | |
3939 | 0.00000000 | EDAC Inc. | 307 | Bulk | Active | -40°C ~ 105°C | Through Hole | Card Guides | 307-052 | Green | Solder | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | 151-307-052-424-268 | EAR99 | 8536.69.4040 | 25 | 0.156" (3.96mm) | 2 | Tin | - | Copper Alloy | Semi Bellows | 52 | Female | Non Specified - Dual Edge | 26 | 0.054" ~ 0.070" (1.37mm ~ 1.78mm) | Dual | Flush Mount, Top Opening, Threaded Insert, 4-40 | Polyester Thermoplastic | 2 | |
 |
857-018-456-212 | 86.9308 | |
5380 | 0.00000000 | EDAC Inc. | 857 | Bulk | Active | -40°C ~ 125°C | Board Edge, Straddle Mount | Card Extender | 857-018 | Black | Solder | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | 151-857-018-456-212 | EAR99 | 8536.69.4040 | 25 | 0.156" (3.96mm) | 2 | Tin | - | Copper Alloy | Semi Bellows | 18 | Female | Non Specified - Dual Edge | 9 | 0.054" ~ 0.070" (1.37mm ~ 1.78mm) | Dual | Side Mount Opening, Unthreaded, 0.128" (3.25mm) Dia | Polyphenylene Sulfide (PPS) | 2 | |
 |
746-049-527-106 | 12.5176 | |
3348 | 0.00000000 | EDAC Inc. | 746 | Bulk | Active | -40°C ~ 105°C | Through Hole | - | 746-049 | Black | Press-Fit | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | 151-746-049-527-106 | EAR99 | 8536.69.4040 | 25 | 0.125" (3.18mm) | 1 | Gold | 30.0µin (0.76µm) | Copper Alloy | Cantilever | 49 | Female | Non Specified - Single Edge | 49 | 0.054" ~ 0.070" (1.37mm ~ 1.78mm) | Single | - | Polyester Thermoplastic | 1 | |
 |
316-009-420-108 | 10.5672 | |
9807 | 0.00000000 | EDAC Inc. | 316 | Bulk | Active | -40°C ~ 105°C | Panel Mount, Through Hole | - | 316-009 | Green | Solder | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | 151-316-009-420-108 | EAR99 | 8536.69.4040 | 25 | 0.156" (3.96mm) | 2 | Tin | - | Copper Alloy | Cantilever | 18 | Female | Non Specified - Dual Edge | 9 | 0.054" ~ 0.070" (1.37mm ~ 1.78mm) | Dual | Flush Mount, Top Opening, Threaded Insert, 4-40 | Polyester Thermoplastic | 1 | |
 |
857-027-453-108 | 200.1680 | |
7952 | 0.00000000 | EDAC Inc. | 857 | Bulk | Active | -40°C ~ 125°C | Through Hole, Right Angle | - | 857-027 | Black | Solder | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | 151-857-027-453-108 | EAR99 | 8536.69.4040 | 25 | 0.156" (3.96mm) | 2 | Tin | - | Copper Alloy | Semi Bellows | 54 | Female | Non Specified - Dual Edge | 27 | 0.054" ~ 0.070" (1.37mm ~ 1.78mm) | Dual | Flush Mount, Top Opening, Threaded Insert, 4-40 | Polyphenylene Sulfide (PPS) | 1 | |
 |
807-026-425-103 | 105.5652 | |
1933 | 0.00000000 | EDAC Inc. | 807 | Bulk | Active | -40°C ~ 125°C | Through Hole | - | 807-026 | Green | Solder | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | 151-807-026-425-103 | EAR99 | 8536.69.4040 | 25 | 0.156" (3.96mm) | 1 | Tin | - | Copper Alloy | Semi Bellows | 26 | Female | Non Specified - Single Edge | 26 | 0.054" ~ 0.070" (1.37mm ~ 1.78mm) | Single | Flush Mount, Floating Bobbin, 0.116" (2.95mm) Dia | Diallyl Phthalate (DAP) | 1 | |
 |
717-060-525-201 | 9.3748 | |
3012 | 0.00000000 | EDAC Inc. | 717 | Bulk | Active | -40°C ~ 105°C | Through Hole | - | 717-060 | Black | Press-Fit | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | 151-717-060-525-201 | EAR99 | 8536.69.4040 | 25 | 0.156" (3.96mm) | 2 | Gold | 30.0µin (0.76µm) | Copper Alloy | Cantilever | 60 | Female | Non Specified - Dual Edge | 30 | 0.054" ~ 0.070" (1.37mm ~ 1.78mm) | Dual | - | Polyester Thermoplastic | 2 | |
 |
726-010-545-201 | 4.6688 | |
4969 | 0.00000000 | EDAC Inc. | 726 | Bulk | Active | -40°C ~ 105°C | Through Hole | - | 726-010 | Black | Press-Fit, Wire Wrap | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | 151-726-010-545-201 | EAR99 | 8536.69.4040 | 25 | 0.125" (3.18mm) | 2 | Gold | 30.0µin (0.76µm) | Copper Alloy | Cantilever | 10 | Female | Non Specified - Dual Edge | 5 | 0.054" ~ 0.070" (1.37mm ~ 1.78mm) | Dual | - | Polyester Thermoplastic | 2 | |
 |
857-041-559-107 | 150.3356 | |
1032 | 0.00000000 | EDAC Inc. | 857 | Bulk | Active | -40°C ~ 125°C | Through Hole, Right Angle | - | 857-041 | Black | Solder | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | 151-857-041-559-107 | EAR99 | 8536.69.4040 | 25 | 0.156" (3.96mm) | 1 | Gold | 10.0µin (0.25µm) | Copper Alloy | Semi Bellows | 41 | Female | Non Specified - Single Edge | 41 | 0.054" ~ 0.070" (1.37mm ~ 1.78mm) | Single | Flush Mount, Top Opening, Threaded Insert, M3 | Polyphenylene Sulfide (PPS) | 1 | |
 |
307-034-420-201 | 11.3056 | |
8040 | 0.00000000 | EDAC Inc. | 307 | Bulk | Active | -40°C ~ 105°C | Through Hole | - | 307-034 | Green | Solder | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | 151-307-034-420-201 | EAR99 | 8536.69.4040 | 25 | 0.156" (3.96mm) | 2 | Tin | - | Copper Alloy | Semi Bellows | 34 | Female | Non Specified - Dual Edge | 17 | 0.054" ~ 0.070" (1.37mm ~ 1.78mm) | Dual | - | Polyester Thermoplastic | 2 | |
 |
307-016-431-168 | 14.0252 | |
8674 | 0.00000000 | EDAC Inc. | 307 | Bulk | Active | -40°C ~ 105°C | Through Hole | Card Guides | 307-016 | Green | Solder | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | 151-307-016-431-168 | EAR99 | 8536.69.4040 | 25 | 0.156" (3.96mm) | 1 | Tin | - | Copper Alloy | Semi Bellows | 16 | Female | Non Specified - Single Edge | 16 | 0.054" ~ 0.070" (1.37mm ~ 1.78mm) | Single | Flush Mount, Top Opening, Threaded Insert, 4-40 | Polyester Thermoplastic | 1 | |
 |
345-042-525-288 | 13.8008 | |
3013 | 0.00000000 | EDAC Inc. | 345 | Bulk | Active | -40°C ~ 105°C | Through Hole | Card Guides | 345-042 | Green | Solder | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | 151-345-042-525-288 | EAR99 | 8536.69.4040 | 25 | 0.100" (2.54mm) | 2 | Gold | 10.0µin (0.25µm) | Copper Alloy | Cantilever | 42 | Female | Non Specified - Dual Edge | 21 | 0.054" ~ 0.070" (1.37mm ~ 1.78mm) | Dual | Flush Mount, Top Opening, Threaded Insert, 4-40 | Polyester Thermoplastic | 2 | |
 |
845-030-525-404 | 55.3428 | |
9366 | 0.00000000 | EDAC Inc. | 845 | Bulk | Active | -40°C ~ 125°C | Through Hole | - | 845-030 | Green | Solder | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | 151-845-030-525-404 | EAR99 | 8536.69.4040 | 25 | 0.100" (2.54mm) | 1 | Gold | 10.0µin (0.25µm) | Copper Alloy | Cantilever | 30 | Female | Non Specified - Single Edge | 30 | 0.054" ~ 0.070" (1.37mm ~ 1.78mm) | Single | Top Mount Opening, Unthreaded, 0.156" (3.96mm) Dia | Diallyl Phthalate (DAP) | 1 | |
 |
857-025-521-101 | 155.0048 | |
5309 | 0.00000000 | EDAC Inc. | 857 | Bulk | Active | -40°C ~ 125°C | Through Hole | - | 857-025 | Black | Solder | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | 151-857-025-521-101 | EAR99 | 8536.69.4040 | 25 | 0.156" (3.96mm) | 2 | Gold | 10.0µin (0.25µm) | Copper Alloy | Semi Bellows | 50 | Female | Non Specified - Dual Edge | 25 | 0.054" ~ 0.070" (1.37mm ~ 1.78mm) | Dual | - | Polyphenylene Sulfide (PPS) | 1 | |
 |
307-021-453-104 | 26.1376 | |
1849 | 0.00000000 | EDAC Inc. | 307 | Bulk | Active | -40°C ~ 105°C | Through Hole, Right Angle | - | 307-021 | Green | Solder | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | 151-307-021-453-104 | EAR99 | 8536.69.4040 | 25 | 0.156" (3.96mm) | 2 | Tin | - | Copper Alloy | Semi Bellows | 42 | Female | Non Specified - Dual Edge | 21 | 0.054" ~ 0.070" (1.37mm ~ 1.78mm) | Dual | Flush Mount, Top Opening, Unthreaded, 0.156" (3.96mm) Dia | Polyester Thermoplastic | 1 | |
 |
717-010-525-101 | 6.1492 | |
4455 | 0.00000000 | EDAC Inc. | 717 | Bulk | Active | -40°C ~ 105°C | Through Hole | - | 717-010 | Black | Press-Fit | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | 151-717-010-525-101 | EAR99 | 8536.69.4040 | 25 | 0.156" (3.96mm) | 1 | Gold | 30.0µin (0.76µm) | Copper Alloy | Cantilever | 10 | Female | Non Specified - Single Edge | 10 | 0.054" ~ 0.070" (1.37mm ~ 1.78mm) | Single | - | Polyester Thermoplastic | 1 | |
 |
345-019-525-612 | 11.0972 | |
8764 | 0.00000000 | EDAC Inc. | 345 | Bulk | Active | -40°C ~ 105°C | Through Hole | - | 345-019 | Green | Solder | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | 151-345-019-525-612 | EAR99 | 8536.69.4040 | 25 | 0.100" (2.54mm) | 1 | Gold | 10.0µin (0.25µm) | Copper Alloy | Cantilever | 19 | Female | Non Specified - Single Edge | 19 | 0.054" ~ 0.070" (1.37mm ~ 1.78mm) | Single | Side Mount Opening, Unthreaded, 0.128" (3.25mm) Dia | Polyester Thermoplastic | 1 | |
 |
807-015-453-101 | 129.0780 | |
2945 | 0.00000000 | EDAC Inc. | 807 | Bulk | Active | -40°C ~ 125°C | Through Hole, Right Angle | - | 807-015 | Green | Solder | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | 151-807-015-453-101 | EAR99 | 8536.69.4040 | 25 | 0.156" (3.96mm) | 2 | Tin | - | Copper Alloy | Semi Bellows | 30 | Female | Non Specified - Dual Edge | 15 | 0.054" ~ 0.070" (1.37mm ~ 1.78mm) | Dual | - | Diallyl Phthalate (DAP) | 1 | |
 |
345-042-525-502 | 10.0408 | |
3077 | 0.00000000 | EDAC Inc. | 345 | Bulk | Active | -40°C ~ 105°C | Through Hole | - | 345-042 | Green | Solder | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | 151-345-042-525-502 | EAR99 | 8536.69.4040 | 25 | 0.100" (2.54mm) | 2 | Gold | 10.0µin (0.25µm) | Copper Alloy | Cantilever | 42 | Female | Non Specified - Dual Edge | 21 | 0.054" ~ 0.070" (1.37mm ~ 1.78mm) | Dual | Top Mount Opening, Unthreaded, 0.128" (3.25mm) Dia | Polyester Thermoplastic | 2 | |
 |
745-082-525-206 | 11.1540 | |
7449 | 0.00000000 | EDAC Inc. | 745 | Bulk | Active | -40°C ~ 105°C | Through Hole | - | 745-082 | Black | Press-Fit | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | 151-745-082-525-206 | EAR99 | 8536.69.4040 | 25 | 0.100" (2.54mm) | 2 | Gold | 30.0µin (0.76µm) | Copper Alloy | Cantilever | 82 | Female | Non Specified - Dual Edge | 41 | 0.054" ~ 0.070" (1.37mm ~ 1.78mm) | Dual | - | Polyester Thermoplastic | 2 | |
 |
307-036-454-168 | 39.0264 | |
4475 | 0.00000000 | EDAC Inc. | 307 | Bulk | Active | -40°C ~ 105°C | Surface Mount | Card Guides | 307-036 | Green | Solder Eyelet(s) | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | 151-307-036-454-168 | EAR99 | 8536.69.4040 | 25 | 0.156" (3.96mm) | 2 | Tin | - | Copper Alloy | Semi Bellows | 72 | Female | Non Specified - Dual Edge | 36 | 0.054" ~ 0.070" (1.37mm ~ 1.78mm) | Dual | Flush Mount, Top Opening, Threaded Insert, 4-40 | Polyester Thermoplastic | 1 | |
|
345-054-525-203 | 12.7640 | |
9294 | 0.00000000 | EDAC Inc. | 345 | Bulk | Active | -40°C ~ 105°C | Through Hole | - | 345-054 | Green | Solder | download | ROHS3 Compliant | 1 (Unlimited) | REACH Unaffected | 151-345-054-525-203 | EAR99 | 8536.69.4040 | 25 | 0.100" (2.54mm) | 2 | Gold | 10.0µin (0.25µm) | Copper Alloy | Cantilever | 54 | Female | Non Specified - Dual Edge | 27 | 0.054" ~ 0.070" (1.37mm ~ 1.78mm) | Dual | Flush Mount, Floating Bobbin, 0.116" (2.95mm) Dia | Polyester Thermoplastic | 2 |
